NightWatcher NW 750 User Manual

Motorized led flood light with wi-fi camera
Hide thumbs Also See for NW 750:
Table of Contents

Advertisement

Quick Links

Model # NWNW750
USER GUIDE
NIGHTWATCHER NW 750
MOTORIZED LED FLOOD LIGHT WITH WI-FI CAMERA
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
OS
Windows 2000 / XP / Vista / 7, 8 & 10 / MAC
Micro Memory card
1GB SD ~ 32GB SDHC (max) Class 4
THANK YOU
We appreciate the trust and confidence you have placed in NightWatcherPro through the purchase of this motorized LED flood
light with camera. We strive to continually create quality products designed to enhance your home. Visit us online to see our full
line of products available for your home improvement needs. Thank you for choosing NightWatcherPro!

Advertisement

Table of Contents
loading

Related Manuals for NightWatcher NW 750

Summary of Contents for NightWatcher NW 750

  • Page 1 Model # NWNW750 USER GUIDE NIGHTWATCHER NW 750 MOTORIZED LED FLOOD LIGHT WITH WI-FI CAMERA IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Windows 2000 / XP / Vista / 7, 8 & 10 / MAC Micro Memory card 1GB SD ~ 32GB SDHC (max) Class 4...

  • Page 2: Table Of Contents

    4. The motion sensor may not operate correctly if it is installed: equipment. This NightWatcher NW750 is a precision electronic □ Near the outlet of a central heating boiler. device. Do not attempt to service this camera □...

  • Page 3: Warranty

    Warranty 12 MONTH WARRANTY WHAT IS COVERED 12 month limited warranty from date of purchase. Please retain proof of purchase. The manufacturer reserves the right to replace or repair the faulty unit. WHAT IS NOT COVERED The warranty does not cover damage to the unit that may occur as a result of improper installation. This product is designed to illuminate, it will not prevent the perpetration of any act, legal or illegal.

  • Page 4: Pre-Installation

    Pre-installation PLANNING INSTALLATION Never attempt to turn the light head by hand as this can damage the internal motor components. NOTE: Before attempting any installation or maintenance, ensure that the electrical supply is switched off and the circuit fuses removed or the circuit breaker is in the “OFF”...

  • Page 5: Package Contents

    Pre-installation (continued) PACKAGE CONTENTS NOTE: NightWatcherPro NW750 is designed to illuminate, record video and produce audio warnings when a person enters the detection area. While it will detect a moving heat source, there is no guarantee implied that it will provide total security or prevent illegal entry.

  • Page 6: Nightwatcher Nw750 Overview

    NightWatcher NW750 Overview Top View Front View Bottom View Side View Camera angle adjustable downward by 25 degrees...

  • Page 7: Installation

    Mounting and wiring the light Mounting and wiring the light fixture fixture (Continued) Installing your NightWatcher NW750 on a DANGER: wall or building surface - use cross bar Incorrect voltage may cause electric shock. If you are Attach the crossbar to junction box and fix by mounting not sure, please contact your retailer.
  • Page 8 Installation mounting height.

  • Page 9: Operation

    Operation Detection range Adjusting the settings This light is equipped with three motion sensors: zone 1 Selecting working mode: There is a “Mode” LED indicator covers 60 degrees, zone 2 covers 100 degrees and zone 3 hidden inside the motion detector window that will display covers 60 degrees.

  • Page 10: Led Indicator

    Before removing the micro memory card from the slot, please Camera LED indicator press the mode button on the bottom of the NightWatcher The LED light next to the memory card compartment NW750 for 3 seconds to stop the light from turning – the indicates the function status of the camera by using ‘Mode’...

  • Page 11: On-Board Controls

    - In case of system malfunction, please press once. stop automatically after 10 seconds. OFF/REC: Please press OFF/REC button to 2. The NightWatcher NW750 can hold 2 custom- remove micro memory card. Please remove card recorded messages. If you have recorded one within 30 seconds of pressing the OFF/REC button message, repeat above step for message 2.

  • Page 12: Setting The Time And Date

    Time/Date setting mode. 2. “YEAR” setting: “Y” and “10” are displayed on the 5. On the “P” (photo) setting, NightWatcher NW750 will screen. Push the TIME/DATE SET button to set year take a series of digital photographs at a rate of 1-3 photos from “10-99.”...

