  • Page 1 Hand-Held Computer Microsoft® Windows® Mobile 6.5 Operating System User's Guide...

  • Page 2: Limited Warranty

    Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction About this Guide Laser Warnings and Labels Label Location Label Components Front Special Purpose Keys Special Purpose Keys - 38 Key Bottom Back Battery Bay Trigger Handle Handstrap Label Locations 1-10 Chapter 2: Set Up A New MX9 Hardware Setup Software Setup Battery...
  • Page 4 Adjust Sounds and Notifications 2-11 Touch Screen 2-12 Calibrating the Touch Screen 2-12 Adjusting the Display Backlight Timer 2-12 Apply the Touch Screen Protective Film 2-12 Protect the Touch Screen when using a Holster / Carrycase 2-13 Holster without Handle 2-13 Holster with Handle 2-13...
  • Page 5 Cradle Power Connector Port 3-11 Connecting the Headset Cable 3-12 Connecting a Tethered Scanner 3-13 Chapter 4: Product Agency Compliance - MX9 Laser Light Safety Statement Vehicle Power Supply Connection Safety Statement Hazardous Locations Warnings Chapter 5: Technical Assistance...

  • Page 7: Chapter 1: Introduction

    Chapter 1: Introduction The MX9 is a ruggedized handheld computer targeted for indoor and outdoor use. It is powered by a lightweight main battery that can be removed and replaced without the need for special tools. MX9 wireless connectivity is secured by user-configured encryption and authentication protocols. The MX9 has an integrated keyboard, outdoor readable touch display, a tethered stylus, Microsoft®...

  • Page 8: Laser Warnings And Labels

    Laser Warnings and Labels Do not look into the laser’s lens. Do not stare directly into the laser beam. Do not remove the laser caution labels from the MX9. Do not connect the laser bar code aperture to any other device. The laser bar code aperture is certified for use with the MX9 only.

  • Page 9: Components

    Components Front 1. Microphone 2. Touch screen 3. Speaker 4. Scan buttons 5. Enter key 6. Scanner status LED 7. Power key Note: The above list is the same on the 38 key MX9. Special keys are listed below.

  • Page 10: Special Purpose Keys

    Special Purpose Keys 1. Function Keys 2. Cursor up and down Keys 3. Diamond 1 key 4. Backspace [BS] key and Space [SPC] key 5. Escape [ESC] key 6. Power key 7. Tab key 8. Alt key 9. Control [CTL] key 10.

  • Page 11: Special Purpose Keys - 38 Key

    Special Purpose Keys - 38 Key 1. Diamond 1 key 2. Function keys 3. Tab | Space | Backspace keys 4. Diamond 2 key 5. Orange key 6. Escape [ESC] key 7. Alpha key 8. Control [CTRL] key 9. Shift [SHIFT] key 10.

  • Page 12: Top

    Bar code reader aperture Bottom Input / Output Connector Tethered boot cover (covers I/O connector) not shown...

  • Page 13: Back

    Back Battery Bay 1. Battery Charging Terminals 2. Battery Bay 3. Battery Bay Access Tab...

  • Page 14: Trigger Handle

    Trigger Handle Trigger handle attach points 1. Upper 2. Lower 1. Trigger 2. Tether attach point Stylus storage bay in trigger handle base...

  • Page 15: Handstrap

    Handstrap 1. Handstrap 2. Handstrap Base 3. Stylus 1. Attach - Upper Handstrap Base 2. Attach - Lower Handstrap Base 1. Handstrap connector, upper 2. Stylus holder on Handstrap 3. Handstrap connector, lower...

  • Page 16: Label Locations

    Label Locations Device with Summit radio 1. Laser Warning Label 2. Bluetooth Label 3. Product Identification Label 4. Java Label (if installed) 5. Windows OS License Label 6. Tamper Proof Label The tamper-proof label covers the top right screw in the battery bay. The label states "Warranty void if removed or damaged".

