Page 17: Chapter 1: Introduction
Chapter 1: Introduction About This Manual About This Manual This User Manual describes how to configure, operate, and maintain the Psion Omnii Hand-Held Computer. Chapter 1: Introduction provides a basic overview of Omnii. Chapter 2: Basic Operation describes the steps required to get Omnii ready for operation.
Page 18: Text Conventions
Note: Omnii Hand-Held Computer is a body worn device, and to maintain compliance with the FCC RF exposure guidelines, use a Psion approved carrying case. Use of non-approved accessories may violate FCC RF exposure guidelines.
Page 19 Optional SIRF III GPS Receiver • Optional GPS/GPRS/EDGE WWAN radio Note: 802.11b/g and Bluetooth are available simultaneously. The following figures illustrate the main features of Omnii—for detailed views, please see “Omnii Features” on page 11. Psion Omnii Hand-Held Computer User Manual...
Page 20 Chapter 1: Introduction Overview of Omnii Hand-Held Computer Figure 1.1 Omnii XT15 and RT15 Models Omnii RT15 Omnii XT15 55-Key Alpha ABC Keyboard 59-Key Alpha ABC Keyboard Figure 1.2 Bottom View (Docking Connector) Psion Omnii Hand-Held Computer User Manual...
Page 21: Regulatory Labels
Using controls or adjustments or performing procedures other than those speci- fied herein may result in hazardous radiation exposure. Figure 1.5 LED Radiation Notice Label Thi l b l i ffi d b l Psion Omnii Hand-Held Computer User Manual...
Page 23 2.4 Preparing Omnii for Operation........
Page 25: Chapter 2: Basic Operation
Chapter 2: Basic Operation Omnii Features Omnii Features Figure 2.1 Front View of Omnii XT15 Model with Alphanumeric Keyboard Speaker Beeper LEDs Display Scan Key Microphone Symbol Modifier Key FN Modifier Key ENTER/Power Key Psion Omnii Hand-Held Computer User Manual...
Page 26 Side rail Slot for Snap Module arm Figure 2.3 Bottom View 1 - Docking Connector 2 - Alignment Pin Holes 3 - M2.5 Locking Screws (for firmly attaching devices) 4 - Hand Strap Slot Psion Omnii Hand-Held Computer User Manual...
Page 27: Omnii Modules Available
Attachment Screws (4) Battery Pack Omnii Modules Available To see a current list of Omnii accessories and modules, please go to the Psion website at: http://www.psion.com/us/products/handheld.htm Documents Available To see a current list of documents and download what you need, please go to the Knowledge Base on the Psion Ingenuity Working community website: http://community.psion.com/knowledge/w/knowledgebase/product-manuals.aspx...
Page 28: Preparing Omnii For Operation
“Battery Details” on page 21. Replacing the Battery Pack Important: Always switch the unit off before changing the battery (see “Switching Omnii On and Off” on page 15). However, assuming the default power saving parameters and battery reserve level have not been altered, battery swap time is a minimum of 4 minutes—you will not lose data if the battery is replaced within this time frame.
Page 29: Switching Omnii On And Off
Switching Omnii On and Off Switching Omnii On and Off Follow the instructions below for your Omnii. If your keyboard has a power button (55- and 66-key key- boards only), press that instead of the key combinations described. Switching Omnii On •...
Page 30: Performing A Warm Reset
To execute a hard reset: • Remove the battery. • Using a coin, or other conductive item, connect pins 5 and 6 of the Omnii battery contacts for at least 6 seconds. Pin 6 Pin 5 Psion Omnii Hand-Held Computer User Manual...
Page 31: Attaching Carrying Accessories
2.10 Connectivity For information on connecting Omnii to a PC, please refer to “Data Transfer between Omnii and a PC” on page 66 Omnii contains an integrated 802.11a/b/g/n radio module. The Wi-Fi Config application is used to configure the radio for one or more wireless network profiles.
Page 33 3.10 General Maintenance ............44 Psion Omnii Hand-Held Computer User Manual...
Page 34 3.10.2 Cleaning Omnii ........
Page 35: Chapter 3: Getting To Know Your Omnii
The Suspend Threshold adjustment in the Power Properties tab allows you to determine the battery capac- ity at which Omnii will be shut down. If left at the default value, Maximum Operating Time, the unit will run until the battery is completely empty; the RAM is only backed up for a short period of time. If you choose Maximum Backup Time, Omnii shuts off with more energy left in the battery so RAM can be backed up for a longer period of time.
Page 36: The Keyboard
Chapter 3: Getting To Know Your Omnii The Keyboard Normally it takes 3 to 4 hours to charge a battery. The Omnii intelligent charging system protects the battery from over-charging by terminating the charge process when the battery is at maximum capacity.
Page 37: Regular Keys
The [ENTER/Power] key is used to execute the usual Enter keyboard functions as well as to power the unit on and off (for details refer to “Switching Omnii On and Off” on page 15). Note: 55-key and 66-key keyboards are equipped with a [Power] button. For these keyboards, the [ENTER] key does not switch the unit on or off.
Page 38: Modifier Keys
The [SCAN] Key Omnii is equipped with a single [SCAN] key on the keyboard and an extra [SCAN] button located on the left side of the unit. [SCAN] keys activate the scanner beam. For units that do not have internal scanners, these keys can be remapped to serve other functions.
Page 39: Activating Modifier Keys
3.3.3 Function Keys and Macro Keys In addition to the standard keyboard functions (see “The Keyboard” on page 22), Omnii supports function keys and macro keys. All function keys and macro keys can be custom defined for each application. The Open TekTerm applica- tion utilizes these keys (for detailed information, see the Open TekTerm Software User Manual, PN 8000073).
Page 40: Macro Keys
Important: Refer to “Keyboard Macro Keys” on page 77 for details about creating macros. Several of the Omnii keyboards are equipped with a series of macro keys that can be programmed to replace frequently used keystrokes, along with the function of executable keys like the [ENTER/Power] key, the [BACKSPACE] key, any function key and arrow key, etc.
Page 41: The Keypad Backlight
Calibrating the Touchscreen If your Omnii touchscreen has never been calibrated, or if you find that the stylus pointer is not accurate when you tap on an item, use the Stylus Properties dialog box in the Control Panel to recalibrate the screen.
Page 42: Indicators
• Follow the directions on the calibration screen to calibrate the screen. Indicators Omnii uses LEDs (Light Emitting Diodes), onscreen messages, vibrations, and audio tones as indicators. 3.5.1 LEDs Omnii is equipped with four coloured LEDs. This section outlines what these LEDs indicate.
Page 43: Battery Charge Status Led
Chapter 3: Getting To Know Your Omnii LEDs 3.5.1.1 Battery Charge Status LED The far left LED is reserved for battery charge status. This indicator is active even when the hand-held is in- serted in a docking station (and in suspend mode) so that the charge status of the battery can be detected easily.
Page 44: Onscreen Indicators
Figure 3.4 Taskbar The taskbar changes dynamically, and only those icons that are applicable are displayed. For example, if a radio is not installed in your Omnii, the radio signal icon is not displayed in the taskbar. ® Windows Start Button If you are using the touchscreen, you can either tap the Windows icon at the bottom left of the screen, or press the [Windows] key to display the Start Menu, and then tap on the desired application.
Page 45: Audio Indicators
There are two slots available in the battery compartment—the lower slot is provided for a microSD (Secure Digital) card, which provides additional non-volatile memory to your Omnii, and the upper slot is for a SIM (Subscriber Identity Module) card, which allows access to the Voice option, access to the Internet, and so...
Page 46: Scanners And Imagers
If your unit has a [Power] button, press and hold down the [FN] key and the [Power] button for a minimum of three seconds. Omnii supports a wide range of scanner options to address a variety of user application requirements. Refer to the following sections for detailed information: •...
Page 47: Basic Scanner Operations
Chapter 3: Getting To Know Your Omnii Basic Scanner Operations • EA11 2D imager: reads 1D and 2D barcodes including damaged and low contrast regular 1D barcodes; smallest barcode at 5 mil with a minimum read distance to 2.8 in. / maximum read distance of 5.1 in.;...
