GAI-Tronics 13352 Installation And Operation Manual

Addressable amplified speakers
Table of Contents

Advertisement

Foreword .........................................................................................................................................3
Scope of Manual...................................................................................................................................... 3
Nomenclature .......................................................................................................................................... 3
Ordering Replacement Parts ................................................................................................................. 3
Service and Repair .................................................................................................................................. 3
Confidentiality Notice ............................................................................................................................. 4
FCC Licensing Information ................................................................................................................... 4
Computer Software Copyrights............................................................................................................. 5
Warranty ................................................................................................................................................. 5
Safety and General Information............................................................................................................ 6
User Instructions...............................................................................................................................................6
Exposure to Radio Frequency Energy..............................................................................................................6
Antenna Care....................................................................................................................................................6
Electromagnetic Interference/Compatibility.....................................................................................................6
Hospitals or Health Care Facilities...................................................................................................................6
Medical Devices - Pacemakers.........................................................................................................................6
Blasting Caps and Areas...................................................................................................................................6
Safe Handling of CMOS Integrated Circuit Devices ........................................................................... 7
Replacement Parts and Kits................................................................................................................... 8
Programming Software and Cable........................................................................................................ 8
Performance Specifications.................................................................................................................... 9
Introduction...................................................................................................................................11
Functional Description.................................................................................................................12
Generic Operation................................................................................................................................. 12
Selective Operation ............................................................................................................................... 12
DTMF Signaling.................................................................................................................................................12
2-Tone Signaling ................................................................................................................................................13
Volume Adjustments............................................................................................................................. 13
GAI-Tronics Corporation P.O. Box 1060, Reading, PA 19607-1060 USA
610-777-1374
V
ISIT WWW
A H U B B E L L C O M P A N Y

Table of Contents

800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
Fax: 610-796-5954
Pub. 43004-030A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 13352 and is the answer not in the manual?

Questions and answers

Summary of Contents for GAI-Tronics 13352

  • Page 1: Table Of Contents

    Introduction...........................11 Functional Description.........................12 Generic Operation..........................12 Selective Operation ..........................12 DTMF Signaling..............................12 2-Tone Signaling ..............................13 Volume Adjustments..........................13 GAI-Tronics Corporation P.O. Box 1060, Reading, PA 19607-1060 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
  • Page 2 Fuses ...................................28 LEDs ...................................28 TB1 Wiring Connector ............................29 Radio Connector Pinout............................30 Terminal Strip Designations ..........................31 Definitions and Acronyms ......................32 GAI-Tronics Corporation P.O. Box 1060, Reading, PA 19607-1060 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
  • Page 3: Gai-Tronics Corporation

    This manual offers descriptive data and service information for the Addressable Amplified Speaker Assemblies. Nomenclature The model number, located on the nameplate on the bottom, specifically identifies GAI-Tronics equipment. If additional options are ordered, the option will be identified on the circuit board. Ordering Replacement Parts When ordering replacement parts or requesting equipment information, please include the complete identification number.
  • Page 4: Confidentiality Notice

    GAI-Tronics retains all intellectual property and other rights in or to the information contained herein, and such information may only be used in connection with the operation of your GAI-Tronics product or system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
  • Page 5: Computer Software Copyrights

    If the services fail to meet the applicable industry standard, GAI-Tronics will, for a period of one (1) year from the date of completion, re-perform such services at no cost to the Buyer. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall GAI-Tronics’...
  • Page 6: Safety And General Information

    6 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Safety and General Information User Instructions This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 7: Safe Handling Of Cmos Integrated Circuit Devices

    7 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Safe Handling of CMOS Integrated Circuit Devices Many of the integrated circuit devices used in communications equipment are of the Complementary Metal Oxide Semiconductor (CMOS) type. Because of their high open circuit impedance, CMOS integrated circuits are vulnerable to damage from static charges.
  • Page 8: Replacement Parts And Kits

