Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for A&D HV-G Series

Summary of Contents for A&D HV-G Series

  • Page 1 Instruction Manual...
  • Page 2 Compliance ..................3 Compliance with FCC rules ............3 Outline and Features ................. 4 Unpacking ..................5 Accessories and Options list ............6 Caution ....................8 Precautions for Installing the Scale ..........8 Precautions for Operating the Scale ..........8 Precautions for Storing the Scale ..........8 Installing the Scale ................

  • Page 3: Table Of Contents

    Calibration (Adjusting the Scale)............39 14.1 The Gravity Acceleration Table ........... 40 14.2 The Complete Calibration Procedure .......... 41 14.2.1 Gravity Acceleration Correction ..........41 14.2.2 Preparation ................41 14.2.3 Calibration of the Zero Point ............ 42 14.2.4 Span Calibration ..............42 The Function Table ................
  • Page 4 Please note that this equipment generates, uses and can radiate radio frequency energy. This equipment has been tested and has been found to comply with the limits of a Class A computing device pursuant to Sub-part J of Part 15 of FCC rules.
  • Page 5 The HV-G series is a platform scale with 1/3000 resolution, and has a “triple weighing range” function to select the weighing range. Type L scales have an LCD (Liquid Crystal Display) and use batteries as a power source to provide portability. This type can also use an AC mains adaptor.
  • Page 6 HV-G Instruction Manual Page 5...
  • Page 7 Accessories for HV-G series Type Products Accessories HV-15KGV Display unit cover Instruction manual Type V HV-60KGV Display unit cover HV-200KGV 5mm Allen wrench Instruction manual HV-15KGL Display unit cover AC adaptor 6 x ‘D’ size batteries Instruction manual 6 x ‘D’ size batteries...
  • Page 8 Options List Order code or option name Accessories OP-03 RS232C interface / Relay output / Buzzer Connector JA:TCP0586 OP-04 RS422/485 interface / Relay output Connector TM:BLA9 AC adaptor OP-06 Built-in printer for type V Paper PP156 Ink ribbon ERC-05 AX-K0557A RS232C cable, D-sub 25 pin, 2m AX-KO1786-200 RS232C cable, D-sub 9 pin, 2m Consumables...
  • Page 9 Consider the following conditions to get the most from your scale. The best operation is where the temperature and relative humidity are stable, the scale is installed on a solid floor or bench and there is no draft. Do not install the scale in direct sunlight. Do not install the scale near heaters or air conditioners.
  • Page 10 This procedure includes all of the steps for installing the HV-G series scales Step 1 Unpacking Remove the base unit and column from the carton, taking care not to pull on the loadcell cable. Step 2 Fit the pan to the base unit.
  • Page 11 Step 1 Turn off the display. Remove the AC adaptor. Step 2 Press and slide to open the external cover. Press the hook of the internal cover to the left side and lift the cover. Step 3 Insert six new dry cells ensuring correct polarity (+,-).
  • Page 12 HV-G Instruction Manual Page 11...
  • Page 13 Stability mark. When the current weight value is not changing, this mark is displayed. The reading may now be taken. Zero point mark. With nothing on the pan and pressing the switch, this mark is displayed. The zero point is the ZERO starting point to weighing.
  • Page 14 Example:-. Display of the counting mode. This mode uses the registered unit mass, counts the amount of articles on the pan. The unit is PCS. Example:- Storing the unit mass in the counting mode. This is a display of zero point for counting mode and uses 20 pieces for the unit mass registration.
  • Page 15 Calibration error. Means “Calibration mass is too heavy”. Check the base unit and weighing pan. Weighed value is unstable due to drift, vibration etc. when turning on the scale. Check around the weighing pan. Check the connection of load cell cable. Remove everything from the weighing pan.
  • Page 16 Set switch. Can be used to turn the comparator on/off. (Refer to f6 ) Counting mode, it is used to enter the mode to store the unit mass. Percentage mode, it is used to enter the mode to store the 100% mass.
  • Page 17 7.1.1 Type V or Type L with AC adaptor Step 1 Connect the scale to a ground point. Step 2 Ensure that the pan is empty. Step 3 Confirm that local voltage and receptacle type fit your scale. Step 4 The scale turns on/off using the switch alternately.