Page 48: Operating One Dimensional (1D) Internal Laser Scanners
Chapter 3: Getting To Know Your Omnii Operating One Dimensional (1D) Internal Laser Scanners 3.7.5 Operating One Dimensional (1D) Internal Laser Scanners • Turn the hand-held on. Wait until the unit has booted up completely. Important: If an aiming dot is available on the installed scanner, the dot will be enabled for a configurable time period (including off), after which normal scanning begins.
Page 49: Navigating Using A Touchscreen
Refer to “Calibrating the Touchscreen” on page 27. Omnii comes equipped with a stylus—a pointing tool that looks like a pen. The stylus is used to select objects on the touchscreen. You can also use gestures with your fingers. You can use two gestures: pan and flick.
Page 50: The Taskbar
The Taskbar Omnii is equipped with a taskbar at the bottom of the screen. It displays icons through which you can view the battery capacity and radio signal quality of your unit. If the hand-held is attached to a charger, cradle, docking station, or Snap Module, an associated icon is displayed.
Page 51: The Start Menu
Chapter 3: Getting To Know Your Omnii The Windows Classic Shell Startup Desktop the Keyboard menu and you press the key, it is displayed as an underlined ‘Ctrl’ in the taskbar. (For detailed information on modifier keys and keyboard options, see “The Keyboard” on page 22).
Page 52 Chapter 3: Getting To Know Your Omnii The Windows Classic Shell Startup Desktop Note: Tap on the item in the menu with which you want to work. If you’re using the keyboard: • Use the arrow keys to highlight a menu item, and press [ENTER], or If the menu item has an underlined character: •...
Page 53 Classic Shell to the PsionVU shell. Remote Desktop Connection Remote Desktop Connection is an Omnii application used to connect to a Windows Terminal Server so that you can run a “session” on the Server machine using the hand-held (Windows Embedded CE device).
Page 54 Chapter 3: Getting To Know Your Omnii The Windows Classic Shell Startup Desktop When System Tray is chosen, the taskbar icons become accessible. To display the dialog box attached to an icon: • Use the arrow keys to highlight an icon, for example, the Bluetooth icon.
Page 55 Control Panel. Network and Dial-Up Connections The Network and Dial-up Connections window allows you to configure the Omnii network interfaces or execute an existing configuration. Refer to “Connectivity” on page 17 for radio setup details.
Page 56: The Psionvu Desktop Shell
Figure 3.9 Switch to PsionVU Shell After resetting the Omnii, the desktop appearance will be very different. The programs are accessed with finger (or stylus) taps and swipes. If there are more applications than shown on one screen, a white ani- mated dot will be present on the side of the screen in the direction of the next set of icons.
Page 57 Chapter 3: Getting To Know Your Omnii The PsionVU Desktop Shell Hold the stylus or your finger on the Active Tasks, Favourites, or Notifications Bar, and swipe to the left or right to switch to the next screen. Active Tasks Bar...
Page 58: Restoring The Windows Classic Shell
The default Desktop appearance and actions can be restored by tapping on the PsionVU Shell icon in the Favourites Bar. Figure 3.10 Shell Switch to Windows Classic Shell Desktop Note: Omnii will be reset if you choose to switch shells. 3.10 General Maintenance 3.10.1...
Page 59: Cleaning Omnii
Use only mild detergent or soapy water to clean the hand-held unit. • Avoid abrasive cleaners, solvents or strong chemicals for cleaning. Omnii has a plastic case that is sus- ceptible to harsh chemicals. The plastic is partially soluble in oils, mineral spirits and gasoline. The plastic slowly decomposes in strong alkaline solutions.
Page 61 Psion Software Advantage........
Page 62 4.26.3.1 Viewing a Profile ..........111 Psion Omnii Hand-Held Computer User Manual...
Page 63 4.30.5 Monitoring the Network Connection ........129 Psion Omnii Hand-Held Computer User Manual...
Page 65: Chapter 4: Configuration
When Omnii boots up, the startup desktop (Windows Classic Shell) is displayed, and any applications stored in the Startup folder start up immediately.
Page 66: Control Panel Applications
Control Panel Applications The Control Panel provides a group of applications that allow you to customize and adjust settings on your Omnii. This section shows the related icons in the Control Panel and gives a brief description of each. App Launch Keys By mapping keys to applications using this program, you can then launch those applications from a single key-press.
Page 67 Control Panel, and lock down access to various different components on the computer and the system tray icons for security. With PsionVU and PsionVU Shell (see “The PsionVU Desktop Shell” on page 42) you can customize the entire look and feel of your User Experience. Psion Omnii Hand-Held Computer User Manual...
Page 68 Lists the programs that can be removed from your unit. To remove a program, select it and then click on the Remove button. Scanners Provides scanner parameters and the barcode symbologies that the Omnii barcode scanner will success- fully read. Screen Rotation This feature enables you to change screen orientation into either landscape, portrait, or both modes.
Page 69: App Launch Keys
The cursor moves to the App field and a new screen is displayed where you can choose the application to which you want to assign the application key. If you need to, you can Browse through the information in your Omnii until you locate the application you want to launch. •...
Page 70: Bluetooth ® Setup
• Bluetooth headset Keep in mind that Bluetooth and IEEE 802.11g radios both operate in the 2.4GHz band. Although Omnii in- cludes features to minimize interference, performance of the system will not be optimal if you use both radios simultaneously. Typically, when both radios operate in the hand-held at the same time, they cannot transmit simultaneously—this has a negative impact on overall system throughput.
Page 71: Paired
The HSP (Headset Profile) allows users to connect their device to Bluetooth enabled headsets and other audio devices. HSP/HFP services provide the following unique menu options: • Connect Audio establishes an audio connection to the Bluetooth headset. Psion Omnii Hand-Held Computer User Manual...
Page 72: Device
4.4.2.1 Discovering and Removing Devices Scan discovers Bluetooth devices in range of Omnii and lists them in this tab. Any existing devices previ- ously discovered and listed will also be displayed. Clear removes all Bluetooth devices listed except those with currently paired and connected services.
Page 73: Device Pop-Up Menu
If the remote device has authentication enabled, type the PIN in this dialog box. • To proceed without authentication, tap on Next. After entering the device PIN, the Services dialog appears with a list of services available for that device. Psion Omnii Hand-Held Computer User Manual...
Page 74 Printer Port must be chosen here if you want to communicate with a paired Bluetooth printer. For further details, see “Mode” on page 61. • Once you’ve completed the information, tap on Next and then in the Services screen, click on Done. Psion Omnii Hand-Held Computer User Manual...
Page 75: Servers
‘Bluetooth master’ and the hand-held, the ‘Bluetooth slave’. In order for the remote device to connect to the hand-held, Omnii must offer a service in the form of a server. The Servers tab allows these services to be enabled and configured. There are three server services available: Serial, Scanner and OBEX OPP.
Page 76: About
The following steps describe how to set up an Internet data connection using a GSM cellular telephone with Bluetooth. Omnii communicates via Bluetooth to the cell phone, which then accesses a WAN (Wide Area Network) and transfers data using GPRS.
Page 77 Configure button to display the Device Properties dialog box. Omnii communicates via Bluetooth to your Bluetooth equipped cellular telephone and retrieves the parameters for the Device Properties dialog box. Omnii then disconnects. Psion Omnii Hand-Held Computer User Manual...