    8 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Replacement Parts and Kits Part No. Description 13352 13362 13372 12544-003 Wiring Harness, Weatherproof Amplified Speaker 12544-006 Wiring Harness, 600-ohm 13327-021 Speaker 19101-022 VHF Radio...
  • Page 9: Performance Specifications

    Vertical............................Upward: 40º Downward: 60º Horizontal ..............................90º Model 13352 audio input level ..................20 to 1500 mVrms Audio speaker volume adjustment................... 80-116 dB spl Audio speaker volume ..........Factory set @ nominal 89 dB spl at a distance of 1 meter Frequency response....................
  • Page 10 10 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A RF Module (Models 13362 /13372 only) General Frequency range......................VHF: 154-174 MHz UHF: 450-470 MHz Antenna impedance..........................50 Ω Operating voltage....................9-18 V dc, 12 V dc nominal Decoder ..........................
  • Page 11: Introduction

    11 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Introduction The GAI-Tronics Model 13352, 13362 and 13372 Addressable Amplified Speaker Assemblies are designed for remote paging in temporary or permanent applications such as public gatherings, construction sites, or amusement parks.
  • Page 12: Functional Description

    “DTMF” or “2-Tone” must be selected via the CARD Suite programming software. While in the “off” state, the speaker assembly detects the presence of a page closure (Model 13352) or carrier-detect (Models 13362/13372) and becomes activated. The speaker assembly waits for the preprogrammed code to enable the speaker amplifier.
  • Page 13: 2-Tone Signaling

    13 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A 2-Tone Signaling In this operating mode, the speaker assembly detects preprogrammed 2-Tone signaling codes. The 2- Tone protocol is one frequency followed by a second frequency, and is programmed via the CARD Suite software application.
  • Page 14: Field Installed Options

    This option provides a complete solar charging system when purchased with the GAI-Tronics Model RFP7784-108 Solar Panel. Refer to Publication 43003-039 for solar panel installation details. This kit must be used in conjunction with the XB001 External Long-Life Battery Kit and the 40201-008 18 Ah battery.
  • Page 15: Model 40404-048 External Power Supply

    15 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Model 40404-048 External Power Supply 1. The 40404-048 Power Supply can be mounted indoors at a convenient location, such as a telephone/electrical room, or local to the RF Call Box. Outdoor installations require a customer-provided weatherproof enclosure.
  • Page 16: Model Bb133 Battery Back-Up Kit

    16 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Model BB133 Battery Back-up Kit The Model BB133 Battery Back-up Kit provides up to 2.5 hours of continuous output (full power) if main power is lost or disconnected. The kit includes an easily-installed battery bracket, Model 40201-010 2.8 Ah battery, and a single mounting screw.
  • Page 17: Operation

    17 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Operation Use Cases Generic Broadcast Activation Step Action Response Page closure (Model 13352) or Speaker assembly activates and waits for audio signal. carrier-detect (Model 13362/ 13372) is detected.
  • Page 18: Remote Volume Adjustment (Dtmf Only)

    18 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Remote Volume Adjustment (DTMF only) Step Action Response Page closure (Model 13352) or The speaker assembly activates and waits for correct Page ID. carrier-detect (Model 13362/ 13372) is detected.
  • Page 19: Installation

    Programming General Description GAI-Tronics’ CARD Suite Programming Software, Part No. XAC1000A, is needed to program some of the functions and parameter settings of the Addressable Amplified Speaker. It allows entry of operational programming data into your personal computer for transfer to the equipment. The programmed data can be retrieved, edited, archived, and printed in hard copy for record keeping.
  • Page 20: Rf Module Programming Software Installation

    20 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Place the CD in the PC’s CD-ROM drive. If the “auto-run” feature on your CD-ROM drive is enabled, the CARD Suite menu screen should appear within a few seconds. If for any reason the installation does not start up automatically, it can be run from the Start menu.
  • Page 21: Programming The Addressable Speaker Pcba (All Models)

