- Page 1 User Guide SiriUS ConneCt ™ Home Kit...
- Page 2 Congratulations on the Purchase of your new SCHDOC1 SiriusConnect Home Docking Kit The SCHDOC1 SiriusConnect™ Home Docking Kit will turn your SIRIUS Dock & Play or portable radio into a dedicated tuner, allowing you to control your SIRIUS radio from your Sirius Ready home audio system.
-
Page 3: Table Of Contents
Table of Contents Table Of COnTenTS COPyrigHTS & TraDemarKS Warning anD SafeTy infOrmaTiOn FCC Information ......5 Canadian Compliance . -
Page 4: Copyrights & Trademarks
Copyrights & Trademarks © 2007 Sirius Satellite Radio Inc. All Rights Reserved. ® “SIRIUS”, the SIRIUS dog logo, channel names and logos are trademarks of Sirius Satellite Radio Inc. All Rights Reserved. ™ “SiriusConnect”, “Stiletto”, “Sportster”, “Starmate”, and “Stratus” are trademarks of Sirius Satellite Radio Inc. -
Page 5: Warning And Safety Information
Warning and Safety Information FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Canadian Compliance
Canadian Compliance This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Safety Precautions Be sure to observe the following warnings. Failure to follow these safety instructions and warnings may result in a serious accident and/or personal injury. -
Page 7: Package Contents
Package Contents The following items are included with your purchase of the SCHDOC1 SiriusConnect Home Docking Kit. Unpack the kit carefully and make sure that everything shown is present. If anything is missing or damaged, or if the kit fails to operate properly, notify your dealer immediately. - Page 8 SiriusConnect SiriusConnect aC adapter aC adapter indoor/Outdoor antenna indoor/Outdoor antenna interface Cable interface Cable The following compatibility chart shows which SIRIUS radios are compatible with each radio adapter: Radio Adapter Compatible with these SIRIUS radios Adapter 1 (preinstalled) Sportster 5, Starmate 3 & 4, Stratus & Stratus 4 Adapter 2 Sportster 3 &...
-
Page 9: Controls And Connectors
Controls and Connectors Figure 1 and the table following identify and describe the controls, connectors, and various mounting connections of the dock. Radio Adapter Mounting Hole Radio Adapter Alignment Holes Sirius Universal Docking Connector SiriusConnect Interface Connector Antenna Connector Radio Release Button Power Connector figure 1... - Page 10 Description of Dock Controls, Connectors, and mounting Connections Control/Connector/ Description mounting Connection Pressing this button releases the SIRIUS radio from Radio Release Button the dock. Tabs on the radio adapter align with these holes for Radio Adapter correct placement in the dock. Alignment Holes This connector plugs into the bottom of the SIRIUS Sirius Universal Docking...
-
Page 11: Installation
Installation It is recommended that prior to starting the installation, you read this installation sec- tion completely and then follow the instructions. In addition, consult the manual of the receiver to which you will be connecting the dock to determine any required installa- tion configuration. - Page 12 Radio Adapter Mounting Screw (A) Radio Adapter figure 2 figure 2 When the radio adapter has been attached to the dock, you can place your SIRIUS radio into the dock. Installation...
-
Page 13: Connecting The Dock To The Sirius-Ready Receiver
Connecting the Dock to the SIRIUS-Ready Receiver The SCHDOC1 SiriusConnect Home Docking Kit is designed to work with any Sirius- Ready or SAT Radio Ready receiver. Please consult the user manual or manufacturer for your receiver for more details concerning compatibility. Some systems that only have RS232 control (and no 8-pin DIN connector) require the SCHDOC1P kit instead. -
Page 14: Installing The Indoor/Outdoor Antenna
Installing the Indoor/Outdoor Antenna Before installing the indoor/outdoor antenna, read this entire section. To ensure consistent reception of the SIRIUS signal in your home, it is important that the antenna be oriented correctly. Note the following Best, Better, and Good consider- ations for antenna placement. - Page 15 figure 4 figure 4 GOOD reception can be achieved by placing the antenna indoors on a windowsill. The window will need to be facing in the direction of the SIRIUS satellites, as de- scribed later, and have a clear view of the sky. The antenna may need to be placed on a book to raise it above the level of the window frame.
- Page 16 figure 5 figure 5 If you cannot obtain a clear 360 degree view of the sky (Best), then for the Better and Good installations you must at least have a clear view of the sky in the direction of the SIRIUS satellites, as shown in the following map diagram.
- Page 17 NORTH WEST EAST HORIZON SOUTH figure 6 figure 6 Use the map to find the area you are located in (1 to 5). Then find the direction in which you need to have a clear view of the sky: Area 1: You will need a location with a clear view of the sky facing EAST or NORTHEAST or SOUTHEAST Area 2: You will need a location with a clear view of the sky facing NORTH or NORTHEAST...
- Page 18 The location for the antenna must have an unobstructed view of the sky in the direction indicated for your area. (Figure 7) For example, suppose you live in Area 2. You determined that your antenna will need to have a clear view of the sky facing North or Northeast. The exact direction is determined by your specific location in Area 2 relative to the X on the map: If you live in Texas, you will need a more North facing clear view of the sky whereas if you live in southern California, you will need a more Northeast facing clear view of the sky.
- Page 19 Testing and Optimizing the antenna Signal Strength The stronger the SIRIUS signal strength, the less likely it is that you will experience an interruption of the audio when listening to a broadcast. To assist you in adjusting the antenna aiming for optimal reception, your SIRIUS radio or SIRIUS-Ready receiver can display a screen showing the strength of the SIRIUS signal being received, similar to Figure 8.
- Page 20 THIS SURFACE OF THE ANTENNA SHOULD BE POINTED AT THE SKY TOWARDS THE DIRECTION OF THE SATELLITES figure 9 figure 9 The second adjustment is to turn the antenna slightly to the left or right until the high- est possible signal strength is achieved. (Figure 10) figure 10 figure 10 Installation...
-
Page 21: Connecting The Ac Power Adapter
If you find that it is not possible to receive a good SIRIUS signal in your location, SIRIUS offers a outdoor home antenna which can be mounted to the exterior of the home. The outdoor home antenna offers more mounting options, such as mounting on an existing mast or satellite dish mast, and provides 30 ft. -
Page 22: Operation
Operation Before you can listen to the SIRIUS service, you need to subscribe to the Sirius Satel- lite Radio service if you have not done so already. Please be sure to follow the activa- tion instructions for your specific SIRIUS radio as well as your receiver. Place your SIRIUS radio into the dock (Figure 11), aligning the tabs at the edges of the radio adapter with the groves in your SIRIUS radio. - Page 23 For operating instructions consult the owners manual of your audio system. When your SIRIUS radio is connected via the SCHDOC1 SiriusConnect Home Docking Kit to your receiver, the buttons and controls of the SIRIUS radio will be disabled, and a SiriusConnect message or logo will be displayed. Operation...
-
Page 24: Specifications
Specifications Power Requirements ......... . 5.2V DC, 2A Operation Temperature . - Page 28 sirius.com SiriUS Satellite radio inc. 1221 Avenue of the Americas new York, nY 10020 800.869.5590 SCHDoC1 (SCHDoC1122007a) oo.ABCD1.001...