Page 78 The phone number you enter is network carrier dependent. Once you’ve specified all the necessary information, choose the Finish button. In the Control Panel, choose the Dialing icon. 12. The values in the Dialing Properties dialog box need to be edited according to your network carrier specifications. Psion Omnii Hand-Held Computer User Manual...
Page 79: Certificates
Windows Certificate Store, and allows you to import, delete, and view these certificates. Omnii checks that the certificate has been digitally signed by a certification authority that Omnii explicitly trusts. This option is used in conjunction with 802.1x authentication to enhance Omnii security.
Page 80: Data Transfer Between Omnii And A Pc
, Windows 7 or later, operating system is installed in your PC, ActiveSync is not re- quired to transfer data between your Omnii and your PC. By using a Snap Module or Desktop Docking Station with your Omnii, you can connect to a PC with a cable and: •...
Page 81: Using Windows Mobile Device Center
To transfer data between your PC and your hand-held: • Tap on Start>Computer to display the drives. Omnii will be visible here. • Open drives, files and folders as you would on your PC. Display Properties •...
Page 82: Backlight
To maximize battery run time, keep the display backlight brightness and active durations as low as possible. Intensity This parameter is used to adjust the light intensity of the Omnii backlight. Sliding the bar to the left lowers the light intensity, and sliding it to the right raises the intensity. Bright For The value chosen from this drop-down menu determines the duration of time that the backlight stays on at the configured intensity after the last user action (keypress, scan trigger).
Page 83: Dr. Debug
Tap on Start>Settings>Control Panel. Tap on the Dr. Debug icon. 4.8.1 Status This tab indicates the status (on/off) of the debug engines. Tapping on Browse logs displays error logs for your review. The logs should be used as reference when working with Psion Technical Support personnel. 4.8.2 Settings •...
Page 84: Utilities
Utilities The Utilities tab is used to log network traffic. When you tap on the Start button, debug data is collected so that, if necessary, it can be forwarded to a Psion technician for evaluation. Error Reporting Error Reporting allows you to enable or disable Microsoft error reporting prompts.
Page 85: Power
Always on – the GPS module is powered on at all times regardless of the power state of the hand-held (suspend). • On, and off in suspend – the GPS module is powered on, but if Omnii is in suspend mode, the GPS module is turned off. 4.10.2...
Page 86: Agps
Use custom settings. The Use default settings option is generally acceptable for most applications. Note that aside from the Update field in which you can choose how long the fix is stored in your Omnii, the field values cannot be edited.
Page 87: Info
In the Control Panel, choose the Imagers icon. Note: This icon is only displayed when the appropriate imager is installed in your Omnii. If there is an imager installed but this icon is not present, additional software (ICS) may need to be installed.
Page 88: Input Panel
Chapter 4: Configuration Input Panel 4.12 Input Panel Omnii is equipped with a Soft Input Panel (SIP). Shown below is the standard Microsoft SIP, accessed from the Control Panel. Soft Keyboard Input Panel Button Icon Tapping on the Input Panel button displays a soft input panel (soft keyboard) that can be customized using the Input Panel dialog box.
Page 89: Keyboard Properties
The value assigned for this parameter determines the delay in milliseconds between repeat characters. Sliding the Repeat Delay bar to the left increases the delay between key repeats, and sliding the bar to the right shortens the repeat delay time. Psion Omnii Hand-Held Computer User Manual...
Page 90: Keyboard Backlight
In the Keyboard Properties dialog box, open the Backlight tab. Intensity This parameter is used to adjust the light intensity of the Omnii keyboard backlight. Sliding the bar to the left darkens the keyboard backlight intensity, and sliding it to the right lightens the intensity.
Page 91: Keyboard Macro Keys
Chapter 4: Configuration Keyboard Properties The options in this tab allow you to determine how modifier keys on your Omnii behave. For each modifier key—[ALT], [SHIFT], [CTRL], [FN], and [SYM]—you have the following options in the drop-down menu: Lock, OneShot, and OneShot/Lock.
Page 92: Unicode Mapping
The Unicode Mapping tab is used to map combinations of virtual key values and [CTRL] and [SHIFT] states to Unicode™ values. This tab shows the configured Unicode character along with the Unicode value. For ex- Psion Omnii Hand-Held Computer User Manual...
Page 93: Scancode Remapping
The Normal table defines unmodified key presses; the FN table defines key presses that occur when the [FN] modifier is on; the SYM table defines key presses that occur when the [SYM] modifier is on. The default Psion Omnii Hand-Held Computer User Manual...
Page 94 When Virtual Key is selected, you can choose to force [SHIFT] to be on or off when the virtual key is sent. If No Force is selected, the shift state is dependent on whether the shift state is on or off at the time the virtual key is sent. Psion Omnii Hand-Held Computer User Manual...
Page 95: Lock Sequence
Tap on OK. 4.12.1.7 Lock Sequence The Lock Sequence menu allows you to lock the Omnii keyboard to prevent keys from being pressed acci- dentally when, for example, the unit is inserted in a holster. • To lock the keyboard, tap in the checkbox next to Enable key lock sequence.
Page 96: Manage Triggers
“trigger consumer(s)”—of the trigger source. Along with keyboard keys, the external trigger (scan button) is software-based. When the specified key is pressed, the owner (for example, a decoded scanner) is sent a message. Psion Omnii Hand-Held Computer User Manual...
Page 97: Add And Edit Trigger Mapping
These dialogs allow you to add and edit trigger mappings. Trigger Key This drop-down list allows you to specify the source of the trigger events, such as the Soft Scan, Left Scan, etc., for the trigger module selected. Psion Omnii Hand-Held Computer User Manual...
Page 98: Microphone
By default, inactive owners are not shown. By checking this checkbox, all owners, both active and inactive, are displayed. 4.14 Microphone • In the Control Panel, choose the Microphone icon. Use this dialog box to adjust the gain for the specific microphones associated with your hand-held. Psion Omnii Hand-Held Computer User Manual...
Page 99: Open Tekterm
Omnii includes unique features that support Open TekTerm, a Psion application that has the ability to maintain multiple simultaneous sessions with a variety of host com- puters. For detailed information, please refer to the Open TekTerm Software User Manual, PN 8000073.
Page 100: Pocket Pc Compatibility
4.17 Pocket PC Compatibility Omnii supports the AYGShell API set that allows Pocket PC-compatible applications to run on the hand- held. Windows Embedded CE includes application programming interface (API) compatibility support for the Microsoft Windows Powered Pocket PC 2002 shell in units running Windows Embedded CE.
Page 101: Suspend Threshold And Estimated Battery Backup
‘on’ (see “Backlight” on page 68). When Omnii is idle—not receiving any user input (a key touch, a scan, and so on) or system activity (serial data, an activity initiated by an application, and so on)—the hand-held uses the value assigned in the Suspend Timeout field to determine when the unit will go to sleep (appear to be off).
Page 102: Advanced
This menu allows you to enable power to your WWAN radio, and whether or not the radio will turn off when Omnii enters Suspend Mode. To configure the radio, please refer to Appendix F: “Wireless Wide Area Network (WWAN) Settings”.
Page 103 Suspend or restart Omnii. Wakeup Device on Battery Insert When this option is enabled, whenever the battery is replaced Omnii is powered up from Suspend and the current health of the battery is displayed.
Page 104: Psionvu Access
User). The computer must be reset following a change, and a confirmation will appear to enable you to continue or dismiss the change. When opening the PsionVu Settings option, the following menus will be available: Psion Omnii Hand-Held Computer User Manual...
Page 105: Administrator Password