  • Page 17: Chapter 2: Set Up A New Mx9

    Chapter 2: Set Up A New MX9 This page lists a quick outline of the steps you might take when setting up a new MX9. More instruction for each step is listed later in this guide. Please refer to the MX9 for Windows Mobile Reference Guide for additional information and instruction. Contact Technical Assistance if you need additional help.

  • Page 18: Battery

    MX9, any dust or moisture that enters the battery well or connector may transfer to the battery/well terminals, potentially causing damage. Warning. Only use Honeywell batteries as replacements: MX9380BATTERY 161888-0001 or 161915-0001 (Low Temperature) Insert/Replace Battery To insert the main battery, complete the following steps: 1.

  • Page 19: Remove Battery

    Remove Battery To remove the battery, complete the following steps: 1. Place the MX9 in Suspend mode. 2. Detach the bottom hook of the handstrap (if installed). 3. Slide the battery retaining clip down to release the main battery. 4. Pull the battery up and out of the battery well with a hinge motion. Place the discharged battery pack in a powered battery charger.

  • Page 20: Charge Or Recharge The Main Battery

    Charge or Recharge the Main Battery Warning. Only use Honeywell batteries as replacements: MX9380BATTERY 161888-0001 or 161915-0001 (Low Temperature) Note: The MX9 Battery Charger is designed for an indoor, protected environment. It is not authorized for use in areas designated as Hazardous Locations.

  • Page 21: Tapping The Touch Screen With A Stylus

    Tapping the Touch Screen with a Stylus Note: Always use the point of the stylus for tapping or making strokes on the touch screen. Never use an actual pen, pencil, or sharp/abrasive object to write on the touch screen. Hold the stylus as if it were a pen or pencil. Touch an element on the screen with the tip of the stylus then remove the stylus from the screen.

  • Page 22: Backlights And Indicators

    Backlights and Indicators Status LEDs Several LEDs are located on the front of the MX9 above the integrated speaker. They are: System Status LED indicates power management status. Battery Charging Status LED indicates main battery charging status. Alpha Mode Status LED applies to the 38-key keypad only. Bluetooth Status LED applies to Bluetooth client functions.

  • Page 23: Toggle Vibrate Indicator

    Toggle Vibrate Indicator The MX9 vibration motor is activated when a scan is completed successfully (good scan vibration) or with a failure (scan key released before good scan, timeout, or rejected because of Data Options configuration). The vibrations can be detected under the handstrap or through the trigger handle. Use the Speaker Volume / Vibrate Icon in the top right corner of the Today screen to toggle sound and/or vibration on or off.

  • Page 24: Device Unlocked / Device Locked

    Device Unlocked / Device Locked The MX9 can be locked manually by tapping Device unlocked on the Today screen. By default, this option is included on the Today screen. Care should be taken to not accidentally tap this area of the Today screen. Lock can be removed from the Today screen by selecting the Start >...

  • Page 25: Set Time Zone

    Set Time Zone Note: The first time it is powered up, or the device returns from a Clean Boot, the MX9 may reset the Time to the factory default value. To set the Time Zone, tap the Date/Time on the Today screen or tap Start > Settings > Clock and Alarms icon. Select the physical time zone.

  • Page 26: Set Power Timers

    Set Power Timers Tap Start > Settings > Power > Advanced tab. Adjust the timer values and tap OK. When the timer expires, the MX9 enters Suspend Mode. 2-10...

  • Page 27: Adjust Sounds And Notifications

    Adjust Sounds and Notifications Note: An application may override the control of the speaker volume. Turning off sounds saves power and prolongs battery life. The speaker is located on the front of the device above the MX9 logo. The audio volume can be adjusted to a comfortable level for the listener.

  • Page 28: Touch Screen

    Adjusting the Display Backlight Timer Start > Settings > System > Backlight The backlight settings use the Honeywell set of default timeouts. When the backlight timer expires, the display backlight is dimmed, not turned off. When both checkboxes are unchecked, the backlight never turns off (or dims).

