- Page 1 Motion tracking sensor halogen light Installation & operating manual NIGHTWATCHER SURVEILLANCE PLUS Wireless Handheld monitor nw1003X Model no:...
-
Page 2: Specifications
INTRODUCTION Congratulations on the purchase of your new Nightwatcher Security Light. Before installation of the unit, please read the operating instructions and safeguards carefully. It is important that you read and follow the instructions in the manual, even if you feel you are familiar with this type of product. -
Page 3: Installing The Bulb
OVERVIEW Lamp Cover Front housing Lamp 150W Antenna Video Camera Dip Switch Sensor LED indicator INSTALLING THE BULB Unscrew the lamp cover of the fitting and install a 150W J-type lamp. Re-fit the lamp cover and tighten the screws. IMPORTANT: THE INTALLATION OF THIS FITTING MUST BE DONE BY A QUALIFIED ELECTRICIAN. This fitting must be earthed. -
Page 4: Top View
MOUNTING THE FITTING To ensure correct operation of the sensor, mount the fitting where traffic passes across the detector. TOP VIEW GOOD SENSITIVITY LESS SENSITIVITY SETTING THE LIGHT UP TIME & SENSITIVTY Remove the back mounting box from the fixture by unscrewing the screw at the bottom. Set the Light up time &... - Page 5 FUNCTION This light is equipped with 3 motion sensors: zone 1 covers 60 degree; zone 2 covers 100 degrees and zone 3 covers 60 degrees. ZONE 2 220 degrees (maximum) in total for 3 zones. ZONE 1 ZONE 3 TOTAL DETECTION RANGE The light will switch on for 30 /60 seconds and off automatically when heat/ movement is detected.
-
Page 6: Operation
• be used with a non-abrasive cleaner. DO NOT use solvents or abrasive cleaners on any part of the Nightwatcher. NOTE: THE INTELLIGENT MOTION SENSOR TRACKING LIGHT IS DESIGNED TO ILLUMINATE WHEN THE DETECTION AREA IS ENTERED BY A PERSON AND WILL DETECT A MOVING HEAT SOURCE. -
Page 7: Assembly Instruction
NIGHTWATCHER SURVEILLANCE PLUS Wireless Handheld monitor I. OVERVIEW OF AEC-711C Holder Antenna LED indicator LCD/TV Button Power switch MENU Button OK Button Video Output Battery case Channel Button View Button (1/4) (Single/Quad) Buzzer Rechargeable battery (inside) Power Socket II. ASSEMBLY INSTRUCTION 1. - Page 8 3 . Set the channel of receiver same as that of NW2202 by pressing the channel button continuously, and the pictures are displayed on the monitor/TV. - Press “MENU Button” then press Channel Button to select “MONITOR” and press “OK button”. - Press “Channel Button”...
- Page 9 III. OPERATION When NW2202 detects any movement, the wireless LCD monitor is triggered for 30/60 seconds image at the same time. The unobstructed transmission effective range is about 80 meters, but actual transmission range may vary according to weather, location, interference and building. One wireless LCD monitor is possible to display 4 camera images. IMPORTANT IMPORTANT IMPORTANT...
- Page 10 -CAMERA： Cam1 EV：-2.0~+2.0 Set the brightness of CAMERA. Standard value is Cam2 EV：-2.0~+2.0 0, turn the knob to”-“side to reduce the brightness, Cam3 EV：-2.0~+2.0 turn the knob to”+”side to increase the brightness. Cam4 EV：-2.0~+2.0 Before attempting any setting, please power sensor light.
-
Page 11: Replace Batteries
- Please replace 3 batteries together PRODUCT WARRANTY 1 YEAR REPLACEMENT WARRANTY THIS WARRANTY FORM SHOULD BE RETAINED Your Nightwatcher Security Light is covered for a BY THE CUSTOMER AT ALL TIMES. Period of 12 months from your Date of Purchase. -
Page 12: Date Of Purchase
The Warranty covers faulty parts or workmanship. being void: The warranty is only made available by returning If the product has been operated on a supply • the product to your point of purchase with your voltage other than that specified on the unit receipt.