When an administrator password is set, the restricted options are accessed using a key combination. If a password has been set, the user would be prompted for the password. The option Show Password changes the displayed password from hidden (***) to readable. Psion Omnii Hand-Held Computer User Manual...
Page 106: Shell Settings
The following options can be enabled or disabled in the Windows Classic Shell Desktop theme: • Start Menu Bar: If disabled, access to both Start Menu and Notifications are disabled. The Notifica- tion tooltips will still display. Any changes made will occur after a device reset. Psion Omnii Hand-Held Computer User Manual...
Page 107: Restrictions
4.19.3 Restrictions This section deals with items that are by default available to users but can be restricted by an administrator. Advanced The Advanced menu lists the system features you can restrict or block. Psion Omnii Hand-Held Computer User Manual...
Page 108: Control Panel Settings
This option enables you to Export your settings file (.xml), and save it in the location of your choice. In addi- tion, an Administrator has the option to Import these settings from one device to multiple devices of the same operating system. Psion Omnii Hand-Held Computer User Manual...
Page 109: Remote Desktop Connection
Chapter 4: Configuration Remote Desktop Connection Important: A copy of this file should also be saved in a central repository for all Psion .xml files with a predefined name so that other Psion utilities can locate it. Tapping on the Export button will display a “Save As” Export Settings dialog, with the default name PsionVU_Settings.xml, which the Administrator can change even after it has been saved.
Page 110: Scanners
—for example, a 1D UPC barcode or 2D barcode. Press the SCAN key or pistol trigger, and check for a valid decode on the hand-held’s screen. For a listing of available scanners and their specifications, please refer to Chapter B: “Omnii Specifications”. 4.21.1 Barcodes 4.21.1.1...
Page 111: Restoring Default Settings
Press and hold on the parameter you want to reset. • Choose Default parameter to reset the parameter to the default setting. 4.21.2 Options This tab allows you to tailor the double-click parameters, display, and data handling options associated with your scanner. Psion Omnii Hand-Held Computer User Manual...
Page 112: Double Click Parameters
Click Data This parameter determines which character is sent to the application installed in your Omnii following a double-click. A dialog box appears, asking that you press the key you want to insert. The ASCII/Unicode key value of the keypress is displayed.
Page 113: 4.21.2.3 Data Handling
Good Scan Vibrates and Bad Scan Vibrates These parameters determine whether or not Omnii creates a vibration when a good (successful) scan or a bad (unsuccessful) scan is performed. Set these parameters to on to enable the vibration. You can set the Number and Duration of vibrations, as well as the Pause between vibrations.
Page 114 In the Translation menu, tap on the Case # to create rules. • Tap on the No rule drop-down menu to display the rules. When you choose a rule, an associated screen is displayed in which you can define the rule. Psion Omnii Hand-Held Computer User Manual...
Page 115: Case Rules
9-pin (COM5). Power (COM6 only) Pin 9 on Omnii COM6 is reserved for 5V power out and is defaulted to OFF. This parameter must be set to ON to enable power to a Snap Module or Vehicle cradle. Psion Omnii Hand-Held Computer User Manual...
Page 116 Trigger On Sequence And Trigger Off Sequence If a SICK scanner connected to an Omnii port requires a serial stream of data bytes to trigger the scanner on and another to trigger the scanner off, the Trigger On Sequence and Trigger Off Sequence parameters allow you to define these serial streams.
Page 117: Screen Rotation
Chapter 4: Configuration Screen Rotation 4.22 Screen Rotation This option allows you to determine how your Omnii screen will behave depending on how the unit is oriented. • Tap Start>Settings>Control Panel, and then tap on the Screen Rotation icon. To Maintain Screen Orientation Choose either the Portrait or Landscape radio button and uncheck the Enable auto screen rotation box.
Page 118: Creating Partitions
If more than one partition is desired, uncheck the Use All Available Diskspace checkbox, then specify the desired number of sectors to be used by the partition. Press OK. The new partition appears in the Partitions list. Psion Omnii Hand-Held Computer User Manual...
Page 119: Partition Management
Tap the Properties button. The Partition Properties dialog appears. Tap the Dismount button. The partition is dismounted. The asterisk disappears next to its name in the partitions list. Tap the Format button. The Format dialog appears: Psion Omnii Hand-Held Computer User Manual...
Page 120 Tap the Mount button. The partition is mounted. The asterisk appears next to its name in the par- titions list. The Partition Properties dialog has buttons for additional functions. Partitions can be defragmented, and their file structure can be scanned. Psion Omnii Hand-Held Computer User Manual...
Page 121: Stylus Properties
Follow the directions in the Calibration tab to recalibrate the screen You will be prompted to save the calibration data. Note: If you do not receive a prompt to save your data, there could be a problem with your touch- screen hardware. Contact your Psion representative. Psion Omnii Hand-Held Computer User Manual...
Page 122: Touch
Instead of expanding each section of items individually, you can also choose to open all the lists at once by choosing the Expand button, which will then change to a Collapse button to enable you to collapse all the sections as well. Psion Omnii Hand-Held Computer User Manual...
Page 123: Total Recall
Total Recall Total Recall is a Psion utility developed to maintain applications and settings during a cold boot, as well as clone settings to other devices. This utility creates a restore point of a device at a known state. This can be...
Page 124: Creating A Clone
• Tap on the Create Clone button to begin the process. Your Omnii model type and OS will be identified in the cloning statement to ensure that you target devices of the same type. Give the clone profile a name and location, then tap on Next.
Page 125: Managing Profiles
\Flash Disk\TotalRecall folder. In an autorestore, Total Recall only restores the profile located in the \Flash Disk\TotalRecall folder. If you store your profile anywhere else it will not be restored. Psion Omnii Hand-Held Computer User Manual...
Page 126 USB key. The profile will be automatically installed to the computer’s \Flash Disk\TotalRecall folder. There is a short delay in deployment so that you can cancel the process if needed. USB drive prepared for cloning Autorun installation on next Omnii Psion Omnii Hand-Held Computer User Manual...
Page 127: Deleting A Profile
Temp folder—that is, data are always loaded from the FTP Server to the Temp folder and from the Temp folder to the FTP Server. If this option is disabled, a warm reset must be performed to accept the change. Psion Omnii Hand-Held Computer User Manual...
Page 128: Advanced Interface And Network Settings
Advanced Services Settings SNTP (Simple Network Time Protocol) Server The SNTP Server Name typed in this dialog box is used to synchronize Omnii time with the server time. A warm reset must be performed once the server name as been entered.
Page 129: User
4.27.2.1 User Display Settings User Font Size This option allows you to adjust the size of the font used in the Omnii display: Large, Normal, or Small. 4.27.3 TweakIt This option is reserved for senior administrators who have a strong understanding of registry keys and values.
Page 130: Dialing A Number
The + symbol replaces the universal dialing prefix 011. Sending and Ending Calls Using the Omnii Keyboard The 55-key and the 66-key Omnii keyboards come equipped with phone keys—each has a [Talk] and an [End] key on the physical keyboard.
Page 131: Receiving An Incoming Call
Highlight the phone number that is currently On Hold, and choose Retrieve. Tap on Execute. Both calls will be listed as Active in the Call Management list. All calls are now conferenced so that you as well as your callers can speak to one another. Psion Omnii Hand-Held Computer User Manual...
Page 132: 4.28.3.2 Call Lists