  • Page 29: Protect The Touch Screen When Using A Holster / Carrycase

    Protect the Touch Screen when using a Holster / Carrycase Holster without Handle The MX9 is inserted upside-down in the holster with the touch screen facing the belt connecting the holster to the body. Holster with Handle The MX9 is inserted upside-down in the holster with the touch screen facing the belt connecting the holster to the body. Guide the installed trigger handle into the trigger handle notch.

  • Page 30: Carrycase

    Carrycase Remove the handstrap components from the MX9. Open the zippered case until there is enough space to insert the MX9 into the case. The touch screen must face forward so it, and the keypad, are visible through the windows in the carrycase. Close the zippers.

  • Page 31: Using The Input Panel / Virtual Keyboard

    Using the Input Panel / Virtual Keyboard The virtual keyboard is always available when needed e.g., text entry. Place the cursor in the text entry field and, using the stylus: Tap the Shift key to type one capital letter. Tap the CAPS key to type all capital letters. Tap the áü...

  • Page 32: Connecting Bluetooth Devices

    Connecting Bluetooth Devices Before connecting to Bluetooth Devices: The system administrator has discovered, paired, connected and disconnected (using LXEZ Pairing Control Panel) Bluetooth devices for each MX9. The system administrator has enabled and disabled LXEZ Pairing parameters for the MX9. The system administrator has also assigned a Computer Friendly Name using LXEZ Pairing Control Panel for the MX9.

  • Page 33: Setup Terminal Emulation Parameters

    Setup Terminal Emulation Parameters Before you make a host connection, you will, at a minimum, need to know: the alias name or IP address (Host Address) and the port number (Telnet Port) of the host system to properly set up your host session. 1.

  • Page 34: Using The Applock Switchpad

    Using the AppLock Switchpad Click the switchpad icon in the taskbar. A checkmark on the switchpad menu indicates applications currently active or available for Launching by the MX9 user. When Keyboard, on the Switchpad Menu, is selected, the default input method (Input Panel, Transcriber, or custom input method) is activated.

  • Page 35: Installing The Sim Card

    Installing the SIM Card Tools required: standard size Phillips screwdriver (not supplied). Note: Installing or removing accessories should be performed on a clean, well-lit surface. When necessary, protect the work surface, the MX9, and components from electrostatic discharge. Note: Contact Technical Assistance if you need help when installing or removing a SIMM card.

  • Page 36: Attaching The Handstrap

    Attaching the Handstrap 1. Place the MX9 with the screen facing down, on a flat stable surface. 2. Place the handstrap base (2) in the grooved area, matching the screw holes in the handstrap base with the screw holes in the body of the MX9. 3.

  • Page 37: Attaching The Trigger Handle

    Equipment needed: Torque wrench capable of torquing to 3±1 in/lb (.34±.11 N/m). Either the trigger handle or the handstrap is attached, not both. Honeywell recommends that, in the absence of a trigger handle, the handstrap be used at all times.

  • Page 38: Adjust Headset / Microphone And Secure Cable

    Adjust Headset / Microphone and Secure Cable The headset consists of an earpiece, a microphone, a clothing clip and a cable. The headset attaches to the audio cable end of the voice cable which attaches to the MX9. Align the audio connector and the headset quick connect cable end. Firmly push the cable ends together until they click and lock in place.

  • Page 39: Cleaning The Touch Screen And Scanner Aperture

    Cleaning the Touch Screen and Scanner Aperture Note: These instructions are for components made of glass. If there is a removable protective film sheet on the display, remove the film sheet before cleaning the screen. Keep fingers and rough or sharp objects away from the bar code reader scanning aperture and the mobile device touch screen. If the glass becomes soiled or smudged, clean only with a standard household cleaner such as Windex®...

