Step 3. Replacing the drive faceplate
The Zip drive comes with a pre-installed white faceplate. If you prefer, you can
remove the white faceplate and attach the included black faceplate to the drive.
To replace the faceplate:
1. Use the electrostatic precautions in "Step 2. Unpacking the drive" on
page 1-2 when you handle the drive. Save the antistatic bag for later use.
2. Do not press on the top of the drive when you are replacing faceplates 1 .
Always hold the drive by the sides 2 . Conduct the faceplate replacement
operation on a clean, flat, padded, and static-free surface.
1
3. Using a straightened paper clip, as shown in the illustration, press on the
right tab of the faceplate to detach it from the drive; then slowly and gently
remove the faceplate. Do not bend the hooks that secure the top of the
faceplate.