    21 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Programming the Addressable Speaker PCBA (All Models) The Addressable Amplified Speaker must be connected to your personal computer with the programming cable, part number XAC0004A, before the CARD Suite programming software can be used. To make this connection, attach the cable to the COM1 or COM2 connector on the computer.
  • Page 22: Settings And Adjustments

    22 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Settings and Adjustments The following settings and adjustments are made via the XAC1000A CARD Suite programming software: Mode: • Generic (default) • Selective Coding: •...
  • Page 23: Programming The Rf Module (19101-024 Programming Kit) - Models 13362/13372 Only

    23 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Programming the RF Module (19101-024 Programming Kit) - Models 13362/13372 Only 1. Disconnect the connecting cable from the RF Module. Refer to Figure 4. 2. Connect the DTXP-PAC cable assembly’s red and black leads to a 12 V dc source (battery or supply) and plug into the 15-pin D connector on the RF Module.
  • Page 24: Wiring

    Install the necessary cable for wiring the speaker. Two pairs are required for wiring to the audio input terminals for the Model 13352 unit only (one audio, one page closure). Two conductors are required for supplying external 12 V dc power to all three models of the speaker. A minimum 22 AWG-conductor is recommended for audio and page control and a minimum 20 AWG-conductor is recommended for 12 V dc power.
  • Page 25: 12506-001 Remote Volume Control Wiring Instructions

    25 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A 12506-001 Remote Volume Control Wiring Instructions If the speaker requires local mechanical control of the output volume, an 8-ohm L-Pad volume control (Part No. 12506-001) can be installed. The 12506-00l Remote Volume Control assembly is designed for indoor installation but can easily be installed in a single gang outlet box, mounted inside a weatherproof enclosure.
  • Page 26 26 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Figure 6. Model 13352 Weatherproof Amplified Speaker Assembly d:\radio products-draft\gtc 43004\43004-030a\43004-030a.doc 06/05...
  • Page 27 27 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Figure 7. Model 13362 and 13372 Weatherproof Amplified Speaker Assemblies d:\radio products-draft\gtc 43004\43004-030a\43004-030a.doc 06/05...
  • Page 28: Hardware Configuration

    Hardware Configuration Jumpers The Model 13352 P2 termination jumper setting configures the unit for 600-ohm (P2-2 to P2-3) or 15 k- ohm (P2-1 to P2-2) termination. For Models 13362 and 13372, this jumper has no function. This jumper is accessible by separating the rear section of the speaker from the front section. Refer to Figure 8.
  • Page 29: Tb1 Wiring Connector

    The numbering orientation is shown in Figure 8. Pin No. Pin Name Function Positive audio input for 13352; no connection for Models 13362 or 13372 600Ω AUDIO Negative audio input for 13352; no connection for Models 13362 or 13372 600Ω AUDIO Active low signal to initiate speaker for 13352;...
  • Page 30: Radio Connector Pinout

    30 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Radio Connector Pinout The pin-out for the radio connector on the speaker half of the assembly is described below. The numbering orientation is shown in Figure 8.
  • Page 31: Terminal Strip Designations

    Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Terminal Strip Designations The wiring terminal strip is located on the rear half of the assembly. The screw terminal designations for the Model 13352 are as shown below. Refer also to Figure 6. Terminal Label Function...
  • Page 32: Definitions And Acronyms

    32 of 32 Page Model 13352, 13362, and 13372 Addressable Amplified Speaker Assemblies Pub.: 43004-030A Definitions and Acronyms Term Definition Carrier squelch Tone Private Line - A means of grouping users of a common radio channel. Subaudible tones are transmitted with audio; a particular radio's speaker (or the speakers of a group of radios) will unmute to broadcast a transmission only if the associated subaudible tone identifies it as belonging to the radio’s user group.
