Electric Fireplace
holds up to a 50" flat panel television
Foyer Électrique
le support de TV supportent un télévision
plat jusqu'à 50"
Chimenea Eléctrica
el soporte de Televisión sostiene hasta
un televisor de pantalla plana de 50"
SAVE THESE INSTRUCTIONS
CONSERVER CES INSTRUCTIONS
GUARDE ESTAS INSTRUCCIONES
MTVS2547SE
1 1
YEAR
AN
AÑO
REV06-21
Assembly Instructions
Instructions d'assemblage
Instrucciones de montaje
Advertisement
Related Manuals for Muskoka Bellamy MTVS2547SE
Summary of Contents for Muskoka Bellamy MTVS2547SE
- Page 1 Electric Fireplace holds up to a 50” flat panel television Foyer Électrique le support de TV supportent un télévision plat jusqu’à 50” Chimenea Eléctrica el soporte de Televisión sostiene hasta un televisor de pantalla plana de 50“ YEAR AÑO SAVE THESE INSTRUCTIONS CONSERVER CES INSTRUCTIONS GUARDE ESTAS INSTRUCCIONES REV06-21...
-
Page 2: Parts View
TIPS FOR THE ASSEMBLY OF YOUR NEW MANTEL Before you begin assembly, locate the instructions and hardware. Take out all the parts and compare them to the diagrams below. Be sure you have all the parts and can identify them. CARE AND MAINTENANCE 1. -
Page 3: Assembly
GET READY TO START FIG 7 Before assembly, use scissors to unwrap the parts from the packaging. DO NOT use a box cutter or exacto-knife as you may cut into the mantel pieces inside the box and damage the finish. Check for the hardware bag which is red and located inside the packaging, taped to the top box. - Page 4 CAM LOCK Step 4 Step 4 FIG 2 Locate the left and right exterior panels E & F, central shelf D and upper facing panel N. Insert 2 cam lock dowels (BB) into the 2 upper holes on each of the left and right exterior panels E & F. Make sure the threaded side is against each panel so you can insert and tighten each cam lock dowel (BB) into each hole in exterior panels E &...
- Page 5 FIG 2 FIG 4 Step 6 Step 6 Locate top G. Turn top G upside down on a clean, dry surface. Insert 4 cam lock dowels (BB) into the 4 holes on the underside of top G. Get your assistant. This top is very heavy. It will take 2 people to lift and position the top into place.
- Page 6 Step 9 Step 9 FIG 7 Locate left and right doors K and L. Open the 2 hinges already CAM LOCK DOWEL CAM LOCK DOWEL assembled to left exterior panel E. Take door K and place the mounting bracket from the top hinge onto the recessed hinge position on left CAM LOCK CAM LOCK door K.
- Page 7 CAM LOCK CAM LOCK DOWEL WOOD DOWEL Step 12 Step 12 FIG 11 FIG 13 CAM LOCK Anti-tipping device (instructions included with hardware) MOUNTING PEG 1. Attach one of the mounting brackets (JJ) securely to the back WALL WOOD DOWEL edge of the furniture.
-
Page 8: Warranty
WARRANTY Greenway Home Products is pleased to offer in-home warranty repairs. Please refer to your Firebox Use and Care Guide for warranty information on your Firebox. DO NOT RETURN THIS PRODUCT TO THE STORE: Please contact Customer Service at: 1-866-253-0447 Monday to Thursday from 8:30AM to 5:00PM (EST), Friday from 8:30AM to 4:00PM (EST) Web: www.greenwayhp.com Email: support@greenwayhp.com...
