HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

MODEL NAME
KD-32FS130
KD-36FS130
ORIGINAL MANUAL ISSUE DATE: 6/2005
REVISION DATE
6/2005
9-965-983-01
REMOTE COMMANDER
RM-YD001
RM-YD001
SUBJECT
No revisions or updates are applicable at this time.
BA-6
DESTINATION
CHASSIS NO.
US
SCC-S61V-A
US
SCC-S61W-A
®
TRINITRON
COLOR TELEVISION
CHASSIS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRINITRON KD-32FS130 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony TRINITRON KD-32FS130

Summary of Contents for Sony TRINITRON KD-32FS130

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: BA-6 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO. KD-32FS130 RM-YD001 SCC-S61V-A KD-36FS130 RM-YD001 SCC-S61W-A ORIGINAL MANUAL ISSUE DATE: 6/2005 REVISION DATE SUBJECT 6/2005 No revisions or updates are applicable at this time.
  • Page 2 Self Diagnosis Supported model BA-6 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO. KD-32FS130 RM-YD001 SCC-S61V-A KD-36FS130 RM-YD001 SCC-S61W-A KD-32FS130 RM-YD001 ® TRINITRON COLOR TELEVISION 9-965-983-01...

  • Page 3: Table Of Contents

    Anode Cap Removal Procedure .......... 12 GS Board Schematic Diagram ..........59 Cable Wire Dressing ............13 HS Board Schematic Diagram ..........60 KD-32FS130 Models Only ..........13 5-4. Semiconductors ..............61 KD-36FS130 Models Only ..........22 SECTION 6: EXPLODED VIEWS ............62 SECTION 2: SET-UP ADJUSTMENTS ..........

  • Page 4: Specifi Cations

    PR Vp-p, 75 ohms. 4) 500 mVrms (100% modulation), Impedance: 47 kilohms 5) This specifi cation is the maximum wattage. As an ENERGY STAR® Partner, Sony Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR®...
  • Page 5 75-ohm external antenna terminal for VHF/UHF Picture tube ® FD Trinitron tube Visible screen size 32-inch picture measured diagonally (KD-32FS130 Only) 36-inch picture measured diagonally (KD-36FS130 Only) Actual screen size 34-inch measured diagonally (KD-32FS130 Only) 38-inch measured diagonally (KD-36FS130 Only) Supplied Accessories...

  • Page 6: Warnings And Cautions

    Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identifi ed in this manual. Follow these procedures whenever critical components are replaced or improper operation is suspected.

  • Page 7: Safety Check-Out

    KD-32FS130/36FS130 SAFETY CHECK-OUT The AC leakage from any exposed metal part to earth ground and After correcting the original service problem, perform the following from all exposed metal parts to any exposed metal part having a safety checks before releasing the set to the customer: return to chassis, must not exceed 0.5 mA (500 microamperes).

  • Page 8: Self-Diagnostic Function

    KD-32FS130/36FS130 Self Diagnosis SELF-DIAGNOSTIC FUNCTION Supported model The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to fl ash. The number of times the LED fl ashes translates to a probable source of the problem. A defi nition of the STANDBY/TIMER LED fl ash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 9 KD-32FS130/36FS130 Self-Diagnostic Screen Display For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confi rmed, it is possible to bring up past occurrences of failure on the screen for confi rmation.

  • Page 10: Section 1: Disassembly

    KD-32FS130/36FS130 SECTION 1: DISASSEMBLY 1-1. REAR COVER REMOVAL 1 Remove screws from top of cover. 4 Screws SCREW +BVTP 3X12 TYPE2 TT (B) 2 Remove screws from sides of cover. 4 Screws SCREW +BVTP 3X12 TYPE2 TT (B)-2 each side 3 Remove screws from sides of cover.

  • Page 11: Service Position

    KD-32FS130/36FS130 1-3. SERVICE POSITION 1 Disconnect the CN501 cable from the A Board. 2 Press on catch tab to release A Board. 3 Gently pull the A Board forward to access the GS and HS Boards. 4 Gently continuing pulling the A Board, GS Board and HS Board forward to place in service position.

  • Page 12: Picture Tube Removal

    KD-32FS130/36FS130 1-4. PICTURE TUBE REMOVAL WARNING: BEFORE REMOVING THE ANODE CAP High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to remove the anode cap. Short between anode and CRT coated earth ground strap.

