SERVI C E MANUAL MODEL DVD5860 CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section on page 2 of this manual. CONTENTS DVD and CD SERVICE PRECAUTIONS............2,3 BLOCK DIAGRAMS..............4 TROUBLE SHOOTING............5,8 PLAYER BOARD DIAGRAM...............9,10...
LASER BEAM CAUTION LABEL When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of laser may be received. PREPARATION OF SERVICING Pickup Head consists of a laser diode that is very susceptible to external static electrocity. Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement, its life might be shortened.
SAFTY NOTICE SAFTY PRECAUTIONS LEAKAGE CURRENT CHECK Plug the AC line cord directly into a 120V AC outlet (do Measure the AC voltage across the 1500 resistor. not use an isolation transformer for this check). Use an The test must be conducted with the AC switch on and AC voltmeter, having 5000 per volt or more sensitivity.
Page 4
OVERALL BLOCK DIAGRAM 27MHz TFT CONT TRANSFORMER TFT MONITOR (MN5814) 8M FlashROM 64M SDRAM TC4W53 74HCU04 TFT POWER MX29LV008TTC-70 NT56V6620C0T-75S +5V +7.5V -16V +13V 27MHz SERVO & DVD PROCESSOR VIDEO PROCESSOR (AN2546FH) KHM252 MPEG-2 DECODER VIDEO OUT RF AMP VIDEO DRIVER D2891 &...
1. Troubleshooting 1. No power when turned on. 2. The initial screen is not displayed on the LCD. 3. The DVD drive does not work. 4. The operation of the DVD player stops at initializing display. 5. Image output stops during the operation. 6.
Page 6
1.2 The initial screen is not displayed on the LCD. If the initial screen is not displayed on the LCD, check the following items. (1) Check the LED on the front If the LED does not light, proceed to 1.1. (2) Check the backlight If the backlight does not light up, separate.
Page 7
1.3 The DVD drive does not work. When the DVD drive does not work after the power is turned on, check the following items and repair or replace the defective parts. (1) Press the DISC cover switch at the center of the DVD player and turn on the power.
Page 8
1.5 Image output stops during the operation. If the image output form the media in the DVD player stops during the operation, replace the DVD drive. 1.6 No sound or abnormal sound comes out from the speakers in the DVD player. If no sound comes out form the speakers in the DVD player, check the following: (1) Check for moving images on the LCD screen Check whether or not the move of image stops in halfway.
ELECTRICAL PARTS LIST PART No. PART NAME Q'TY DVD5860 21116 LI-IONCHP-2 ASS'Y 21154 DVD5860 HV ASS'Y 21184 DVD5860 KEY A ASS'Y 21209 DVD5860 TFT ASS'Y 21220 CDQ-5A ASS'Y 21244 DVD5861 MAIN B ASS'Y S7401 DVD5860 KEY B ASS'Y S2706a ICR18650 (2200)
Page 12
REF No. PART No. PART NAME REF No. PART No. PART NAME DVD5860 MAIN PCB ASS'Y R127 P11018 Resistor chip 47K Ω RESISTOR R129 P11000 Resistor chip 0 Ω P11038 Resistor chip 39K R130 P11013 Resistor chip 10K Ω Ω...
Page 13
REF No. PART No. PART NAME REF No. PART No. PART NAME R419 P11207 Resistor chip 0.5 R488 P11003 Resistor chip 10 Ω Ω R421 P11207 Resistor chip 0.5 R489 P11004 Resistor chip 33 Ω Ω R425 P11015 Resistor chip 15K R490 P11004 Resistor chip 33 Ω...
Page 14
REF No. PART No. PART NAME REF No. PART No. PART NAME R543 P11019 Resistor chip 100K C110 P31088 Electrolytic CAP 220uF/6V Ω R544 P11055 Resistor chip 8.2K C112 P31002 Electrolytic CAP 10uF/16V(Ta) Ω R545 P11019 Resistor chip 100K C113 P20015 Capacitor chip 0.1uF Ω...
Page 15
REF No. PART No. PART NAME REF No. PART No. PART NAME C302 P20002 Capacitor chip 22pF C443 P31088 Electrolytic CAP 220uF/6V C304 P20002 Capacitor chip 22pF C444 P31002 Electrolytic CAP 10uF/16V(Ta) C307 P20002 Capacitor chip 22pF C445 P20012 Capacitor chip 0.01uF C308 P20002 Capacitor chip 22pF C446...
Page 16
REF No. PART No. PART NAME REF No. PART No. PART NAME C511 a3690 Electrolytic CAP 220uF/10V P20015 Capacitor chip 0.1uF C512 P31002 Electrolytic CAP 10uF/16V(Ta) P20015 Capacitor chip 0.1uF C513 P31002 Electrolytic CAP 10uF/16V(Ta) P20015 Capacitor chip 0.1uF C514 P31002 Electrolytic CAP 10uF/16V(Ta) P20015 Capacitor chip 0.1uF C515...
Page 17
REF No. PART No. PART NAME REF No. PART No. PART NAME CB36 P20015 Capacitor chip 0.1uF EM407 P60006 FK2125T186AL CB38 P20015 Capacitor chip 0.1uF EM503 P60006 FK2125T186AL CB39 P20015 Capacitor chip 0.1uF EM504 P60006 FK2125T186AL CB40 P20015 Capacitor chip 0.1uF EM506 P60006 FK2125T186AL CB41...
Page 18
REF No. PART No. PART NAME REF No. PART No. PART NAME P5722 RB060L-40 VD509 P5073a 2SD601AR P5722 RB060L-40 VD510 P5073a 2SD601AR P5073a 2SD601AR VD520 P5073a 2SD601AR P5073a 2SD601AR VD521 P1200 1SS355TE Switch Diode P5702 XN4601 VD522 P1200 1SS355TE Switch Diode P5702 XN4601 VD523...
Page 20
REF No. PART No. PART NAME REF No. PART No. PART NAME P11017 Resistor chip 33K P30002 Electrolytic CAP 47uF/6V Ω P11018 Resistor chip 47K P20084 Capacitor chip 0.15uF Ω P11040 Resistor chip 68K P20015 Capacitor chip 0.1uF Ω P11029 Resistor chip 2.2K P20035 Capacitor chip 1uF Ω...
Page 21
REF No. PART No. PART NAME REF No. PART No. PART NAME P31002 Electrolytic CAP 10uF/16V(Ta) P6659 Impedance at 100MHz:600 Ω P30010 Electrolytic CAP 10uF/16V(Al) P60004 100uH TRANSISTOR P30010 Electrolytic CAP 10uF/16V(Al) P30010 Electrolytic CAP 10uF/16V(Al) P90072 BA033FP P20085 Capacitor chip 2.2uF P5709 DTC124EUAT106 P30010 Electrolytic CAP 10uF/16V(Al)
