Acquiring a locomotive that is currently running:
When selecting a locomotive, either directly using the + or - buttons or from the
stack, you may adjust the speed dial to approximate the locomotive's speed.
When acquiring a locomotive directly, select the locomotive address on the dis-
play. Then press and hold the direction button and adjust the Speed dial to
approximate the speed of the locomotive, then release the direction button.
When recalling a locomotive from the stack, adjust the Speed dial prior to releas-
ing the direction button. This allows you to recall a locomotive without an abrupt
change in speed.
.
THE MENU
The HandCommand has a Menu System which is used for the following set-
tings and functions:

• Controlling turnouts

• Adjust system settings • Setting speed steps

Accessing the Menu

Press both Forward and Reverse
Menu system. The display changes and now shows the last used menu. You may
scroll through the menu choices using the + and - buttons.
When you reach the desired menu, press the Enter button to access the settings
in that menu. Press the Exit button a second time to return to the locomotive dis-
play.
buttons at the same time to access the
9

Menu Selections

This menu is used to control turnouts, or control other accessories.
NOTE: You must have an accessory decoder attached to one or
more turnouts on your layout to use this function. For more about
controlling turnouts, see below.
This menu is used to select the speed steps of the selected
SPE
locomotive decoder.
.
This menu is used to change the system settings.
SY S
Controlling Turnouts
Accessory decoders, like your locomotives, require a unique address to allow
independent control. Most Accessory Decoders are programmed in groups of four.
I.E. (1,2,3,4), (5,6,7,8), (9,10,11,12), ... Accessory decoders must be pro-
grammed just like a locomotive decoder (consult the instructions included with
your accessory decoder for programming directions). After the required pro-
gramming you can use the Function buttons on your HandCommand to control
the turnouts as described on the next page.
1. Press both Forward and Reverse
Menu system.
buttons at the same time to access the
(...continued at top of next page)
10
