- Page 1 LH1 Home Kit User Guide 121412a...
-
Page 2: Table Of Contents
To Automatically Connect Lynx to the SiriusXM Lynx Home Dock ................... 18 To Reconnect Lynx to the SiriusXM Lynx Home Dock ....................... 18 To Manually Pair and Connect Lynx to the SiriusXM Lynx Home Dock ................18 Brightness ....................................19 Display Timeout .................................. -
Page 3: Introduction To Lynx Home Dock
Bluetooth Button: Tap to enter connection mode. If connected, tap to disconnect. If previously connected, tap to reconnect without placing Lynx in the dock. Bluetooth Indicator Light: Blinks slowly when in discoverable mode; blinks fast when connecting; is steady when... -
Page 4: Remote Control
The buttons of the Remote Control are identified in the illustration below. The details of each begin below the illustration. Power Button: Press for 3 seconds to turn Lynx On; press and hold to turn Lynx Off. Pause and Replay Buttons: Pause/Play button: Pauses or resumes playing of the currently tuned channel. -
Page 5: Remote Control Battery Replacement
Introduction to Lynx Home Dock Remote Control Battery Replacement To replace the battery in the Remote Control, follow these steps: 1. Turn the Remote Control over and remove the battery cover. It is best if you remove the battery door by inserting your fingernail in the center of the gap between the door and the back of the remote. -
Page 6: Installation
2. Connect the Indoor/Outdoor Home Antenna to the silver ANT connector at the rear of the dock. 3. Place Lynx into the Home Dock. Orient Lynx so that it is parallel to the backrest, and then gently slide it down... -
Page 7: To Connect The Siriusxm Lynx Home Dock To Your Stereo System
Installation 4. Lynx will turn on automatically when inserted into the home dock (as long as the battery is inserted). If you need to manually power on Lynx, press the Power button on the top of Lynx for 3 seconds. - Page 8 Installation 2. Plug the powered speakers into a wall outlet. 3. Turn on the powered speakers.
-
Page 9: Install The Indoor/Outdoor Home Antenna
Installation Install the Indoor/Outdoor Home Antenna These steps are only necessary if you will be subscribing to SiriusXM Satellite Radio, and listening to Satellite Radio instead of SiriusXM Internet Radio in the home. The Indoor/Outdoor Home Antenna needs to installed so that it has a clear view toward the SiriusXM satellites in the south sky. - Page 10 Installation 2. If you have not yet subscribed your Lynx to Satellite Radio, Lynx will automatically check the signal strength. If Signal Found is displayed, tap Continue to proceed with the audio check. If Lynx displays No Signal/Check Antenna, try repositioning the antenna in a different south facing window, and tap to check the signal strength again.
-
Page 11: Outdoor Antenna Installation Instructions
Home , tap , tap Settings , tap About Lynx, and tap Connection status to display the satellite and terrestrial signal strength. While observing the signal strength, make small adjustments to the angle of tilt of the clamshell until the highest possible signal strength is achieved. - Page 12 Installation Note: You need to consider any potential hazards when you choose the mounting location, and consider professional installation. SiriusXM is not liable for any damages or injury. To mount the antenna, you will need four screws (not included) with a 1/4” head (e.g., a #4 screw), and that are suitable for the material onto which you are affixing the antenna, (e.g., wood, metal, etc.).
-
Page 13: Activation
Activate your SiriusXM Satellite Radio Subscription When Lynx is in the LH1 Home Dock, with the Indoor/Outdoor Home Antenna connected, you will be prompted to subscribe to Satellite Radio, if you have not yet subscribed. Be sure that you have installed the dock according to the instructions included with the Kit, and that you are at the Activation screen with good satellite signal strength. -
Page 14: Activate Your Siriusxm Internet Radio Subscription
7. Activation usually takes 10 to 15 minutes after you have completed the subscription process, but may take up to an hour. We recommend that Lynx remain on and in the dock until subscribed. Lynx will display a Subscription Updated message when it receives the activation signal. Once subscribed, you’ll be able to tune to the channels in your subscription plan. - Page 15 6. From the Wi-Fi settings screen, tap Wi-Fi On/Off to turn on the Wi-Fi. 7. Lynx will scan for and detect any Wi-Fi networks within its range and display them under Wi-Fi networks. If no Wi-Fi networks were detected, move to a location where there is a Wi-Fi network and tap Scan for networks.
- Page 16 • by tuning to channel 0 • on a label on the bottom of the gift box • on the label inside the rear cover of Lynx Note: The Radio ID does not use the letters I, O, S, or F.
- Page 17 Username to display the on-screen keyboard. Enter your username, then tap Next and enter your password. Tap Done and tap Login & Listen Now. 14. Lynx will check your username and password and connect to SiriusXM Internet Radio. If you entered them incorrectly, tap Close to try again.
-
Page 18: Using The Lynx Home Dock
Lynx Radio. This allows you to take your Lynx out of the dock and carry it with you and manage your listening experience up to 30 feet away from your dock. (Listening to Satellite Radio, or using the Remote Control, requires Lynx to be inserted in the dock.) -
Page 19: Brightness
Bluetooth available devices under Bluetooth devices. 4. Tap the SiriusXM Lynx Home Dock name in the list. Lynx will connect with the dock. If successful, the Connected to... message will be displayed below dock name. The Bluetooth Indicator Light on the dock will blink rapidly 3 times during the connection process and then remain on indicating that your Lynx is now connected. -
Page 20: Display Timeout
Audio Level Audio level allows you to adjust the volume of Lynx to match the audio output level of other devices you may have connected to your stereo system, so that, when you switch between them, you don’t have to adjust the stereo volume up or down. - Page 21 Using the Lynx Home Dock Note: The < and > volume button will also adjust the volume.
-
Page 22: Auto Off
Auto Off Auto off sets the amount of time before Lynx turns itself off. This is useful if you are listening to Lynx as you fall asleep. Choices are Never (default), 30 minutes, or 1, 2, or 3 hours. If Auto off is on, and you touch any of the controls, or the display screen, the Auto off countdown will reset and begin over again. -
Page 23: Renaming The Home Dock
The Home Dock can be renamed, up to 25 characters long. To rename the Home Dock, tap Home , tap , tap Settings , tap About Lynx, tap Device Information, tap Dock Information, tap Dock Name. Using the on-screen keyboard, type the new Home Dock name. When complete, tap Done on the keyboard (or Back... -
Page 24: Troubleshooting
If this message persists, the antenna cable may have been damaged. Replace the antenna. To listen to Satellite Radio, Lynx has to be in a powered dock, with a Satellite Radio not available properly installed Satellite Radio antenna connected and correctly aimed. -
Page 25: Problem Troubleshooting
Lynx on. I connected Lynx to my computer Lynx will not charge from the computer if it is in any audio playing to charge the battery, but it does mode. It’s recommended that Lynx be turned off, or not in any audio not charge. - Page 26 Satellite Radio, go to http://www.siriusxm.com/refresh 1 on Satellite Radio. and enter the Radio ID of your Lynx. For Canadian residents, go to I don’t receive all the Satellite http://refresh.xmradio.ca.) Once you have entered the Radio ID, the Radio channels to which I subscription information will be sent to your Lynx within 5 minutes.
- Page 27 On/Off to turn it on. Favorites. Featured Favorites are received when listening to Satellite Radio. Have you set any Show Alerts and/or Game Alerts? Consult the Lynx User Guide for more information. Have you turned off the alert notification feature? I don’t receive any Show Alerts.