  • Page 40: Startup Help

    Startup Help Contact Technical Assistance if you need more help. Can’t change the date/time or AppLock is installed and may be running in User Mode on the MX9. AppLock user mode adjust the volume. restricts access to the control panels. Touch screen is not accepting See Also: "Calibrating the Touch Screen"when the touch screen needs recalibration,...

  • Page 41: Chapter 3: Connecting Cables To The Mx9

    Chapter 3: Connecting Cables to the MX9 Note: Do not connect or disconnect cables in a Hazardous location. Connecting the USB Host and Power Cable Note: AC/DC Adapter must be assembled before this process begins. Note: Do not connect AC power to the AC Adapter yet. 1.

  • Page 42: Connecting The Usb Client And Power Cable

    Connecting the USB Client and Power Cable Note: AC/DC Adapter must be assembled before this process begins. Note: Do not connect AC power to the AC Adapter yet. 1. Holding the cable I/O connector (1), pinch the catch release buttons in until the catches are open. Connect the cable to the MX9 I/O port by matching the shape of the I/O connector on the cable with the shape of the I/O connector at the base of the MX9.

  • Page 43: Connecting The Serial And Power Cable

    Connecting the Serial and Power Cable Note: AC/DC Adapter must be assembled before this procedure begins. Note: Do not connect AC power to the AC Adapter yet. 1. Holding the cable I/O connector (1), squeeze the catch release buttons in until the catches are open. Connect the cable to the MX9 I/O port by matching the shape of the I/O connector on the cable with the shape of the I/O connector at the base of the MX9.

  • Page 44: Connecting An External Power Supply

    Connecting an External Power Supply 1. Connects to multi-purpose cables connected to I/O port on MX9 2. AC receptacle 3. Wall plug 4. AC connection from wall to adapter To apply external power to the MX9 follow the steps below in sequence. 1.

  • Page 45: Connecting Vehicle Power

    Complete vehicle cradle mounting and power instruction is contained in the MX9 Cradle Guide. The MX9 must have a main battery installed before docking the MX9 in a cradle. DC to DC Power Supply Installation For use with Honeywell power supplies: 9000301PWRSPLY – Power Supply, 18-60VDC with cable 9000302PWRSPLY – Power Supply, 60-110VDC with cable Connecting Electrical Cables to Power Sources The DC to DC power supply is used to provide vehicle power to the MX9 when placed in a DC powered vehicle dock.

  • Page 46: Wiring Schematic

    Wiring Schematic 1. Existing Circuitry on Vehicle 2. Forklift Battery 3. Main Switch 4. 5A slow fuse close to power source 5. Power input 6. Isolated DC power output 7. Green 8. Red / Black 9. Red / White 10. Use color scheme corresponding to input wire provided 11.
  • Page 47 10. Wire colors depend on the type of device attached. Please refer to this illustration for wire colors. 11. Use the looms and wire ties to secure all wiring as shown above, then reattach the cover with the screws. 12. Connect the DC to DC converter to the vehicle’s electrical system. 13.

  • Page 48: Vehicle 12V Bare Wire Adapter

    Vehicle 12V Bare Wire Adapter Part Number: 9000A079CBL12ML3 Caution For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle. This fused circuit requires a ten Amp maximum time delay (slow blow) high interrupting rating fuse. If the supply con- nection is made directly to the battery, the fuse should be installed in the positive lead within 5 inches of the battery positive (+) terminal.

  • Page 49: Connecting The Power Cable To The Vehicle

    Connecting the Power Cable to the Vehicle 1. Vehicle Electrical System 2. 10 Amp Slow Blow Fuse 3. DC + 4. DC - 5. Vehicle Chassis 6. Brown 7. Blue 8. Green Note: Correct electrical polarity is required for safe and proper installation. The cradle will not power on or function if the cable is connected with the polarity reversed.