  • Page 18: Type L With Batteries

    7.1.2 Type L with Batteries Step 1 Install six new batteries. Refer to “5.1. Installing the batteries for Type L”. Step 2 Ensure that the pan is empty. Step 3 The scale turns on/off using the switch alternately. ON/OFF Step 4 Check the accuracy of weighing. If you calibrate the scale, perform it after warming up the scale for 30 minutes.
  • Page 19 The “Tare” is used to cancel the mass of a container, receptacle, case, bag, etc. which is put on the pan to contain the item to be weighed. Caution The tare reduces the available weighing range. The current tare value is reset by pressing the ZERO switch or turning the scale off.
  • Page 20 This is the function to select a weighing range. The mass value is displayed within a selected range. There is the automatic range (f2 0) and manual range (f2 1) using the RANGE switch. Operation and Performance Function Table Meaning and purpose Automatic range Weighing range changes automatically as items are placed onto the pan.
  • Page 21 Pressing the MODE switch the display changes as shown below. Refer to the function table f3 for available units. Useable units are according to the factory settings. HV-G Instruction Manual Page 20...
  • Page 22 Counting Mode In counting mode the total weight of articles is converted to a count and assumes all articles have the same mass value. It is necessary to store a unit mass to count articles. Step 1 Press the switch to display the unit MODE Step 2 Press the switch to enter the mode to store a...
  • Page 23 Step 1 Press the switch to display the unit MODE Step 2 Store the unit mass of the item. Refer to “8.1 Storing a Unit Mass” Step 3 Put the container only onto the pan. Press the switch. TARE Step 5 Put articles into the container and read the count.
  • Page 24 The percent mode is to display a mass value in the unit of “%”. It is necessary to store a 100% mass value, in advance to use this function. Step 1 Press the switch to display the unit %. MODE Step 2 Press the switch to enter the mode that...
  • Page 25 Step 1 Press the switch to display the MODE unit %. Step 2 Store the unit mass of the article. Refer to “9.1 Storing a 100% Mass “ Step 3 If a container is needed, put the container only onto the pan and press switch.
  • Page 26 This function counts the number of weighed items, calculates the total mass value and can display the number and accumulated mass value. It is necessary to set the parameters of the “accumulation function ( f8 )” in the function table in advance to use this function. It is necessary to set the parameters of the “print mode ( f9 )”...
  • Page 27 Function table Meaning & Purpose f8 4 When the display is a stable value, the scale accumulates the data automatically. The next accumulation can be performed after the display returns to near-zero. Used for recording the number and mass of articles removed from the pan.
  • Page 28 Example 1 Weighing each article, the scale makes the accumulation according to f8 3 . Step 1 If accumulation has previously been used press the switch to display MODE Step 2 Press the switch to reset the accumulation data. ZERO Step 3 Return to the kg mode using the switch.
  • Page 29 This function compares a display value with the upper limit (HI) and the lower limit (LO) and displays these results. It is necessary to set the “comparator function ( f6 0 ~ f6 7 )” parameters, upper limit value (HI) and lower limit value (LO) in the function table, in advance to use this function. It is necessary to install option OP-03 or OP-04, if you use the relay output of the comparator.
  • Page 30 Step 1 Turn off the display. Press the switch while the switch is ON/OFF ZERO pressed and held. The function table is displayed. Step 2 Press the switch to display an item of the ENTER accumulation function ( Step 3 Select a parameter of the comparator function f6 0 f6 7 ) with the...
  • Page 31 f6 0 f6 2 f6 4 f6 6 Step 6 If one of been selected, press the switch to use the comparator. Step 7 Press the switch to display the MODE blinking HI. Step 8 Set the upper limit value by using the following switches.
  • Page 32 Example 1 This example is set as follows: f6 3 Function table (If the current display value is not near-zero, the scale compares the display value with the upper limit value and the lower limit value immediately.) Upper limit value (HI) 7.000kg Lower limit value (LO) 6.500kg...
  • Page 33 This function changes the scale to a filling machine which sub-divides a bulk product,e.g. grain, into loads of predetermined and virtually constant mass. It is necessary to set the parameter of the “comparator function ( f6 9 )”, “ full/dribble batch sub-function ( f10 0 ~ f10 3 )”...
  • Page 34 Caution The comparison of the full/dribble batch function is not reversible (One way se- quence). If the display value becomes less than the final value after the value reached a predetermined target value, neither HI or LO is on. The parameters of the upper limit value (HI) and the final value (HI) use the same memory.
  • Page 35 Step 1 Turn off the display. Press the switch while the switch ON/OFF ZERO is pressed and held. The function table is displayed. Step 2 Press the switch to display an item of ENTER the comparator function ( f6 ). Step 3 Select a parameter of the full/dribble batch function ( f6 9 ) with the ^ switch.
  • Page 36 Step 8 Press the switch to display the HI, MODE flashing, (of the final value). Step 9 Set the final value using the following switches:- ^ switch Selecting the value of a digit. < switch Selecting a digit. Step 10 Press the switch to store the new ENTER...
  • Page 37 This function compares a display value with the final value, preliminary value and zero band for the full/dribble batch function. The result is indicated to zero band (LO indicator), full flow (HI indicator) and dribble flow (OK indicator). Even if a weighing value increases and decreases this function continues to compare.
  • Page 38 Caution The parameters of the upper limit value (HI) and a final value (HI) use the same memory. The parameters of the lower limit value (LO) and the zero band (LO) use the same memory. The upper/lower comparator function, the simple batch function and the full/dribble batch function cannot be used at the same time because these parameters use common memory.
  • Page 39 Step 6 Press the MODE switch to display the blinking HI (of the final value). Step 7 Set the final value using the following switches. switch Selecting the value of a digit. < switch Selecting a digit. Step 8 Press the switch to store the new ENTER parameter and display the blinking OK...