Note: Keep in mind that some services may not be supported by your network, or they may not have been subscribed to. • Tap on the service you want to enable. The service dialog boxes allow you to tailor your available services to meet your requirements. Psion Omnii Hand-Held Computer User Manual...
Page 133: File Menu - Phonebook Management
Tap on the Execute button to save the phone number in your Phonebook. Phonebook entries are saved even after you exit Wireless WAN. Once you’ve added a phone number to the Phonebook, a list of new commands is available in the drop- down menu. Psion Omnii Hand-Held Computer User Manual...
Page 134: Volume & Sounds Properties
4.29 Volume & Sounds Properties Omnii supports several audio options, including Bluetooth. The beeper is used for the standard sounds: key clicks, screen taps, and scanning. The optional rear speaker can be used for system (Windows) sounds and .wav files. When a rear speaker is absent, those sounds are routed to the front receiver.
Page 135: Sound Adjustments
4.30 Wi-Fi Config The Wi-Fi Config application is used to configure the Omnii 802.11a/b/g/n radio for one or more wireless network profiles. A network profile contains settings for SSID (Service Set Identifier) and security options. Note: In most situations, the configuration of your 802.11 radio will require parameter setting and access keys from a network administrator.
Page 136: Wi-Fi Config: Configure
If, for example, you are using a different type of security for your network, the fields you complete may not match those described here. Psion Omnii Hand-Held Computer User Manual...
Page 137: 4.30.2.1 Authentication Mode
Note: Each Auth. Mode has a unique Configure Profile screen attached to it with fields appropriate to the authorization mode you’ve chosen. Open Authentication Open authentication does not provide security. When this option is chosen, Omnii will connect to wireless networks which do not use authentication or encryption. WEP (Wired Equivalent Privacy) WEP provides static security to prevent others from accidentally accessing your network.
Page 138: 4.30.2.2 Encryption
Complete the fields in the Configure Profile screen. If you’re uncertain about some of the options, your system administrator will be able to provide the correct information for your wireless network. • Once you’ve completed the necessary fields, tap on OK. Psion Omnii Hand-Held Computer User Manual...
Page 139: 4.30.2.4 Verify Server Certificate
Wi-Fi Config: Configure 4.30.2.4 Verify Server Certificate When the Verify Server Certificate box is checked, Omnii will verify the certificate provided by the authenti- cation server during the authentication process. This requires that an appropriate certificate be manually installed on Omnii for the verification.
Page 140: Configuring Tcp/Ip
Configuring TCP/IP If your network is not using a DHCP server, you will need to assign an IP address. 4.30.3.1 IP Address To assign an IP address for your Omnii: • Tap on the radio icon in the taskbar, Tap on Start>Settings>Network and Dial-up Connections. Tap on the radio icon for which you want to assign an IP address—in the sample screen below, the icon is labelled SDIO86861.
Page 141: 4.30.3.2 Name Server
Figure 4.7 SDIO86861 IP Information Note: When DHCP is enabled, tapping the ‘Renew’ button forces Omnii to renew or find a new IP address. This is useful if, for example, you are out of communication range for a longer period of time and your hand-held is dropped from the network.
Page 142: Wi-Fi Config: Advanced
Values range from 5 to 30 dBm. Concluding the Wi-Fi Configuration If you’ve made changes in the Advanced menus, you will need to warm reset your Omnii. •...
Page 143: Monitoring The Network Connection
Press [ENTER] to display the Wireless Statistics dialog box. Note: Moving in and out of the radio coverage area can have varying effects on a network session. At times, you may need to renew your connection by logging in again. Psion Omnii Hand-Held Computer User Manual...
Page 145 5.5.5.2 Omnii charge indicator LED stays off........145...
Page 146 5.7.2 Insertion and Removal of Omnii ........
Page 147: Chapter 5: Accessories
The pistol grip is attached to the back of Omnii using the four threaded inserts in the upper part of the Omnii casing (see Figure 5.2). Four M3x6 Phillips head screws are provided.
Page 148: Carrying And Protective Accessories
There are several Omnii carrying and protective accessories to help you work safely and comfortably. Attaching Carrying Accessories If your Omnii is not fitted with a hand strap, you can install it using the carrying accessory kit supplied. You’ll need: •...
Page 149: The Hand Strap - Model St6025
Figure 5.3 Attaching the hand strap Clip Hand strap slot 5.2.2 The Shoulder Strap - Model ST6030 Figure 5.4 Model ST6030 features Nylon strap Break-away Velcro Unlocking clip Retaining clip Psion Omnii Hand-Held Computer User Manual...
Page 150 Chapter 5: Accessories The Shoulder Strap - Model ST6030 Installation To lock the shoulder strap in place, insert the retaining clip in the slot at the bottom of the Omnii Hand-Held Computer (Figure 5.5). Figure 5.5 Removal With your thumb, place the unlocking clip tab in the Omnii top slot (Figure 5.6).
Page 151: Protective Carrying Case - Model St6090
5.2.4 Hard Shell Holster - Model ST6055 A hard shell holster that includes a belt, leg tie-down, and tether, can be used to hang Omnii with a pistol grip from your waist. • Feed the belt through the top panel of the holster, and adjust the belt as needed.
Page 152: Snap Modules
Model ST4001 (USB variant): powers and charges the hand-held. It provides communications via USB 1.1/2.0 Host and USB 2.0 Client connectors and provides a DC IN port. When attached to Omnii, it allows ActiveSync or Windows Mobile Device Center connectivity with your PC, and the use of a USB device such as a USB memory key or supported peripheral.
Page 153: Ac Wall Adaptor - Models St1050 And St1050-Ar
(Refer to Figure 5.10). • To remove the charger, press down on the base of the clip arms to release them from the Omnii side rails and slide the adaptor off. •...
Page 154: Vehicle Power Outlet Adaptor - Model St3113
Insert the DC power plug on the Vehicle Power Outlet Adaptor into the DC IN port on the Snap Module. • Insert the Vehicle Power Outlet Adaptor plug into automotive power outlet in your vehicle. Note: Battery charging continues whether the hand-held is switched on or off. Psion Omnii Hand-Held Computer User Manual...
Page 155: Chargers And Docking Stations: General Information
The Desktop Docking Stations operate as both chargers and docking stations. Operating as a charger, both the battery installed in Omnii and a spare battery can be charged. Priority is given to charging the hand-held's battery. See “Desktop Docking Stations - Models ST4002 and ST4003” on page 142.
Page 156: Power Consumption Considerations
ST4003 Desktop Docking Stations Quick Start Guide, PN 8000203). It is critical that it be reviewed for additional information and updates. Omnii can be inserted into two desktop docking stations which are designed to charge the battery installed in the hand-held along with a spare battery pack: Models ST4002 and ST4003.
Page 157 Figure 5.14 Back of ST4003 Desktop Docking Station Locking arm Omnii Connector pins charging bay DC IN port Spare battery charging bay RJ45 Ethernet port Client USB port Host USB port DE9M serial port Psion Omnii Hand-Held Computer User Manual...
Page 158: Charging A Battery Installed In Omnii
The LED on Omnii lights up indicating that the unit has external power and battery charging will begin. It is safe to leave the unit in the desktop docking station while it is not in use—the battery will not be over- charged.
Page 159: Cleaning The Desktop Docking Station
Omnii charge indicator LED stays off. When Omnii is docked into a powered desktop docking station and the Omnii charge indicator LED stays off, there could be a problem with the hand-held or with the docking station. Use a hand-held with a properly functioning charge indicator to isolate the problem.
Page 160: Quad Docking Station - Model No. St4004
DC IN connector RJ45 Ethernet ports The ST4004 Quad Docking Station is designed to accept up to four Omnii hand-held computers. The docking station powers the units and their internal battery charger. The docking station also connects up to four of the hand-held computers to a 10/100 Base-T Ethernet network and allows for Ethernet data transfer.