  • Page 13: Cable Wire Dressing

    KD-32FS130/36FS130 CABLE WIRE DRESSING KD-32FS130 MODELS ONLY 32FS130 speaker harness harness harness NOTE: 4P (14v) harness (A/CN201~GS/CN1650) - Dress Right & left speaker wire through DGC's tie wrap & DY's clip as should be between speaker harness shown in pictures.
  • Page 14 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 Dress CRT ground behind DGC as picture shows. Focus & Anodo cap - Install rotation coil lead wire connection under DY clip. - Dress RGB harness (MD/CN301~ C/CN705) over Rotation coil lead wire. -Dress RGB & Rotation coil lead wire harnesses interlace twice as picture shows.
  • Page 15 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 - Dress DY's lead wire using a 9mm purse lock Twist G2 & DF wire without (3-703-982-02). stressing it, as picture shows. Pass G2 wire through FBT clip. Rev 1.2 4/10 KD-32FS130/36FS130...
  • Page 16 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 Caution point: Avoid wires to touch LFT or any 12P harness other primary component DY's magnet as reference. Wire clip Black Tape 4P harness - Fix 12P harness (HS/CN1004~MD/CN303) using a wire clip (4-051-925-01) & purse lock (4-072-499-11).
  • Page 17 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES Tunner 4P Harness Pass 12P harness between connector AC-Cord & USB Cable. 30mm Q-Box Tab CRT support - Pass 12P harness (A/CN101~Q-BOX) - Dress 4P (10.5V) harness (GS/CN1670~Q-BOX)
  • Page 18 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES - Tunner connector should be as shown in picture. - Dress Tunner cable as shown in picture. Rev 1.2 7/10 KD-32FS130/36FS130...
  • Page 19 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES USB cable, 6P (MD/CN304~Q-Box) 6P (MD/CN304~Q-Box) & & 12P (MD/CN302~Q-Box) 12P (MD/CN302~Q-Box) Q-BOX Tab USB cable should be beside heatsink - Interlace 6P (MD/CN304~Q-Box) & 12P - Dress USB Cable, 6P (MD/CN304~Q-Box) &...
  • Page 20 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES Fix from Ferrite loop. -Fix AC-Cord to DGC using a DGC purse Tunner lock (4-081-411-02). Fix AC-Cord from ferrite ground loop. -Pass Tunner ground through ferrite loop as shown in picture.
  • Page 21 KD-32FS130/36FS130 KD-32FS130 MODELS ONLY 32FS130 15cm Dress focus lead and HV cable together using 5mm purse lock Install purse lock (4-081-411-02) using carbon paint as (3-703-981-02) reference. Rev 1.2 10/10 KD-32FS130/36FS130...

  • Page 22: Kd-36Fs130 Models Only

    KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 - Fix Right speaker to DGC hook using a 9mm purse Fix Left speaker to DGC hook using a 11mm purse lock (3-703-982-02). lock (3-703-983-02). - Fix DGC lead wire to DGC's tie wrap with a 9mm purse lock (3-703-982-02) as shown in picture.
  • Page 23 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 Through Rotation coil Rotation coil wire loop Over V board Under DGC Harness - Dress rotation coil lead wire make a loop as shown in picture. Dress earth groun wires under DGC, througt - Pass RGB harness (MD/CN301~ C/CN705) througt rotation coil &...
  • Page 24 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 - Dress DY's lead wire using a 9mm purse lock (3-703-982- Twist G2 & DF wire without 02). stressing it, as picture shows. Dress VM & Heater harnesses using a 5mm purse lock (3-703-981-02). Take as Reference YUV jack height as picture shows.
  • Page 25 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 AC-Cord, Caution point: AC-Cord & Tunner cable Avoid wires to touch LFT or any Tunner cable & tunner 12P harness other primary component ground Tunner ground Wire clip 4P harness Dress AC-Cord, Tuner cable & Tunner ground...
  • Page 26 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES Tunner 4P Harness Pass 12P harness between connector AC-Cord & USB Cable. 30mm Q-Box Tab CRT support - Dress 4P (10.5V) harness (GS/CN1670~Q-BOX) - Pass 12P harness (A/CN101~Q-BOX) pass under Tunner connector, Q-Box tab &...
  • Page 27 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 CRITICAL POINT FOR EMI RESULTS, DRESSING MUST BE FOLLOW AS SHOWN IN PICTURES USB cable, 6P (MD/CN304~Q-Box) 6P (MD/CN304~Q-Box) & & 12P (MD/CN302~Q-Box) 12P (MD/CN302~Q-Box) Q-BOX Tab USB cable should be beside heatsink - Interlace 6P (MD/CN304~Q-Box) & 12P - Dress USB Cable, 6P (MD/CN304~Q-Box) &...
  • Page 28 KD-32FS130/36FS130 KD-36FS130 MODELS ONLY 36FS130 Beside V BOARD Install purse lock (4-089-469-11) using carbon paint as reference. - Pass focus lead beside V board as shown in picture. Rev 1.2 KD-32FS130/36FS130...

