12:0 LOGS

The Control panel has the ability to look at the last 9 set and unset
conditions of the panel as well as the last alarm conditions. This is useful if
the panel has been reset and you need to find the zone that caused the
alarm.
Enter a user code, the exit tone will start, then press the * key then 9, 3.
The log starts viewing Day 1 set. The log is organised as SET and UNSET
events. All events are recorded. The first alarm is shown by the relevant
LED being lit continuously. Subsequent alarms are shown by a fast pulse
of the zone LED. Any isolated zones are shown by a slow pulse of the
zone LED. The buzzer sounds whilst viewing the SET logs. Pressing the
0 key shows the last alarm event that occurred, even if the panel has been
set many times. Pressing the # key changes between viewing the SET
and UNSET logs.
automatically ends after15 seconds if no keys are pressed.
KEY VIEW
0 LAST ALARM
1 LOG EVENT 1
2 LOG EVENT 2
3 LOG EVENT 3
4 LOG EVENT 4
5 LOG EVENT 5
6 LOG EVENT 6
7 LOG EVENT 7
8 LOG EVENT 8
9 LOG EVENT 9
# SET / UNSET
Press the * key to finish.

13:0 RESETTING THE ALARM SYSTEM

If the alarm system has activated you will need to reset the panel, make a
note of the zone that caused the activation for future reference. Enter the
user code, the internal sounder will give a low two tone sound, press the #
key and an accept tone will be given and the activated zone light will go
out and the panel will reset. The system is now ready for use.
This may be done at any time. The log review