Page 161: Quad Docking Station Operation
When the battery finishes charging, the LED turns solid green. • To remove Omnii, push down on the release mechanism on the front face of the docking bay. The hand- held will detach from the docking bay release arms and can be pulled up and out.
Page 162: Cleaning The St4004
When Omnii is docked in a powered ST4004 and the hand-held’s charge indicator LED stays off, there may be a problem with Omnii or with the docking station. Make sure a battery is installed in the Omnii, otherwise use an Omnii with a properly functioning charge indicator to isolate the problem.
Page 163: Power Led Does Not Light Up
Omnii Charge Indicator LED is Red If the Omnii charge indicator is red when Omnii is in any of the four bays, the quad dock cannot read the battery, is in charging timeout, or it is not a Psion battery.
Page 164: Vehicle Cradle Mounting Recommendations
Figure 5.20 Front and back of ST1002 with Omnii Mounting holes Release button Power/Communications port Psion also supplies a range of standard mounts for the hand-held vehicle cradles, and the Omnii vehicle cradles are compatible with all of them. 5.7.1 Vehicle Cradle Mounting Recommendations...
Page 165: Insertion And Removal Of Omnii
• Slide Omnii into the cradle, and press firmly downward until it locks into place. On a vehicle, it’s a good idea to pull up on Omnii to be certain that it is secure.
Page 166: Maintaining The Vehicle Cradle
Two latches in the cradle hold Omnii firmly in place. Although these latches are designed for at least 100,000 insertion and removal cycles, they will wear over time and will no longer lock Omnii securely in the cradle. For replacement parts and instructions contact Psion. Partial disassembly is required.
Page 167: Wiring Guidelines
For a diagram of a power with communications setup, see “Connecting ST1002 to vehicle power and com- munications in a typical setup” on page 155. The Omnii charging LED (see “Battery Charge Status LED” on page 29) indicates that external power is available, and it also indicates the charging status of the internal battery.
Page 168: Extreme Wet Environments
Keep in mind that Omnii will continue to operate with or without vehicle power as long as its battery has sufficient charge. If an unfused power source must be used, a fuse assembly (PN 19440-300) must be added to the extension power cable (the fuse and instructions are supplied with the cable).
Page 169 Note: The serial port is 5 VDC, 1 A maximum power out and is defaulted to off. To enable power to this port, in your Omnii desktop, go to Control Panel>Scanners, which opens the Scanner Settings menus. In the Ports menu, select ON for the Power parameter under the COM6 port.
Page 170: Battery Charger (6-Slot) - Model St3006
Battery Charger (6-Slot) - Model ST3006 Battery Charger (6-Slot) - Model ST3006 The ST3006 is designed to charge up to six Omnii lithium-ion batteries at one time. Important: The battery charger is shipped with its own quick start guide—ST3006 6-Slot Battery Charger Quick Start Guide (PN 8000204).
Page 171: Operator Controls
All charge indicators flash momentarily at power up to indicate that the charger is ready for operation. If you choose to wall mount the charger, detailed installation instructions are included in the Omnii 6-Slot Battery Charger ST3006 Quick Start Guide (PN 8000204) included with the charger kit. Be sure to locate the charger in an area where there is no risk of injury to persons walking in the vicinity.
Page 172: Power Self-Test Leds Don't Light Up
Inspect the charge slot contacts for damage (are they bent, flattened, twisted or broken). • Try inserting a battery that you know to be working in the charger slot. • Reconnect the mains power cable, and check that the slot indicator flashes at power up. Psion Omnii Hand-Held Computer User Manual...
Page 173 A.1 Omnii Docking Connector ........
Page 175: Appendix A: Port Pinouts
Appendix A: Port Pinouts Omnii Docking Connector Omnii Docking Connector The docking interface on the base of Omnii is custom-designed to dock with a device via an array of spring- mounted pins. The following are the pin assignments of the interface.
Page 176: Snap Modules Connectors
Snap Modules Connectors Pinout ST4001 ST4005 USB Micro B Connector USB Type A Connector DE9M Serial Connector Pin # Signal Pin # Signal Pin # Signal VBus VBus GROUND GROUND SHIELD GROUND SHIELD 5Vdc 1A power out Psion Omnii Hand-Held Computer User Manual...
Page 177: Cable Connectors For Vehicle Cradle Model St1002
USB Type A Power Pin # Signal Pin # Signal Pin # Signal VBus VIN (11.5 to 30Vdc) GND (not chassis ground) MOTION DETECT DGROUND MOTION DETECT RETURN (not ground) GROUND 5Vdc 1A power out Psion Omnii Hand-Held Computer User Manual...
Page 178: Omnii Battery Contacts
Plastic Rip - provides mechanical polarity. BATT+ Positive lead of battery. BATT-CLK SMBus data clock. BATT-ID Connected to GND in the battery. BATT-DATA SMBus bi-directional data line. Negative lead of battery. Negative lead of battery. Psion Omnii Hand-Held Computer User Manual...
Page 179 The Omnii Hand-Held Computer (Model 7545) ........
Page 181: Appendix B: Omnii Specifications
Appendix B: Omnii Specifications The Omnii Hand-Held Computer (Model 7545) The Omnii Hand-Held Computer (Model 7545) Note: Performance specifications are nominal and subject to change without notice. B.1.1 Hardware Physical Dimensions • Overall: 100 mm width x 44 mm depth x 222 mm length (3.9 in x 1.7 in x 8.7 in).
Page 182: Regulatory Approvals
Rain And Dust Resistance: IEC 60529, classification IP67. B.1.2 Regulatory Approvals • Woldwide Safety, EMC, RF, Laser approvals • CE Mark • E Mark (vehicle cradles) • RoHS compliant • WEEE compliant • REACH compliant Psion Omnii Hand-Held Computer User Manual...
Page 183: Lithium-Ion Smart Battery 5000 Mah (St3001
Appendix B: Omnii Specifications Lithium-ion Smart Battery 5000 mAh (ST3001) Lithium-ion Smart Battery 5000 mAh (ST3001) For safety instructions, please see “Lithium-ion Battery Safety Precautions” in the Omnii Hand-Held Com- puter Regulatory & Warranty Guide (PN 8000191). Parameter Specification Model Number...
Page 184: Wireless Radios
Noise reduction Interfaces Hirose U.FL-R-SMT 50 ohm antenna connector Antenna solder pad Molex 80-pin board-to-board connector: Power supply Audio: 2x analog, 1x digital Serial interface (ITU-T V.24 protocol) SIM card interface 3 V, 1.8 V Psion Omnii Hand-Held Computer User Manual...
Page 185: 802.11A/B/G/N Radio
802.11n 6.5,13,19.5,26,39,52,58.5,65 Mbps 802.11b 32% max 802.11g -26 dB max 802.11a -26 dB max 802.11n (2.4 GHz) -29 dB max 802.11n (5 GHz) -29 dB max Bluetooth TI Wilink6 proprietary WiFi-BT co-existent scheme. Coexistence Psion Omnii Hand-Held Computer User Manual...
Page 186: Bluetooth Radio
2.400-2.4835 GHz Channels RX Sensitivity -90 dBm typical, -70 dBm max Data Rates V1.2=732.2 kbps and 57.6 kbps asymmetric, 433.9 kbps symmetric V2.0=2 & 3 Mbps 802.11 Coexistence TI Wilink6 proprietary WiFi-BT co-existent scheme. Psion Omnii Hand-Held Computer User Manual...
Page 187 C.4.2 Color Camera Barcode Symbologies ........C-18 Psion Omnii Hand-Held Computer User Manual...
Page 189: Appendix C: Imager & Camera Settings
In order to configure imaging, the Manage Triggers applet must be present in the Control Panel, along with the Imagers applet. Note: The Imagers icon is only displayed when the appropriate imager is installed in your Omnii. If there is an imager installed but this icon is not present, additional software (ICS) may need to be installed.
Page 190: Barcode Decoding Symbology Predefined Presets
The following presets enable successful image capture in almost all conditions. Note: It is recommended that the default preset be used whenever possible. Default This preset works in a wide range of conditions. It is optimized for a normal office lighting (about 300 Lux). Psion Omnii Hand-Held Computer User Manual...
Page 191: Using The Imagers Applet
Choose a camera—specifically, Front Imager which is located at the top of the unit. C.3.1.2 Setting the Active Preset An active preset has an A to the right. To set an active preset: • Highlight the preset, and tap on the Activate button. Psion Omnii Hand-Held Computer User Manual...
