- Page 1 Home Kit LH1 QUICK START GUIDE Listen to your Lynx Radio through your home stereo or powered speakers...
-
Page 2: What's In The Box
What’s in the Box? ch - ch + Lynx Home Dock Remote Control Indoor/Outdoor Home Power Stereo Audio Home Antenna Adapter Cable... - Page 3 Home Dock Buttons & Connectors Lynx Home Dock Rear View Lynx Home Dock Top View POWER AUDIO ANT (Silver) POWER AUDIO Bluetooth Button (Green) Connection for the (Red) Connection for Tap to enter Bluetooth Indoor/Outdoor Connection stereo system connection mode. If connected, Home Antenna.
- Page 4 Remote Control Button Functions and Battery Pause and Replay Buttons: Power Button Press for 3 seconds to turn Pause/Play button Radio On; press and hold to Pauses or resumes playing of turn Radio Off. the currently tuned channel. Rewind button Tune Up/Down Channels Immediately tunes up or Rewinds through content so...
- Page 5 Subscription Options Lynx allows you to connect to SiriusXM Satellite Radio, SiriusXM Internet Radio, or both. Connecting to both services provides you with the complete experience, giving you access to all of the features Lynx has to offer. Whether you’re in your home, in your vehicle*, out walking or jogging, or within range of a Wi-Fi®...
- Page 6 Install the Home Dock and Radio... Select a location in close proximity to your stereo system or powered speakers for the SiriusXM Lynx Home Dock. The location should be easily accessible and provide good visibility of the display, but should not be located where it will be in direct sunlight, which will reduce the visibility of the display screen.
- Page 7 ...and Connect an Audio Device The SiriusXM Lynx Home Dock can be connected to your stereo system, or to a set of powered speakers. To Connect the SiriusXM Lynx Home Dock to Your Stereo System: Using the provided Stereo Audio Cable, connect the single connector to the green AUDIO connector at the rear of the dock.
-
Page 8: Bluetooth Connections
Bluetooth Connections The SiriusXM Lynx Home Dock incorporates Bluetooth and allows for a wireless stereo audio connection with your Lynx Radio. This allows you to take your Lynx out of the dock and carry it with you and manage your listening experience up to 30 feet away from your dock.** (Listening to Satellite Radio, or using the Remote Control, requires Lynx to be inserted in the dock.) You can also use Bluetooth to connect Lynx with a Bluetooth stereo audio... - Page 9 Bluetooth Connections (continued) To Manually Pair and Connect Lynx to the SiriusXM Lynx Home Dock: Tap the Bluetooth button on the dock. The Bluetooth Indicator Light will blink slowly. On Lynx, tap Home , tap , tap Connect . From the Bluetooth Settings menu tap Bluetooth On/Off to turn it on, if it’s not already on.
- Page 10 Install the Indoor/Outdoor Home Antenna... This step is optional and only necessary if you will be subscribing to SiriusXM Satellite Radio. The Indoor/Outdoor Home Antenna needs to installed so that it has a clear view toward the satellites in the south sky. Open the antenna clamshell approximately half way, and place the antenna in a window that faces south.
- Page 11 ...and Subscribe to Satellite Radio If you have connected the Indoor/Outdoor Home Antenna, but have not yet subscribed to SiriusXM Satellite Radio, follow the instructions on the Activation screen to subscribe. You may need to turn Lynx off, and then on again to show the Activation screen.
-
Page 12: Specifications
Specifications System Power Requirements: 5 V DC, 1.6 A (max) Operating Temperature: -4°F to +122°F (-20°C to +50°C) Audio Output: 2.0 V rms (max) Bluetooth Home Dock Dimensions: 4.5 in (width) x 2.1 in (height) x 1.9 in (depth) 115 mm (width) x 54 mm (height) x 49 mm (depth) Weight: 5.1 oz (145 g) Audio Connector:... - Page 13 FCC and SAR Statements FCC STATEMENT: The user is cautioned that changes or modifications not expressly approved by Sirius XM Radio Inc. can void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
-
Page 14: Copyrights And Trademarks
Sirius XM Radio Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sirius XM Radio Inc is under license. “Wi-Fi” is a trademark of the Wi-Fi Alliance. Visit www.siriusxm.com/channellineup for updates. All programming/ channel lineup/XM service subject to change or preemption. - Page 16 SiriusXM or third party products. SiriusXM product warranties do not cover the installation, removal, or reinstallation of any product. Sirius XM Radio Inc. 1221 Avenue of the Americas siriusxm.com New York, NY 10020 1.866.635.2349 © 2013 Sirius XM Radio Inc. Lynx HK QSG 130108a...