  • Page 29: Section 2: Set-Up Adjustments

    KD-32FS130/36FS130 SECTION 2: SET-UP ADJUSTMENTS The following adjustments should be made when a complete Perform the adjustments in order as follows: realignment is required or a new picture tube is installed. Beam Landing Convergence These adjustments should be performed with rated power supply Focus voltage unless otherwise noted.

  • Page 30: Convergence

    KD-32FS130/36FS130 2-2. CONVERGENCE Horizontal Static Convergence Before starting convergence adjustments: If the blue dot does not converge with the red and green dots, perform the following: 1 Perform FOCUS, VLIN and VSIZE adjustments. 1. Move H STAT VR magnet (a) to correct insuffi cient H.Static 2.

  • Page 31: Focus

    KD-32FS130/36FS130 Dynamic Convergence Adjustment Before performing this adjustment, perform Horizontal and Vertical Static Convergence Adjustment. 1. Slightly loosen defl ection yoke screw. TLH+ 2. Remove defl ection yoke spacers. (R)(B) (B)(R) TLH- 3. Move the defl ection yoke for best convergence as shown below: 4.

  • Page 32: Screen (G2)

    KD-32FS130/36FS130 2-4. SCREEN (G2) 1. Input a dot pattern. 2. Set the PICTURE and BRIGHTNESS controls at minimum and COLOR control at normal. 3. Adjust SBRT, GCUT, BCUT in service mode with an oscilloscope as shown below so that voltages on the red, green, and blue cathodes are 172 ±...

  • Page 33: Section 3: Safety Related Adjustments

    KD-32FS130/36FS130 SECTION 3: SAFETY RELATED ADJUSTMENTS 3-1. X R530, R531 CONFIRMATION METHOD Hold-Down Readjustment (HV HOLD-DOWN CONFIRMATION) AND If the setting indicated in Step 2 of Hold-Down Operation Confi rmation READJUSTMENTS cannot be met, readjustment should be performed by altering the resistance value of R530, R531 component marked with X.

  • Page 34: Section 4: Circuit Adjustments

    KD-32FS130/36FS130 SECTION 4: CIRCUIT ADJUSTMENTS Electrical Adjustments by Remote Commander Use the Remote Commander (RM-YD001) perform the circuit adjustments in this section. Test Equipment Required: 1. Pattern generator 2. Frequency counter 3. Digital multimeter 4. Audio oscillator 4-2. ACCESSING THE SERVICE 4-1.

  • Page 35: Confi Rming Service Adjustment Changes

    KD-32FS130/36FS130 Service Adjustment Mode Memory 4-3. CONFIRMING SERVICE ADJUSTMENT CHANGES Use the following procedure when adjusting IDs 0-7 and when replacing and adjusting IC002. 1. After completing adjustments, pull out the plug from the AC outlet, 1. Access Service Adjustment Mode.

  • Page 36: White Balance Adjustments

    KD-32FS130/36FS130 4-4. WHITE BALANCE ADJUSTMENTS 11. Press 3 or 6 to adjust the value of SCON to 85 ± 2Vpp. 1. Input an entire white signal with burst. 85 + 2Vpp 2. Access Service Adjustment Mode. 3. Set the PICTURE and BRIGHTNESS to minimum.
  • Page 37 KD-32FS130/36FS130 Sub Hue, Sub Color Adjustment H. Center Adjustment (HPOS) (SHUE, SCOL) Perform this adjustment after performing H. Frequency (Free Run) Check. 1. Input color-bar signal at 75%. 1. Input a crosshatch signal. 2. Access Service Adjustment Mode. 2. Access Service Adjustment Mode.
  • Page 38 KD-32FS130/36FS130 V. Linearity (VLIN), V. Correction (SCOR), V. Angle (VANG), V. Bow (VBOW), Upper PIN PIN Amp (PAMP), and Trapezoid (TRAP) (UPIN) and Low PIN (LPIN) Adjustments Adjustments 1. Input a crosshatch signal. 1. Input a crosshatch signal. 2. Access Service Adjustment Mode.

  • Page 39: Service Data Lists

    KD-32FS130/36FS130 4-6. SERVICE DATA LISTS KD-32FS130/36FS130...
  • Page 40 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 41 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 42 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 43 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 44 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 45 KD-32FS130/36FS130 KD-32FS130/36FS130...
  • Page 46 KD-32FS130/36FS130 KD-32FS130/36FS130...

  • Page 47: Id Map Table

    KD-32FS130/36FS130 4-7. ID MAP TABLE Model Dstination KD-32FS130 KD-36FS130 KD-32FS130/36FS130...