Page 192: Viewing A Preset
To ensure that it will work reliably, it should be as close as possible to the original predefined preset. To change a parameter value: • Highlight the custom preset, and double-tap on the Edit button. Psion Omnii Hand-Held Computer User Manual...
Page 193: Removing A Custom Preset
Tap on Yes to remove the preset or No to cancel the operation. C.3.2 Configuring the Barcode Decoding Camera Presets (Barcoding Menu) To configure the barcode decoding camera presets: • Tap on Start>Settings>Control Panel>Imagers. • Tap on the Barcoding tab. Psion Omnii Hand-Held Computer User Manual...
Page 194: Selecting A Camera
Highlight the preset, and tap on the Activate button. C.3.2.3 Viewing a Preset To view the parameter settings in a preset: • Highlight a preset, and double-tap on the View button. The associated preset window is displayed. Psion Omnii Hand-Held Computer User Manual...
Page 195: Creating A Custom Preset
To ensure that it will work reliably, it should be as close as possible to the original predefined preset. To change a parameter value: • Highlight the custom preset, and double-tap on the Edit button. Psion Omnii Hand-Held Computer User Manual...
Page 196: Removing A Custom Preset
Tap on Yes to remove the preset or No to cancel the operation. C.3.3 Configuring the Barcode Decoding Symbologies (Barcoding Menu) To configure the barcode decoding camera presets: • Tap on Start>Settings>Control Panel>Imagers. • Tap on the Barcoding tab. C-10 Psion Omnii Hand-Held Computer User Manual...
Page 197: Setting The Active Preset
A new custom preset is created by modifying a preset—either a predefined preset or an existing custom preset. To create a custom preset: • Highlight a preset, and tap on the Add button. A screen like the sample following is displayed. C-11 Psion Omnii Hand-Held Computer User Manual...
Page 198: Modifying A Custom Preset
When you’ve completed your edits, tap on OK. The parameter list is displayed; the new value for the changed parameter is shown. • Tap on OK to exit to the preset list and save the changes. C-12 Psion Omnii Hand-Held Computer User Manual...
Page 199: Removing A Custom Preset
- Highlight the parameter, and then press the [SPACE] key or double-click the parameter. - An associated dialog box containing the valid range of values for the parameter and the current setting like the sample screen following is displayed. C-13 Psion Omnii Hand-Held Computer User Manual...
Page 200: Translation Menu - Configuring Rules
• Tap on Start>Settings>Control Panel. • Tap on the Imagers icon, and then tap on the Translations tab. For instructions on adding, editing, and removing translation rules, refer to “Translations” on page 99. C-14 Psion Omnii Hand-Held Computer User Manual...
Page 201: Advanced Menu
C.3.7.2 Configuring Triggers Viewing the Trigger Configuration The trigger on Omnii is configured using the Manage Triggers applet. The Imagers applet provides a short- cut to the Manage Triggers applet. • In the Advanced tab, tap on the Trigger Control button.
Page 202: Barcode Symbologies
In the Camera Presets: drop-down menu at the top of the Imager & Camera Settings screen, choose Imager or Color Camera depending on which set of barcodes you want to work with. • Go to the Barcode Presets. C-16 Psion Omnii Hand-Held Computer User Manual...
Page 203: Imager Barcode Symbologies
The barcode symbologies for the Imager are listed in this section. Table C.1 Imager Barcode Symbologies All 1D With Strong Recovery Enabled Code 39 Code 128 EAN 13 EAN 8 UPC-E UPC-A UPC/EAN Sharing Settings Code 93 (disabled) MSI Plessey (disabled) C-17 Psion Omnii Hand-Held Computer User Manual...
Page 204: Color Camera Barcode Symbologies
Table C.2 Color Camera Barcode Symbologies All 1D With Strong Recovery Enabled Code 39 Code 128 EAN 13 EAN 8 UPC-E UPC-A Code 93 (disabled) Codabar Interleaved 2 of 5 (disabled) Gs1 DataBar (disabled) C-18 Psion Omnii Hand-Held Computer User Manual...
Page 205 2D QR Code 2D Maxicode (disabled) 2D Aztec (disabled) Postal: PlanNET (disabled) Postal: PostNET (disabled) Postal: Australia (disabled) Postal: Canadian (disabled) Postal: Japanese (disabled) Postal: Kix (disabled) Postal: Korean (disabled) Postal: Royal (disabled) C-19 Psion Omnii Hand-Held Computer User Manual...
Page 207 D.5.1 Options ............10 Psion Omnii Hand-Held Computer User Manual...
Page 209: Appendix D: Scanner Settings
Note: Your Omnii comes preconfigured from the factory for internal scanner types. The type of scanner installed can be determined from the System icon in the Control Panel, under the System Properties tab.
Page 210: Decoded (Internal) Scanners
Press and hold on the parameter you want to reset. • Choose Default parameter to reset the parameter to the default setting. Decoded (Internal) Scanners • Tap on the Scanner drop-down menu, and choose Decoded (internal). Psion Omnii Hand-Held Computer User Manual...
Page 211: Options
When you double-tap on this parameter, a dialog box is displayed in which you can choose a value of 30 sec., 1 min., 2 min. or 3 min. Note: This parameter is only used if the Trigger Mode has been set to Continuous On and Omnii is mounted in a fixed position; otherwise, ‘Low Power Timeout’ is not used.
Page 212: Decoded (Internal) Data Options
A prefix and/or one or two suffixes may be appended to scan data for use in data editing. When you double- tap on these parameters, dialog boxes are displayed in which you can enter a value from 0 to 255. Psion Omnii Hand-Held Computer User Manual...
Page 213: Decoded (Hhp
Tap on the Scanner drop-down menu, and choose Decoded (Intermec ISCP). D.4.1 Decoded (ISCP) Options Laser On Time The value assigned to this parameter determines how long the laser will remain on when the scan button or trigger is pressed. Psion Omnii Hand-Held Computer User Manual...
Page 214: Decoded (Iscp) Advanced Options
Add AIM ID Prefix The AIM ID (Association for Automatic Identification and Mobility) is an international barcode identifier. When this parameter is enabled, the AIM ID is inserted at the beginning of the decoded barcode. Psion Omnii Hand-Held Computer User Manual...
Page 215: Non-Decoded Scanners
Use the [UP] and [DOWN] arrow keys to highlight a parameter. • To change a parameter value, press [SPACE] or the [RIGHT] arrow key. If a field requires text entry, a text box is displayed in which you can enter the appropriate value. Psion Omnii Hand-Held Computer User Manual...
Page 216: Options
Code 93 (disabled) Code 128 Code 11 (disabled) EAN 13 Interleaved 2 of 5 (disabled) EAN 8 MSI Plessey (disabled) UPC-A Discrete 2 of 5 (disabled) UPC-E IATA 2 of 5 (disabled) Codabar (disabled) D-10 Psion Omnii Hand-Held Computer User Manual...
Page 217 E.8.1 HHP 5080 Working Range ..........E-10 Psion Omnii Hand-Held Computer User Manual...
Page 219: Appendix E: Internal Imager & Scanner Specifications
Appendix E: Internal Imager & Scanner Specifications SE955 Scanner This appendix lists specifications for the following internal scanners. For a current list of model numbers and descriptions for Omnii scanner pod and back cover kits, please contact your Psion representative or go to http://www.psion.com/us/products/handheld.htm. SE955 Scanner...
Page 220: Se1223Lr - Long Range (Decoded) Scanner
Table E.1 4,844 Lux to 86,112 Lux Maximum Minimum Range Width of Field Width of Field Range Inches Inches Inches Inches Mil Size 70 reflective 100 reflective High quality symbols in normal room light. Psion Omnii Hand-Held Computer User Manual...
Page 221: Se1224Hp - High Performance Scanner
Laser On Time, Aim Duration, Power Mode, Trigger Mode, Bi-directional Redundancy, Symbology types/lengths, Data formatting. Ambient Light Artificial: 450 ft. candles (4844 Lux). Sunlight: 8000 ft. candles (86112 Lux). Laser Output Power (peak) 1.35 mW E.3.1 SE1224HP Decode Zones Psion Omnii Hand-Held Computer User Manual...
Page 222: Se1524Er - Extended Range Scanner
Redundancy, Symbology types/lengths, Data formatting. Ambient Light Artificial: 450 ft. candles (4,844 Lux) Sunlight: 4,000 ft. candles (86,112 Lux). Laser Output Power (peak) 1.26 mW E.4.1 SE1524ER Decode Zones SE1524ER Decode Zone A (Short Range, Small Codes) Psion Omnii Hand-Held Computer User Manual...
Page 223: Ev15 Imager
