- Page 1 Baumatic WASHER DRYER BWD 1000W INSTRUCTIONS HANDBOOK Read and hold onto this handbook ---------...
- Page 2 This appliance complies with the provisions of the 89/336/EC Directive regarding electromagnetic compatibility and the 73/23/EC directive Low Voltage regarding e l e c t r i c a l s a f e t y m o d i f i e d by t h e 9 3 / 6 8 / E C D i re c t i ve f o r C E m a r k i n g .
- Page 3 INDEX 1-Specification 2- Installation 3- Handling 4- Maintenance 5- Cautions and advice 6- Safety features 7- Controls 8- Wash programme table...
-
Page 4: Specific Characteristics
1 - Specific characteristics 1.1 - Technical data - Dimensions..........Height..........85 cm Width..........60 cm Depth..........55 cm - Wash/Driying capacity........Cotton.........5,5 kg/2,75 kg Synthetics......2,75 kg/1,5 kg Wool...........1 kg - Power supply voltage (s.ph.)..............115 V ~ 60 Hz - Maximum power consumption washing/drying........1.600 W/1600W - Spin speed....................1000 rpm - Energy consumption cotton wash at 60ºC (without pre-wash) 1 cycle....1,25 kWh - Water consumption cotton wash at 60ºC (without pre-wash)1 cycle......50 l... -
Page 5: Installation
2- Installation 2.1 - Removing transit bolts After removing the external packing the drum must be un-blocked before the machine is used. This is done in the following manner: 1.) Unscrew and remove the four screws A-B- C-D. 2.) Push with a screwdriver at an angle in the screw holes until the four spacers (H) fall. - Page 6 2.3 - Levelling For the appliance to work under optimum conditions, it needs to be levelled perfectly, i.e.horizontal and stable. - Once the machine has been positioned in ist place, work the adjustable feet "I" at the front of the washing machine, until it is horizontal and the four feet are resting f irmly on the floor.
- Page 7 3- Handling 3.1 - Loading door-Opening Once the washing programme has f inished, push the programme button (or ON/OFF push- button) and wait 2 minutes before trying to open the door. Case A: 1. Press the hidden lever with the index and middle f ingers 1 2.
- Page 8 3.3 - Selecting the clothes load Beffore putting the clothes into the machine, you should: - Separate the clothes into three lots (cotton, synthetics and wool). - Within each group, separate the coloureds from the whites. - Once the clothes have been sorted, put them into the drum of the machine, separately according to colour and group, loose piece by piece, as per the following proportions: Cotton maximum 5,5 kg.
-
Page 9: Maintenance
4- Maintenance 4.1 - Cleaning the drain-pump outlet filter. It is advisable to periodically clean this f ilter (every 25 wash cycles) in order to maintain the correct operation of the drain pump and consequently, the washing and rinsing eff iciency. In order to clean the filter carry out the following: -Open the access door. -
Page 10: Cautions And Advice
5- Cautions and advice In order to get maximum satisfaction and performance from this appliance, it is important to follow the instructions indicated below: - This washing machine is exclusively for domestic use. - Select the clothes load correctly (section 3.3) and choose the appropriate programme (section 8). - Page 11 If the event any doubts or anomalies which arise, ring the TECHNICAL ASSISTANCE SERVICE, but first, make the following checks: a) The machine is not working. Check that: - The door is properly closed. - The fuses are not brown and the automatic cutout has not been triped. - The programmer control button P (or the push-button X) is not in the STOP position.
-
Page 12: Safety Features
6- Safety features 6.1 - The door An electro-mechanical safety device prevents the door from opening whilst the appliance is operating,thus preventing access to the inside of the machine and the consequent danger of injuries to the hands from coming into contact with high temperatures or from the movement of the drum. - Page 13 7- Controls A R X P- Programme selector This control button is used to select the prog ramme which is adequate a c c o r d i n g t o t h e n a t u r e a n d d eg r e e o f d i r t i n e s s o f t h e c l o t h e s t o b e washed.To set the prog ramme,operate the ON/OFF button (position out) and tur n the control in a clockwise direction until the indicating mark coincides with the chosen programme.
- Page 14 A- Rinse and hold push-button When activated (button IN), it makes the wash cycle of the synthetic and wool programs stop during the last rinse with the drum full of water. This operation is advisable to prevent creasing in certain fabric which need to be drip dried. To end the cycle, press the button again (button OUT).
-
Page 15: Practical Advice
Practical advice a) Correctly select the load of clothes and adequate programme (sec. 3.3 & 8). b) The temperature indicated in the programme table is the maximum which can be reached. c) One can choose the desired temperature with the temperature selector, but always lower than that indicated in the programme table (section 8). - Page 16 8- Wash programme table WOOL COTTON SYNTHETICS FABRIC ºC. SELECTOR PRE-WASH WASH BLEACH SOFTENER LOAD kg RINSE & HOLD NO SPIN 550/1000 rpm ON / OFF EXTRA RINSE CONSUMPTION WASHING MIN.