  • Page 40: Calibration (Adjusting The Scale)

    Use a calibration mass at least two thirds of the weighing capacity. Caution It is necessary to calibrate the HV-G series using a mass of the OIML class M1 or equivalent. Periodically check the accuracy of weighing. Calibrate the scale, if it is moved to another location or the environment has changed.
  • Page 41 Amsterdam 9.813 Manila 9.784m/s Athens 9.800 Melbourne 9.800m/s Auckland NZ 9.799 Mexico 9.779m/s Bangkok 9.783 Milan 9.806m/s Birmingham 9.813 New York 9.802m/s Brussels 9.811 Oslo 9.819m/s Buenos Aires 9.797 Ottawa 9.806m/s Calcutta 9.788 Paris 9.809m/s Chicago 9.803 Rio de Janeiro 9.788m/s Copenhagen 9.815...

  • Page 42: Gravity Acceleration Correction

    14.2.1 Gravity Acceleration Correction Step1 Turn on the display. Open the rear cover of the display unit. Inside the display unit, press and hold the switch to enter the calibration mode. Then Cal 0 is displayed. Step2 Press the switch to enter the gravity ZERO acceleration correction mode.

  • Page 43: Calibration Of The Zero Point

    14.2.3 Calibration of the Zero Point Step 8 Press and hold the switch to enter the calibration mode after displaying normal weighing for 30 minutes. Cal 0 Then the is displayed. Step 9 With nothing on the pan, press switch while the sta- ENTER ble mark is displayed.

  • Page 44: The Function Table

    The function table is provided to store and reference items that determine the performance of the scale. Each item has a parameter. The parameters are maintained even without power applied. Step 1 Turn off the display. Press the switch while the switch is ON/OFF ZERO...
  • Page 45 Item Display Meaning and purpose The type L scale is turned off after 5 minutes of no operation, when displaying zero. f1 0 # Automatic Not used f1 1 turning off Used? Selects the method of changing the weighing range f2 0 # Range Automatic range change.
  • Page 46 Item Display Meaning and purpose Comparator f6 4 When the display value becomes stable the scale compares the display value. Pressing the switch turns the comparator on and off. f6 5 When the display value becomes stable, the scale compares the display value.
  • Page 47 Item Display Meaning and purpose Accumulation When the display becomes a stable value, the scale accumulates the data automatically. Next accumulation can perform after the display becomes near-zero. f8 4 Use: Recording number and mass of articles removed from the pan. (Put articles on the pan. Press switch at each TARE removal.)

  • Page 48: Data Format

    Item Display Meaning and purpose The function to hold the current display value. When the value becomes near-zero and the weighing value changes more than 25% +30 digits, hold display is cancelled. f12 0 # Hold Not used f12 1 The hold function is ON or OFF alternately by the switch.

  • Page 49: Stream Mode

    RS-232C interface has the following two modes. Stream mode Outputs data countinuously and can be used for printing data. Command mode Controls the scale using commands from a computer. It is necessary to set the parameters of the “Baud rate ( f4 )”, ”Output mode ( f5 )”, “...
  • Page 50 Bit Format Format 1 There are four headers for the type of data and weighing condition. Stable weighing data Unstable weighing data Stable counting data Out of range (over) The weighing data consists of 9 characters including decimal point and polarity. The polarity is always output.
  • Page 51 Format 2 There are four headers for the type of data and weighing condition. Stable weighing data Unstable weighing data Stable counting data Out of range (over) The weighing data consists of 7 characters including decimal point and polarity. The data consists of 7 characters in the counting mode. The polarity is always output.

