1) Assembling REAR CASE from upper side.
1) When assembling, be careful dust inflow, components
damage, scratch.
11
1) Assembling completed
1) Keep eyes on SET scratch, key click tension, screw
status.
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
10
1) Insert 6 point screw.
1) When assembling, be careful dust inflow,
components damage, scratch.
2) Screw size : 1.4 * 3.5 (6001-002083)
TORQUE : 1.0~1.2 Kgf·cm
7-7