  • Page 50: Connect Vehicle 12Vdc Connection

    Use proper electrical and mechanical fastening means for terminating the cable. Properly sized “crimp” type electrical terminals are an accepted method of termination. Select electrical connectors sized for use with 18AWG (1mm2) conductors. Wiring color codes for Honeywell supplied DC input power cabling: Vehicle Supply Wire Color...

  • Page 51: Connect Power Supply To Vehicle Cradle

    Connect Power Supply to Vehicle Cradle The power cable connector is L-shaped. The long end of the L (the cable) will be facing up towards the middle strain relief cable clamp. Align the connector pins to the vehicle cradle Power connector; firmly pushing the connector into the Power port. Tighten the nut of the plug clockwise until the power cable is securely fastened.

  • Page 52: Connecting The Headset Cable

    Connecting the Headset Cable Headset 1. Microphone 2. Headphones 3. Connects to voice cable end of voice cable Connect the MX9 voice cable I/O connector to the I/O port on the MX9. The MX9 internal microphone and speaker are automatically disabled. Slide the voice cable ends together until they click shut.

  • Page 53: Connecting A Tethered Scanner

    Connecting a Tethered Scanner 1. Connect to I/O port 2. Connect to tethered scanner 1. Squeeze the I/O port connector latches inwards. Connect part (1) of the RS232 cable to the I/O port at the base of the MX9. Release the connector latches and test the connection for stability. 2.
  • Page 54 3-14...

  • Page 55: Chapter 4: Product Agency Compliance - Mx9

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Notice Changes or modifications made to this equipment not expressly approved by Honeywell may void the FCC authorization to operate this equipment. EMC Directive Requirements This is a Class B product.
  • Page 56 It is advisable to use the device only in the normal operating position. Handheld Devices This device was tested for typical body-worn operation. Use only Honeywell tested and approved accessories to ensure FCC Compliance. The use of third-party accessories may not comply with FCC RF exposure compliance requirements, and should be avoided.
  • Page 57 R&TTE Directive Requirements Dealer License - Republic of Singapore Republic of Singapore - LXE Dealer License Number DA103458 complies with IDA Standards.

  • Page 58: Laser Light Safety Statement

    Laser Light Safety Statement Warning: This product uses laser light. One of the following labels is provided on the scanner. Please read the Cau- tion statement. (US) Mise én garde: Ce produit utilise un rayon laser. L’une des étiquettes suivantes est apposée sur le scanneur. Veuillez lire l’avertissement qu’elle contient.

  • Page 60: Vehicle Power Supply Connection Safety Statement

    Vehicle Power Supply Connection Safety Statement Vehicle Power Supply Connection: If the supply connection is made directly to the battery, a 10A slow-blow fuse should be installed in the positive lead within 5 inches (12.7 cm.) of the battery positive (+) terminal. (US) Raccordement de l’alimentation du véhicule Si l’alimentation est raccordée directement à...

  • Page 61: Hazardous Locations Warnings

    Hazardous Locations Warnings THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C, D OR NON-HAZARDOUS LOCATIONS ONLY. WARNING - EXPLOSION HAZARD-SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR USE IN CLASS I DIVISION 2. AVERTISSEMENT - RISQUE D'EXPLOSION - LA SUBSTITUTION DE COMPOSANTS PEUT RENDRE CE MATERIEL INACCEPTABLE POUR LES EMPLACEMENTS DE CLASSE I DIVISION 2.

  • Page 63: Chapter 5: Technical Assistance

    Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;...
  • Page 64 SHALL HII BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, AND, IN NO EVENT, SHALL ANY LIABILITY OF HII ARISING IN CONNECTION WITH ANY PRODUCT SOLD HEREUNDER (WHETHER SUCH LIABILITY ARISES FROM A CLAIM BASED ON CONTRACT, WARRANTY, TORT, OR OTHERWISE) EXCEED THE ACTUAL AMOUNT PAID TO HII FOR THE PRODUCT.
  • Page 66 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com E-EQ-MX9WMOGWW Rev E 10/12...