  • Page 13: Viewing Recorded Videos On Pc

    Operation Viewing recorded videos on PC Viewing image by computer through an memory card reader. Press the push button on the bottom of the unit for 3 seconds to disable the unit. Open the waterproofed cover on the NW750. Press OFF/REC button and take it out the memory card within 30 seconds.

  • Page 14: Viewing Streaming Videos By App

    Preparations □ Step 1: Find the Right installation location for the NightWatcher fixture within the selected wireless network range. You'll also want to test your network connection from the spot where you want to install the fixture. The easiest way to do this is take your smartphone, walk...
  • Page 15 Login Register User Account □ Device login: using for view steaming video of single camera. Input Device ID consisted of 7 digits Device name, default name is “admin” Default password is “123456” Device Login Add new camera to user account □...
  • Page 16 Login Device Login Set Camera Choose camera’s SSID which is the device ID consisted of 7 digits, enter Wi-Fi configuration page; and input the current Wi-Fi network password which you want to connect, then click “next” icon; waiting for camera connected to Wi-Fi network. Wi-Fi configuration □...
  • Page 17 User Login Device List □ Click “+” icon to enter “Add Device” page, input device ID, user name(device name), and password(device password), then click “add” icon; return to “Device List” page you can see new camera be added in. Default user name is “admin”, password is “123456”. Add Device Device List after camera added Camera setting...
  • Page 18 Click to modify the name of camera Click to modify the camera user name and password Modify the video resolution/frame rate/bit rate on mainstream substream viewing type Click to flip video horizontally or vertically Open/close “motion detection” Push/close the notification; select receive or not receive the alarm info Setting the storage format of SD card Setting the date and time Click to record streaming video or stop recording...
  • Page 19 Click black area Choose camera View page □ In the “Live View” page, double click any camera to view “full screen” mode. Double click video Click screen Full screen viewing □ Click the “More” icon in the “Video” page to choose the number of streaming videos and viewing options.
  • Page 20 Choose the video Choose the viewing way numbers be displayed Send message to friends □ Add friend: input the user name of your friend and send them a request; you can view in the friend list after your friend has accepted your invitation.
  • Page 21 Wait friend agree Friend List □ Send message: click any one friend name, then input message to send to him. View Media □ View your pictures or videos saved on your device;...
  • Page 22 View pictures captured from streaming video View videos recorded from streaming video More Check the alarm message from camera Setting PTZ step and alarm sound Check the version and function information Video recording □ Select the screen which you want to record, then click the video icon. Click again to stop the video.
  • Page 23 Click the icon to record video. Click again to stop recording. □ Click the “media” icon. Then click “Video file” to see locally recorded videos. Delete camera device 一 □ Login to the user account to enter “Device List” page, click icon to enter “camera delete”...
  • Page 24 □ Click “OK” to delete camera from list. Alarm setting □ > In the “camera settings” list, click icon to enter “alarm setting” page: Open/close receiver alarm setting Open/close receiver push message setting □ Click “Finish” to complete alarm setting. □...
  • Page 25 Enable Alarm (on/off) Select alarm type LED color indicator □ WIFI AP mode: red light flash; WIFI STA mode: green light flash; WIFI AP mode WIFI STA mode □ The light is red in the default mode; When the device is connected to the WiFi successfully, the light will change to green. After the WiFi has been successfully configured, If the device is not connected to the WiFi for more than 5 minutes, the light will change to red for 3 minutes and then try to connect to the WiFi again.

  • Page 26: Troubleshooting

    2. The NightWatcher has stopped recording to the memory card Remedy: The date needs to be set for the NightWatcher to record correctly. If there has been a prolonged power outage, the date will need to be reset. Check the LED beside the camera lens. It should be GREEN when it is recording.
  • Page 27 Q. How many videos does the memory card hold? A: The included 4GB memory card will hold approximately 500 video events of 20 seconds each. Higher capacity memory cards may also be used for added storage, up to a maximum storage capacity of 32GB. Please note that the capacity of micro memory card used in this unit will not be 100% used in order to work properly.
  • Page 28 Retain this manual for future use.