Works in any lighting conditions, from 0 to 100,000 lux E.5.1 EV15 Imager Decode Zone 0 Lux to 100,000 Lux Minimum Range Maximum Range Inches Inches Mil Size 14.5 35.5 High quality symbols in normal room light. Psion Omnii Hand-Held Computer User Manual...
Page 224: Ea11 Decoded 2D Imager
Operating Current 170mA - 310mA (lighting condition dependent) Power Saving Mode Ambient Light Works in any lighting conditions, from 0 to 100,000 lux Regulatory Approvals UL, VDE certified, RoHS compliant E.6.1 EA11 Typical Reading Distances Psion Omnii Hand-Held Computer User Manual...
Page 225: Ea20X Imager
Operating Current 410mA @ 3.3V scanning with power save Power Saving Mode Ambient Light From 0 to 100,000 lux Regulatory Approvals UL, cUL, VDE certified, RoHS compliant, Class 2 Laser E.7.1 EA20X Typical Reading Distances Psion Omnii Hand-Held Computer User Manual...
Page 226: Hhp 5080 Imager/Decoder
12.5 (.021cm) 3.4 in. (8.6cm) 5.7 in. (14.5cm) 8.3 (.021cm) 3.4 in. (8.6cm) 5.4 in. (13.7cm) Linear 10 Linear 2.2 in. (5.6cm) 7.6 in. (19.3cm) 13 (.033cm) 2.0 in. (5.1cm) 8.9 in. (22.6cm) E-10 Psion Omnii Hand-Held Computer User Manual...
Page 227 F.2 Power Mode ............F-13 Psion Omnii Hand-Held Computer User Manual...
Page 229: Appendix F: Wireless Wide Area Network (Wwan) Settings
Wireless WAN Wireless WAN Psion offers the MC75i GSM/GPRS/EDGE radio. An Omnii Hand-Held Computer equipped with a GSM/GPRS radio has wide area networking capabilities. With this radio and a SIM card, you can wirelessly transfer data, and you use the Omnii voice option to place phone calls.
Page 230: Disconnecting From A Network
Note: Once you’ve shut down the user interface, you can only enable the radio by opening the Con- trol Panel and tapping on the Wireless WAN icon to display the Wireless WAN dialog box. Psion Omnii Hand-Held Computer User Manual...
Page 231: Advanced Information
The modem did not respond to commands as expected. If a warm boot does not clear this condition, the modem may need to be replaced. • NDIS error. An internal software error has occurred. If a warm boot does not clear this condition, Psion technical support may need to investigate further. Psion Omnii Hand-Held Computer User Manual...
Page 232: Tools Menu
Wireless WAN user interface (e.g. Connection Manager) are expected to open and close connections. If the automatic connection mode is enabled and another application closes the GPRS connection, the WWAN user interface will immediately try to re-establish the connection. Psion Omnii Hand-Held Computer User Manual...
Page 233 The selected profile is deleted. You cannot delete the Default profile. Activate When this button is chosen, the selected profile becomes the active profile. Activation is possible only if the Enable automatic configuration: checkbox is unchecked. Psion Omnii Hand-Held Computer User Manual...
Page 234 The Advanced IP button in the Show Profile and Edit Profile dialog boxes opens another dialog box that allows you to configure a static IP address as well providing DNS and WINS fields so that you can specify DNS and WINS resolvers. Psion Omnii Hand-Held Computer User Manual...
Page 235: Security Configuration
For every network that is found, the network name, country, status and numeric network identifier (MCC/MNC, Mobile Country Code followed by the Mobile Network Code) is displayed. Psion Omnii Hand-Held Computer User Manual...
Page 236: Driver Mode Configuration
GSM modem connected to a serial port of the compu- ter through USB or through Bluetooth. An external modem connected to a serial port must support 115.2 kbit/s, 8bit, no parity and hardware flow control. F-10 Psion Omnii Hand-Held Computer User Manual...
Page 237: Modem Information
If the main menu shows an error status, at least partial modem information may be available. F.1.4.6 User Interface Taskbar Choosing Taskbar displays a dialog box in which you can determine which Wireless WAN icons will be dis- played in the taskbar. F-11 Psion Omnii Hand-Held Computer User Manual...
Page 238: Sms Menu
Appendix F: Wireless Wide Area Network (WWAN) Settings SMS Menu Sounds Tapping on the Sounds option displays a dialog box in which you can customize which sounds your Omnii will emit and when these sounds will be played. F.1.5 SMS Menu SMS (Short Message Service) functions are accessed through the SMS menu.
Page 239: Outbox
Wireless WAN driver). If the checkbox is checked, power is applied to the modem and the drivers are loaded when the computer is turned on. Power is removed from the modem when the computer enters suspend mode. F-13 Psion Omnii Hand-Held Computer User Manual...
Page 241 G.3.3 Changing Network Properties ......... . . G-7 Psion Omnii Hand-Held Computer User Manual...
Page 243: Appendix G: Wireless Zero Config Settings
When you choose the Wireless LAN icon, an 802.11 Wireless LAN Settings window is displayed. This tab lists your radio statistics. Choosing the Zero button resets the statistics of the last four items—Packets IN, Packets OUT, IN errors and OUT errors. Psion Omnii Hand-Held Computer User Manual...
Page 244: Wireless Information
Since access points are generally secure, they will most likely not be listed here. By default, Omnii attempts to connect to preferred networks. This behaviour can be changed by enabling Automatically connect to non-preferred networks in the Advanced dialog box (see Figure G.9).
Page 245 Network name field can contain a maximum of 32 characters. The name assigned here is listed as a preferred network. Important: Keep in mind that Omnii will only communicate with access points that are config- ured with the same SSID.
Page 246: Assigning An Ip Address
If your network is not using a DHCP server, you will need to assign an IP address. Refer to “IP Address” on page 126 for details about assigning an IP address. G.2.1 Name Server Refer to “Name Server” on page 127 for details about this option. Psion Omnii Hand-Held Computer User Manual...
Page 247: Advanced Features
Rearranging Preferred Networks Omnii attempts to connect with the networks listed in this dialog box in sequence, beginning at the top of the list. If you need to rearrange this list of networks—move networks up and down in the list: •...
Page 249: Index
141 viewing 111 operation 144 backups, managing profiles 111 operator controls 141 Bad Scan Vibrates 99 safety instructions 141 barcode Snap Modules 138 appending to 98 ST4004 operator controls 147 Psion Omnii Hand-Held Computer User Manual...
Page 250 Identifier, Default preset group (imaging software) B-3 cleaning 145 imager indicators 144 EV15 specifications D-7 operation 144 HHP 5080 specifications D-10 operator controls 141 two dimensional (2D) imager 34 troubleshooting 145 Imager & Camera settings 73 Psion Omnii Hand-Held Computer User Manual...
Page 251 Predefined preset B-4 onscreen keyboard, Soft Input Panel (SIP) 53, 74 Linear Security Level C-6 Open TekTerm application 85 Lithium-ion batteries operating system properties 108 installing 14 removing 14 Lock Sequence 81 Low light Psion Omnii Hand-Held Computer User Manual...
Page 252 Predefined B-3 Click Data (appending data) 98 Preset Group, Default identifier (imaging software) B-3 Click Time (double-click) 98 Profile Codepage 99 restoring backup 111 Continuous Scan Mode C-8 viewing backup 111 decoded C-9 Programs Psion Omnii Hand-Held Computer User Manual...
Page 253 Shell Settings (PsionVU settings) 92 modifier keys 30 SHIFT Key 23 using 36 Short Code C-10 task manager 40 Shutdown TCP/IP, configuring 126–127 Suspend 41 themes, desktop 93 Shutdown (Start Menu) 41 Total Recall Psion Omnii Hand-Held Computer User Manual...
Page 254 Windows 7 66 Windows Embedded CE, navigating in 34 Windows Explorer 38 Windows Mobile Device Center, setting up 67 Windows Vista® 66 Wireless WAN F-3–F-13 Use Virtual Serial Port F-7 Voice F-13 Wireless Zero Config G-1–G-7 Psion Omnii Hand-Held Computer User Manual...

Psion OMNII User Manual

Chapter 1: Introduction

Chapter 2: Basic Operation

Chapter 3: Getting to Know Your Omnii

Chapter 4: Configuration

Chapter 5: Accessories

Appendix: Port Pinouts

Appendix A: Port Pinouts

Appendix: Omnii

Appendix B: Omnii Specifications

Appendix C: Imager & Camera Settings

Appendix: Imager &

Appendix: Scanner

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Psion OMNII

Summary of Contents for Psion OMNII
