LR-HWLV-HVAC TouchPRO Wireless
Touchscreen Thermostat
System Types
• Gas, oil, or electric heat with air
conditioning
• Warm air, hot water, high
efficiency furnaces, heat pumps,
steam, gravity
CAUTION: SHOCK HAZARD
Can cause electrical shock or equipment damage. If not avoided, could result in
minor or moderate personal injury. Disconnect power before beginning installation or
servicing.
MERCURY NOTICE
This thermostat does not contain mercury. However, do not place your old thermostat in the trash
if it contains mercury in a sealed tube. Contact the Thermostat Recycling Corporation at www.
thermostat-recycle.org or 800.238.8192 for information on how and where to properly and safely
dispose of your old thermostat.
This thermostat contains a Lithium battery which may contain Perchlorate material.
Perchlorate Material—special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate
Technical Assistance | 24 hours a day, 7 days a week | www.lutron.com
U.S.A. / Canada: 1.800.523.9466 | Mexico: +1.888.235.2910
Other Countries: +1.610.282.3800
Warranty: For warranty information, please see the Warranty enclosed with the product, or visit
www.lutron.com/resiinfo
® U.S. Registered Trademark.
Copyright © 2011 Honeywell International Inc.
All rights reserved.
• Heat only — including power
to open and close zone valves
(Series 20), and normally open
zone valves
• Heat only with fan
• Cool only
• 750 mV heating systems
™
69-2655EFS-01
Advertisement
Table of Contents
Related Manuals for Honeywell LR-HWLV-HVAC
Summary of Contents for Honeywell LR-HWLV-HVAC
- Page 1 800.238.8192 for information on how and where to properly and safely dispose of your old thermostat. This thermostat contains a Lithium battery which may contain Perchlorate material. Perchlorate Material—special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate Technical Assistance | 24 hours a day, 7 days a week | www.lutron.com U.S.A. / Canada: 1.800.523.9466 | Mexico: +1.888.235.2910 Other Countries: +1.610.282.3800 Warranty: For warranty information, please see the Warranty enclosed with the product, or visit www.lutron.com/resiinfo ® U.S. Registered Trademark. Copyright © 2011 Honeywell International Inc. All rights reserved. 69-2655EFS-01...
-
Page 2: Wallplate Installation
Installation Guide Wallplate installation Grasp top and bottom of wallplate 1. Separate wallplate from thermostat. and pull to remove from thermostat. 2. Mount wallplate as shown below. Drill 3/16 in (5 mm) holes for drywall. Drill 7/32 in (6 mm) holes for plaster. M29480 Wire hole Mounting screws Wall anchors M33026 CAUTION Thermostat should be installed by a climate control specialist to avoid damage to the equipment. -
Page 3: Battery Replacement
TouchPRO Wireless ™ Battery Replacement The TouchPRO Wireless thermostat has a coin cell battery that retains the time and date during a power failure. Under normal circumstances the coin cell should last five years. Should the time and date need to be reset after a power failure, this is an Coin cell indication that the coin cell needs to be battery tray replaced. -
Page 4: Terminal Designations
Installation Guide Wiring Terminal Designations Conventional Terminal Letters: Heat Pump Terminal Letters: Heating power. Connect to secondary Heating power. Connect to secondary side of heating system transformer. side of heating system transformer. Cooling power. Connect to secondary Cooling power. Connect to secondary side of cooling system transformer. - Page 5 TouchPRO Wireless ™ Wiring Wiring guide—conventional systems 1H/1C System (1 transformer) 1H/1C System (2 transformers) Power [1] Power (cooling transformer) [1, 2] [R+Rc joined by jumper] Power (heating transformer) [1, 2] Heat relay Heat relay Compressor contactor Compressor contactor Fan relay Fan relay 24 V common [3] 24 V common [3, 4] Optional THP9045 Wiring Module Optional THP9045 Wiring Module Terminal [9] Terminal [9] S1/S2 Optional remote sensor S1/S2 Optional remote sensor...
