CAUTIONARY POINTS :
Although the 866F alarm unit is waterproof, it should not be submerged
•
in water. Make certain the installation location is not in an area that
water will collect around the alarm unit. Install only in locations that
are sheltered from the outside elements (such as within the seat).
Do not leave the 866F mounted in locations with condensing humid-
•
ity, high temperatures, and/or a high concentration of dust or airborne
particles.
Connecting & Mounting the Alarm Unit
NOTE: The installation described in this manual does not cover details of
connecting the "universal" or "bike specific" Installation Harness. Please
consult the manual that came with your installation harness for details.
Once the installation harness is installed, you may then complete the in-
stallation by following the steps below.
1. Ensure the battery is connected and the Installation Harness is
properly installed.
2. Plug the Installation Harness connector into the 5-pin Alarm
Unit main wiring connector. Note that the full alarm blast will go
off when the connection is made. Press button-1 on the transmitter (for
about 1 sec.) to stop the siren sound. The siren will then chirp 3 times
to confirm the system is disarmed. (If you later need to disconnect the
vehicle battery, remember to first disconnect the Alarm Unit main wiring
connector and then you may proceed with disconnecting the battery.)
3. Consider a mounting location for the 866F alarm unit somewhere
inside the seat. Keep in mind that your mounting location may impact
the range of the transmitter. If you later find the transmitter range to
be inacceptable, you will need to relocate the 866F alarm unit. For this
reason it may be best to avoid affixing the 2-sided tape or the wire ties
until you have confirmed that the transmitter range is acceptable. (In-
cluded tape is useful for flat-surface mounting, while the wire ties are
for mounting the alarm unit on a support bar.)
