Baumatic BWDI1206 User Manual

Baumatic BWDI1206 User Manual

Fully integrated washer dryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

BWDI1206
Fully integrated
washer dryer
dwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BWDI1206 and is the answer not in the manual?

Questions and answers

Related Manuals for Baumatic BWDI1206

Summary of Contents for Baumatic BWDI1206

  • Page 1 BWDI1206 Fully integrated washer dryer dwan...
  • Page 2 USER MANUAL FOR YOUR BAUMATIC BWDI1206 Fully integrated washer dryer NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference.

  • Page 3: Table Of Contents

    Important safety information 5 - 7 Specifications 7 – 13 Product and aperture dimensions Product specifications 7 – 8 Baumatic consumables Control panel 9 - 12 Detergent drawer 12 - 13 Preparing the wash cycle 13 - 20 Preparing your garments for washing...

  • Page 4: Environmental Note

    Environmental note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance.

  • Page 5: Important Safety Information

    General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents. Any attempt by an inexperienced person to repair the appliance, could result in injury or damage to your washing machine.
  • Page 6 Baumatic cannot be held responsible for any damage that may result. o Items such as foam rubber, shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the washer dryer.

  • Page 7: Specifications

    o It could be possible for a child or pet to gain access to the washer dryer through the porthole door. Therefore please check the drum before using the appliance. o Any packaging that is removed from the machine should be kept away from children.

  • Page 8: Baumatic Consumables

    o 180° door opening o LED display o Digital countdown indicator o Door closed indicator o Delay start o Automatic consumption reduction o Self adjusting water level to load o Imbalance control system o Overflow protection o Foam protection o Safety lock o Fuzzy logic o Adjustable feet 4 Option buttons:...

  • Page 9: Control Panel

    Control panel A) Door open button B) Program selection knob C) Door lock indicator light D) Delay start button E) Delay start indicator light F) Spin speed selection button G) Spin speed indicator light H) Stain remover button I) Extra rinse button J) Drying program selection button K) Drying program indicators L) Cold wash button...
  • Page 10 Door open button A safety device prevents the door from being opened immediately after the end of the cycle. You should wait for 2 minutes after the program has finished and ensure the door security light on the cycle progress indicator has gone out before opening the door.
  • Page 11 Stain remover button This option is recommended for heavily soiled loads. The machine rotates in such a way as to distribute the detergent evenly during the wash and rinse procedures. The spin speed increases to maximise the cleaning action. This option ensures a more intensive washing cycle to remove stains without lengthening the program time.

  • Page 12: Detergent Drawer

    After the final rinse the fabrics are left in water Woollens / silk until it is time to unload. When you are ready to unload, press the anti-crease button (M) to drain and spin. Start / pause button This button should be used to start the chosen wash program. When the button is pressed, the appliance will begin the cycle within a few seconds.

  • Page 13: Preparing The Wash Cycle

    o If liquid detergents are used, insert special container supplied into the compartment labelled “II”. o This ensures that the liquid detergent enters the drum at the right stage of the wash cycle. o Some detergents are difficult to utilise. You can use them in a drum dispenser if recommended by the detergent manufacturer.

  • Page 14: A Selection Of Wash Care Symbols

    help to prevent other garments from getting damaged during the wash. o Woollens and knitted coloured fabrics should be turned inside out before being washed in the appliance. o Small delicate items (tights, baby socks) should be placed in either a washing net or a zipped pillow case. o Curtains should be handled with particular care.

  • Page 15: Detergents And Conditioners

    o The wash care symbols should be used to help you to select the most suitable wash program. They will also help you to sort your laundry into different loads, depending on the fabric type and the highest temperature which the garment can be washed at. o If the wash care label does not appear in the table on the previous page, then please refer to the program table on pages 16-17.

  • Page 16: Program Table

    Program table Detergent Program Laundry Control Temperature drawer knob weight (°C) position (kg) Resistant Whites 90°C fabrics (cotton, linen) Cotton, Whites with 60°+ Pre mixed pre-wash resistant Fast 60°C coloureds Cotton, Non-fast 40°C mixed coloureds Delicates 30°C Mixed fabrics Fast 60°C+ Pre coloureds synthetics...

  • Page 17: Program Description

    “Chef” Cotton drying Mixed drying Program description o The cotton program is designed for maximum washing and rinsing efficiency. With spin cycles in between, the program guarantees the laundry is rinsed thoroughly. The final spin cycle ensures laundry is spun dry as much as possible up to the maximum speed.
  • Page 18 o This program allows a complete washing cycle for garments specified as “Hand-wash only” and laundry items made from silk on the fabric label. o This cycle has a maximum temperature of 30°C and concludes with 3 final rinses and no final spin. o This program allows a complete washing cycle to be carried out in approximately 30 minutes.
  • Page 19 o This program carries out 3 rinses with an intermediate spin which can be reduced or excluded using the spin speed control button (F). o The cycle can be used for rinsing any type of fabric or after hand-washing. This program can also be used as a bleaching cycle.

  • Page 20: Wash Program Guidance

    Wash program guidance o The washer dryer automatically selects a spin speed for a particular wash program. However it is possible to reduce the spin speed by using the spin reduction feature. o Important: You should make sure that the selected spin speed is appropriate for the garments that you are washing.

  • Page 21: Cancelling Or Pausing A Wash Program

    o If there is a power failure or the plug is pulled out of the socket when a wash cycle is in progress. Once power has been restored, the wash program will continue. o Whilst the wash program is in progress, the time remaining to the end of the wash cycle will show on the display.