  • Page 52: Preparation And Performance (Examples)

    The scale outputs the current display data at the same time as refreshing the display. The scale does not output data while in the setting mode. Averaging function table Refresh rate f13 0 Normal weighing Approximately 7 times/s while the display is unstable.
  • Page 53 The command mode is the function which can perform “output data”, “controlling the scale” and “setting parameters” by a command transmitted from a computer. Caution Allow at least 500 milliseconds between commands. 16.3.1 Command List The following explanation uses “format 1 ( f15 0 )” Data output The current weighing data is output.

  • Page 54: Preset Tare

    Preset tare Tare value is set and the net is displayed. The net mark is displayed. Template PT, [parameter] Command Response Net is displayed. Upper limit value An upper limit value is stored. Template HI, [parameter] Command Response The upper limit value is stored. Lower limit value A lower limit value is stored.
  • Page 55 Final value The final value is stored. Template S0, [parameter] Command Response The value is stored. Preliminary value The preliminary value is stored. Template S1, [parameter] Command Response The value is stored. Zero band The zero band is stored. Template S2, [parameter] Command Response...
  • Page 56 Step 1 Turn off the display. Press the switch while the switch is ON/OFF ZERO pressed and held. The function table is displayed. Select a parameter of the “baud rate ( f4 )” using Step 2 switches. ENTER Select “command mode ( f5 1 )” of the “output” Step 3 using the switches.
  • Page 57 Replacing RS-232C interface with this option, refer to “ RS-232C Serial Interface” for its specification. The following option cables can be used, when you do not use the relay output. AX-KO557A, AX-KO1786-200 Pin connections Pin No. Signal name Direction Description Output Relay output of HI Input...

  • Page 58: Command Mode

    Replacing RS-232C interface with this option, the RS-422/ RS-485 interface can connect up to 16 scales and control them from a computer. The RS-422/ RS-485 interface has the following two modes. Stream mode Outputs data countinuouslly. Command mode Controls the scale using commands from a computer. It is necessary to set the parameters of the “Baud rate ( f4 )”, “...
  • Page 59 Circuit Caution Please confirm that the AC adaptor type is correct for your local voltage and receptacle type. Selection switch for the RS-422/ RS-485 interface Selects either of RS-422 or RS-485 interface using a switch on the board. Installing OP-04 Step 1 Remove two screws that attach the RS232C board on...

  • Page 60: Command List

    17.2.1 Communication Format Commands consist of an address and the same command as for the RS-232C. Commands return the same command when there is no transmitting data. If address is 23, the repl y is as follows: Normal response Response of impossible command Undefined command response Bit format 17.2.2 Command List...
  • Page 61 Zero The current mass value is set to the zero point, this is same as the switch. ZERO Template Command Reply The mass value becomes zero and zero point mark is displayed. Tare The current mass value becomes zero after placing a tare (receptacle, case, etc) and the net is displayed.
  • Page 62 Accumulation data output Accumulated data is output. Template Command Reply Accumulation count output Number of accumulations is output. Template Command Reply Reset of Accumulation data and number Data and number of accumulations become zero. Template Command Reply Data and number of accumulations become zero. .inal value The final value is stored.

  • Page 63: Specifications

    It is necessary to set the parameter of the “Print mode ( f9 )” in the function table in advance. It is necessary to set the parameter of the “Date ( f16 )” on the function table in advance. Caution The date Parameter is not updated automatically. Specification Kind 5x7 dot matrix impact type...
  • Page 64 Installation of OP-06 Caution This option cannot be used with type L (Liquid Crystal Display) scales. Packed with the option OP-06 are the following items which are used to install the printer into your scale. Reference No. Description Quantity Printer cover Printer unit Printer control board Self tapping screw...
  • Page 65 (a) Connect the cable between J2 and J3 on the upper case (Item 1). (b) Free the 2 pin cable on the lower case (Item 2) and connect it to CN1. (c) Screw the upper case (Item 1) to the lower case (Item 2) using the 4 screws (Items c).
  • Page 66 HV-G series Product HV-15KGL HV-60KGL HV-200KGL HV-15KGV HV-60KGV HV-200KGV Weighing Capacity [kg] Min. weighing (1 digit) [g] Number of samples in 5*can be changed to 10*20*50*100* counting mode [units] Max. count number [units] 15,000 12,000 11,000 Display HV-GL 7 segment liquid crystal display, Character height 25mm...
  • Page 67 Dimensions HV-G Instruction Manual Page 66...
  • Page 68 HV-G Instruction Manual Page 67...

  • Page 69: Repair

    Refer to “4. Caution” for use. Refer to “6.1. Display and Symbols “ and corresponding mode for displayed error code. Refer to “14. Calibration (Adjusting Scale)” for precision weighing. Periodically check the accuracy of weighing. Calibrate the scale, if it is moved to another location or the environment has changed.