-
Page 6: Installer Setup
Installation Guide Verify battery function It is important to test the battery to ensure that the time and date will be retained should a power failure occur. The following procedure will verify the battery is functioning correctly: After receiving time and date from the TouchPRO Wireless thermostat, remove the thermostat from the wallplate. Wait 10 seconds and replace the thermostat. - Page 7 TouchPRO Wireless ™ Installer setup Setup functions Settings & Options (factory default in bold) 0170 System type 1 heat/1 cool conventional 2 1 heat/1 cool heat pump (no aux. heat) Heat only (2-wire systems) Heat only with fan 5 Hot water Series 20 system (power to open & close zone valves/normally open zone valves) 6 Cool only 7 2 heat/1 cool heat pump (with aux. heat) 2 heat/2 cool multistage conventional 2 heat/1 cool multistage conventional 10 1 heat/2 cool multistage conventional...
- Page 8 Installation Guide Installer setup Setup functions Settings & Options (factory default in bold) 0300 Manual/Auto Automatic changeover (Heat/Cool/Auto/OFF) changeover Manual changeover (Heat/Cool/OFF) 0320 Temperature Fahrenheit ( ºF) display Celsius ( ºC) 0340 Remote Temperature None Sensor Outdoor for Display Outdoor for Control Remote Indoor 0 Balance point only 0345...
- Page 9 TouchPRO Wireless ™ Installer setup Setup functions Settings & Options (factory default in bold) 0360 HP Aux Lockout 40 40 ºF 4.5 ºC None 5 5 ºF -15.0 ºC 10 10 ºF -12.0 ºC 15 15 ºF -9.5 ºC 20 20 ºF -6.5 ºC 25 25 ºF -4.0 ºC 30 30 ºF -1.0 ºC 35 35 ºF 1.5 ºC 45 45 ºF 7.0 ºC...
- Page 10 Installation Guide Installer setup Setup functions Settings & Options (factory default in bold) 0680 Heat temperature Standard temperature control (recommended) control Choose if room is warmer than set temperature Choose if room does not reach set temperature 0690 Cool temperature Standard temperature control (recommended) control Choose if room is cooler than set temperature...
-
Page 11: Installer System Test
TouchPRO Wireless ™ Installer system test Inside Test System During installer setup, press number status repeatedly until “Test” appears. 0170 DONE TEST M33030 DONE M33031 Press Press select test change status Press DONE to terminate testing. System test System status Cooling system Cool Stage 1 Cool Stages 1 &... - Page 12 Installation Guide Adding the thermostat to a Lutron system Programming by a Lutron Factory Trained Installer For full functionality, the HVAC Controller must be programmed to a Repeater and PC software must be used by a Lutron factory-trained installer. For questions on how to become a qualified installer, please contact your local Lutron representative. To add the thermostat to a Lutron system: Use the Lutron PC software to start activation mode. When a Lutron system is in activation mode, an unaddressed thermostat will show “Device Is...
-
Page 13: Special Functions
Accessories & replacement parts Please contact your distributor to order replacement parts. Cover plate* ............Honeywell Part Number 32003796-001 Outdoor Temperature Sensor ......Honeywell Part Number C7089U1006 Remote Indoor Temperature Sensor ....Honeywell Part Number C7189U1005 *(Use to cover marks left by old thermostats.) Specifications Temperature Ranges Electrical Ratings • Heat: 40 ºF to 90 ºF... - Page 14 Technical Assistance | 24 hours a day, 7 days a week | www.lutron.com U.S.A. / Canada: 1.800.523.9466 | Mexico: +1.888.235.2910 Other Countries: +1.610.282.3800 Warranty: For warranty information, please see the Warranty enclosed with the product, or visit www.lutron.com/resiinfo Lutron Electronics Co., Inc. Honeywell International Inc. 7200 Suter Road 1985 Douglas Drive North Coopersburg, PA 18036-1299 Golden Valley, MN 55422 http://yourhome.honeywell.com TEL: +1.610.282.3800 FAX: +1.610.282.1243 www.lutron.com © 2011 Honeywell International Inc. P/N 041-338 Rev. A 69-2655EFS—01 M.S. 09-11 Printed in U.S.A.
