Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / overview.fm / 8.8.06

The handset at a glance

¨
15
11.11.05
§§§§§§INT§§§§§
14
13
12
11
10

Base station at a glance

1 Paging key
1
V
2
11:56
§§§Menu§§
3
4
10 Recall key
5
6
11 Star key
12 Connection socket for headset (page 6)
13 Handsfree key
14 Talk key
7
15 Signal strength
8
9
1
1 Display in idle status
2 Battery charge level
e V U
(1/3 charged to fully charged)
=
flashes: battery almost flat
e V U
flashes: battery charging
3 Control key (page 10)
4 Display keys (page 11)
5 End call key, On/Off key
End call, cancel function, go back one menu level
(press briefly), back to idle status (press and hold),
activate/deactivate handset (press and hold in idle
status)
6 Message key
Opens calls and message lists
Flashes: new message or new call
7 Hash key
Keypad lock on/off (press and hold, page 10)
Toggle between upper/lower case letters and
digits for text entry (page 28)
8 Alarm clock key (page 23)
Activate and deactivate the alarm clock
9 Microphone
Enter flash (press briefly)
Insert a pause (press and hold)
Ringtones on/off (press and hold in idle status),
Switch between earpiece and handsfree mode
Lights up: handsfree activated
Flashes: incoming call
Answer a call, open last number redial list (press
briefly), start dialling (press and hold)
¦ § ¨
(low to high)
¥
flashes: no reception
The handset at a glance
1

Advertisement

Table of Contents
loading

  Also See for Siemens Gigaset C 450

  Summary of Contents for Siemens Gigaset C 450

  • Page 1: The Handset At A Glance

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / overview.fm / 8.8.06 The handset at a glance The handset at a glance 1 Display in idle status 2 Battery charge level e V U (1/3 charged to fully charged) flashes: battery almost flat...
  • Page 2: Table Of Contents

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / C450_laender_IVZ.fm / 8.8.06 Contents Contents Using several handsets ..20 Registering handsets ....20 Locating a handset ("Paging") .
  • Page 3: Safety Precautions

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / security.fm / 8.8.06 Safety precautions Safety precautions Caution: Read the safety precautions and the user guide before use. Explain their contents to your children, and the potential hazards associated with using the telephone.
  • Page 4: Gigaset C450 - More Than Just A Telephone

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / starting.fm / 8.8.06 Gigaset C450 – more than just a telephone Gigaset C450 – Connecting the base station more than just a telephone ¤ First connect the mains adapter and then the phone jack as shown below .
  • Page 5: Setting Up The Handset For Use

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / starting.fm / 8.8.06 First Steps Setting up the handset for use Placing the handset in the base station and registering Inserting the batteries Important: the handset must not already be registered to a base station.
  • Page 6: Belt Clip And Headset

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / starting.fm / 8.8.06 First Steps Belt clip and headset Initial charging and discharging of batteries By using a belt clip and headset (optional) you Battery charging is indicated in the top right of...
  • Page 7: Menu Tree

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / menuetree.fm / 8.8.06 Menu tree Menu tree There are two ways to select a function: Using number combinations ("shortcut") ¤ To open the main menu, press with the handset in idle status.
  • Page 8 Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / menuetree.fm / 8.8.06 Menu tree Settings Date/Time Handset 4-2-1 Display 4-2-1-1 Screensaver 4-2-1-2 Colour Scheme 4-2-1-3 Contrast 4-2-1-4 Backlight 4-2-2 Language 4-2-3 Auto Answer 4-2-4 Register Handset 4-2-5 Reset Handset Base 4-3-2...
  • Page 9: Making Calls

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / telephony.fm / 8.8.06 Making calls Making calls Calling Line Identification When you receive a call, the caller's number Making an external call and/or name is displayed on the screen if the following conditions are met:...
  • Page 10: Handsfree Operation

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / telephony.fm / 8.8.06 Operating the handset Operating the handset Screen display with CNIP If you have CNIP, then the name (town) that is registered with your network provider for the Switching the handset on/off calling number will also be displayed.
  • Page 11: Display Keys

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / telephony.fm / 8.8.06 Operating the handset Menu guidance During an external call Open the directory. Your telephone's functions are accessed using a Adjust loudspeaker volume for menu that has a number of levels.
  • Page 12: Using The Directory And Lists

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / directories_charges.fm / 8.8.06 Using the directory and lists Using the directory and lists Managing directory entries You have selected an entry (page 12). The options are: Editing entries Directory ¢ Edit Entry Last number redial list §Menu§...
  • Page 13: Last Number Redial List

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / directories_charges.fm / 8.8.06 Using the directory and lists Please remember: (as in the directory, page 12) Delete Entry Entries with identical numbers are not over- Delete List (as in the directory, page 12) written in the receiving handset.
  • Page 14: Making Cost-Effective Calls

