SERVICE MANUAL
CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section
on page 2 of this manual.
DVD and CD
PLAYER
CONTENTS
SERVICE PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 2,3
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ELECTRICAL TROUBLE SHOOTING GUIDE. . . . . . . . . . 5,15
PRINTED CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16,21
REPLACEMENT PARTS LIST . . . . . . . . . . . . . . . . . . . . . . 22,27
MODEL
DVD-2610