  • Page 22: Time Remaining Indicator

    o Press the Start / Pause button (N) to begin the delay countdown. The indicator light for the chosen delay time will stop blinking and remain on. o At the end of the required delay time, the chosen program will begin.
  • Page 23 o Load your laundry into the machine. Please refer to the program table on pages 16-17 for maximum load weights. Although, if you are drying large items such as sheets or very absorbent items such as towels or jeans, it is advised that you reduce the load size for optimum performance.

  • Page 24: Table Of Drying Times (In Minutes)

    o Switch off the machine by turning the program selection knob (B) to the OFF position. Open the door and remove the laundry. Turn off the water tap. o IMPORTANT: Never open the door after the drying cycle has begun. You should wait until the cool down period is completed.

  • Page 25: The Washer Dryer Door

    Extra Dry: Recommended for towels, bathrobes and bulky loads. Cupboard Dry: For items that can be put away without ironing. Iron Dry: Leaves laundry suitable for ironing. o If you wish, you can select a timed drying cycle by pressing the drying program selection button (J) and choosing from the times shown on the indicator lights.

  • Page 26: Saving Energy When Using Your Washer Dryer

    Saving energy when using your washer dryer o To prevent any possible waste of energy, water or detergent, we recommend that you put a full load in your washer dryer but without exceeding the recommended maximum load size. Up to 50% of energy saving can be made with one full load compared to two half load washes.

  • Page 27: Stain Removal Rules

    Stain removal rules o Use warm water for soaking or pre-washing stained laundry. Hot water can set stains. o Most stains are easier to remove when they are fresh. o Before treating any stain try to establish; what kind of stain it is, how old the stain is, what the fabric type is and whether the fabric is colourfast (check the care label to find this out).
  • Page 28 cloth, a mixture of 1 unit alcohol, 2 units water should be used). Blood stain Lay your clothes in cold water for 30 minutes. If the stain still does not disappear, lay in mixture of water and ammonia (3 table-spoons of ammonia in 4 litres of water) for 30 minutes.

  • Page 29: Maintenance And Cleaning

    Maintenance and cleaning In daily use o Once a wash cycle has completed, you should pull out the detergent drawer slightly, so it can dry out. o Leave the porthole door ajar for a short while after a wash cycle has completed.

  • Page 30: The Washer Dryer Drum

    o Use warm water and a brush to thoroughly clean the three compartments of the detergent drawer. o Clean the area that the detergent drawer slides into with a brush. o Replace the detergent drawer by placing it back into the slot. Then push the drawer fully back into position.

  • Page 31: Cleaning The Filter

    Cleaning the filter o The washing machine is fitted with a special filter catching large deposits which could block discharge hose such as coins, buttons etc… so they can be easily retrieved. o Before removing filter, recommended that you place a towel below the filter cap to collect any small amounts of water which are likely to be inside the pump.

  • Page 32: General Troubleshooting

    General troubleshooting If your appliance does not appear to be functioning correctly, please refer to the table below before calling the Customer Care Helpline. Malfunction Cause Solution 1) Plug not in socket. 1) Plug it in. 2) Not switched on. 2) Switch it on.

  • Page 33: Poor Wash Results

    drying performance. Machine makes a 1) The machine has a different noise brush motor for better when spinning. performance which causes this noise. Only a small 1) New machines use less level of water water yet achieve the can be seen in same standard of washing the drum.

  • Page 34: Installation

    You may wish to move from a powder detergent and switch to a liquid detergent instead. Installation IMPORTANT: THIS INSTALLATION MUST COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION INSTALLATION GIVEN THIS INSTRUCTION MANUAL. SHOULD KEEP THE TRANSIT PACKAGING, IN CASE YOU NEED TO TRANSPORT THE MACHINE IN THE FUTURE.
  • Page 35 o Remove fixing screws A and remove the spacers B (3). o It possible spacers to fall inside the machine so you should gentle tilt the appliance to remove these. o Cover the 4 holes using the caps provided (4). o We recommend that you keep the transit bolts to immobilise the machine...

  • Page 36: Positioning And Levelling The Appliance

    Positioning and levelling the appliance o The washer dryer requires an aperture of the size given in the diagram on the previous page. o Place the washer dryer on a solid and level floor surface. o DO NOT PLACE THE WASHING MACHINE ON A CARPET. o The feet are adjustable to level the appliance on an uneven floor surface.

  • Page 37: Fitting The Décor Door

    IMPORTANT: When the washer dryer is positioned in the location where it will be used. Make sure that all four feet are resting firmly on the floor, by pressing down on each corner and checking that the appliance stands still. Fitting the décor door o The front of the appliance has been drilled to accommodate the hinges to enable the door to be opened from the left or right...
  • Page 38 o Fasten the magnetic catch striker plate (D) to the front of the appliance, placing the rubber washer (E) under the plate and screw in place with screws (G). o Snap mount the plastic cover cap (H) into the lower hinge position.

  • Page 39: Connecting To The Mains Water Supply

    Connecting to the mains water supply o Connect and fully tighten the inlet hose to the threaded inlet valve that is located at the rear of the washer dryer. You should connect the end with the right angle connector on it to the back of your appliance.

  • Page 40: Power Supply

    o IMPORTANT: Do not insert the drain hose too deeply into the water pipe, as this may cause siphoning. o NEVER EXTEND THE DRAINAGE HOSE FROM ITS ORIGINAL LENGTH. o For the washer dryer to function properly, the end of the discharge hose must be at a minimum of 50 cm and a maximum of 85 cm from the ground.

  • Page 41: Before First Use Maintenance Wash

    Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...

  • Page 42: Baumatic Consumables

    BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk...