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / directories_charges.fm / 8.8.06 Making cost-effective calls Making cost-effective calls List entry Example of a list entry: Make your calls via a network provider who offers very low call charges (call-by-call), have New Call...
  • Page 15: Displaying The Call Duration

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / directories_charges.fm / 8.8.06 Making cost-effective calls Saving or editing entries in the preselection lists Each of the two lists can contain 11 entries with 4 digits. Numbers may be prefixed according to the country in the "with preselection"...
  • Page 16: Sms (Text Messages)

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / sms_neutral.fm / 8.8.06 SMS (text messages) SMS (text messages) Registering for SMS using the registration wizard Your unit is supplied ready for you to send text messages immediately. You can use the registration wizard to register...
  • Page 17: Receiving An Sms

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / sms_neutral.fm / 8.8.06 SMS (text messages) Receiving an SMS Draft message list In the draft message list, you can save, edit later All received text messages are saved in the and send an SMS.
  • Page 18: Setting Sms Centre

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / sms_neutral.fm / 8.8.06 SMS (text messages) Setting SMS centre Deleting incoming message list All new and old SMS in the list are deleted. ¤ Open the incoming message list. Entering/changing SMS centres ¤...
  • Page 19: Activating/Deactivating The Sms Function

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / sms_neutral.fm / 8.8.06 SMS (text messages) Activating/deactivating the SMS The message is played back. function 1. The "display call number" service is not activated. ¥ Ask your service provider to activate this func- tion (chargeable).
  • Page 20: Using The Network Mailbox

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / T-NetBox_SAG-registration.fm / 8.8.06 Using the network mailbox Using the network mailbox Using several handsets The network mailbox is your network provider's Registering handsets answering machine. You cannot use the net- work mailbox unless you have applied to your network provider.
  • Page 21: Locating A Handset ("Paging")

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / T-NetBox_SAG-registration.fm / 8.8.06 Using several handsets Locating a handset ("Paging") Ending an enquiry call Press the display key. §Back§ You can locate your handset using the base sta- You are reconnected with the external caller.
  • Page 22: Handset Settings

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / settings_bs_hs_pabx.fm / 8.8.06 Handset settings Handset settings Activating/deactivating auto answer Your handset is preconfigured, but you can change these settings to suit your individual When this function is activated, when a call requirements.
  • Page 23: Activating/Deactivating Suppression Of The First Ringtone

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / settings_bs_hs_pabx.fm / 8.8.06 Handset settings Advisory tones Setting ringer volume The ringer volume is the same for all types of Your handset uses ‘advisory tones’ to tell you ring. ¢ ¢ about different activities and statuses. The fol-...
  • Page 24: Restoring The Handset Default Settings

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / settings_bs_hs_pabx.fm / 8.8.06 Base station settings Restoring the base station to Setting the wake up time. ¢ ¢ factory settings Alarm Clock Wakeup time §Menu§ Enter the wake up time in hours...
  • Page 25: Operating The Base Station On

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / settings_bs_hs_pabx.fm / 8.8.06 Operating the base station on the PABX Operating the base station on Changing the pause after the recall key the PABX You can change the length of the pause if your PABX requires this (refer to the user guide for your PABX).
  • Page 26: Appendix

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / appendix.fm / 8.8.06 Appendix Appendix When it has fully dried out, you will normally be able to use itagain. Questions and answers Symbols and typographical conventions used If you have any questions about using your...
  • Page 27: Service (Customer Care)

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / appendix.fm / 8.8.06 Appendix Service (Customer Care) Authorisation We offer you support that is fast and tailored to This product is designed for world-wide opera- your specific needs! tion, depending on national approval outside...
  • Page 28: Writing And Editing A Text Message

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / appendix.fm / 8.8.06 Appendix Writing and editing a text message General specifications DECT standard is supported The following rules apply when writing a text message: GAP standard is supported The cursor is controlled with No.
  • Page 29 Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / appendix.fm / 8.8.06 Appendix Entering special characters Standard characters Abc--> Space Space  123 --> £ â ¥ £ < ¤ & ¥ > § ¤ ¿ ¡ “ ‘ *) Directory and other lists...
  • Page 30: Accessories

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / accessories_SAG.fm / 8.8.06 Accessories Accessories Gigaset Handsets Upgrade your Gigaset to a cordless PABX: Gigaset Handset C45 Illuminated colour display (4096 colours) Various different screensavers Illuminated keypad Handsfree operation Polyphonic ringer melodies...
  • Page 31: Index

    Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / C450_laender_SIX.fm / 8.8.06 Index Index ....Care of the telephone ....
  • Page 32 Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / C450_laender_SIX.fm / 8.8.06 Index ........
  • Page 33 Gigaset C 450 / en-AUS / A31008-M1706-C401-1-7619 / C450_laender_SIX.fm / 8.8.06 Index ......Order of entries in directory draft message list .