  • Page 48: Section 5: Diagrams

    KD-32FS130/36FS130 SECTION 5: DIAGRAMS The components identifi ed by shading and 5-1. CIRCUIT BOARDS LOCATION symbol are critical for safety. Replace only with part number specifi ed. The symbol indicates a fast operating fuse and is displayed on the component side of the board.

  • Page 49: Block Diagrams And Schematics

    KD-32FS130/36FS130 5-3. BLOCK DIAGRAMS AND SCHEMATICS SIGNAL FLOW BLOCK DIAGRAM KD-32FS130/36FS130...

  • Page 50: A Board Schematic Diagram (1 Of 2)

    KD-32FS130/36FS130 A BOARD SCHEMATIC DIAGRAM (1 OF 2) A BOARD WAVEFORMS C309 R209 100k C203 R208 R391 :CHIP :CHIP 1/4W R393 D201 R219 :CHIP :CHIP MTZJ-T-77-9.1B R217 C206 :CHIP — 100k 1/16W D305 :CHIP :CHIP C-YC R107 :CHIP PDZ9.1B-115 C202...

  • Page 51: A Board Schematic Diagram (2 Of 2)

    KD-32FS130/36FS130 A BOARD SCHEMATIC DIAGRAM (2 OF 2) D647 Q605 10ERB20-TA1B2 2SD774-T-3 18.8 — R692 C622 C690 D645 1000p 1/10W 10ERB20-TA1B2 CHIP R691 D620 MA111-TX 1/10W Q691 CHIP CHIP D600 T603 D690 2SA933AS D4SB60L-F MTZJ-T-77-27 STBY PWR SW R686 Q690 —...
  • Page 52 KD-32FS130/36FS130 [TUNER/IF, TUNING CONTROL, DEFLECTION, AUDIO, POWER SUPPLY, ] [TUNER/IF, TUNING CONTROL, DEFLECTION, AUDIO, POWER SUPPLY, ] COMPONENT SIDE CONDUCTOR SIDE A BOARD LOCATOR LIST CONDUCTOR SIDE DIODE DIODE DIODE TRANSISTOR D200 D423 D580 IC302 Q509 G-10 D201 D424 D588...

  • Page 53: Md Board Schematic Diagram

    KD-32FS130/36FS130 MD BOARD SCHEMATIC DIAGRAM A BOARD WAVEFORMS CN302 :S-MICRO TO D MODULE FOR JIG FOR JIG TO HS BOARD TO C BOARD CN1004 CN705 2.14V p-p (H) 2.6V p-p (H) 212.5V p-p (H) CN001 CN002 CN303 CN301 — R3395...
  • Page 54 KD-32FS130/36FS130 [MICRO, TUNING CONTROL, Y/C/J] [MICRO, TUNING CONTROL, Y/C/J] COMPONENT SIDE CONDUCTOR SIDE MD BOARD LOCATOR LIST DIODE TRANSISTOR COMP COND COMP COND COMP COND D002 IC001 Q002 D004 IC002 Q004 D005 IC003 Q008 D006 IC004 Q017 D044 IC005 Q301...

  • Page 55: C Board Schematic Diagram

    KD-32FS130/36FS130 C BOARD SCHEMATIC DIAGRAM C BOARD WAVEFORMS 4.10 p-p (H) 3.50V p-p (H) 3.50V p-p (H) — TO A BOARD (T503) R718 (1P) R716 1/2W CN704 164.1V p-p (H) 145.3 V p-p (H) 134.4V p-p (H) C715 4700p C716...
  • Page 56 KD-32FS130/36FS130 [CRT DRIVE, RGB DRIVE] [CRT DRIVE, RGB DRIVE] COMPONENT SIDE CONDUCTOR SIDE KD-32FS130/36FS130...

  • Page 57: Board Schematic Diagram

    KD-32FS130/36FS130 V BOARD SCHEMATIC DIAGRAM — L802 10mH D806 C914 1SS133T-77 R923 0.047mF R876 :CHIP R932 1.5k C811 R935 :CHIP C912 C913 Q907 0.082 Q808 2SC3052EF-T1-1EF 400V L801 0.001mF VM OUT KTB764 10mH D807 QP OUT ERA82-004TP5 TO NECK ASSY...
  • Page 58 KD-32FS130/36FS130 [VELOCITY MODULATION, DEFLECTION] [VELOCITY MODULATION, DEFLECTION] CONDUCTOR SIDE COMPONENT SIDE KD-32FS130/36FS130...

  • Page 59: Gs Board Schematic Diagram

    KD-32FS130/36FS130 GS BOARD SCHEMATIC DIAGRAM [10.5V REG] [10.5V REG] COMPONENT SIDE CONDUCTOR SIDE TO A BOARD CN201 — IC1690 CN1650 PQ15RW21J00H R1691 10V REG 3.3k TO D MODULE C1630 L1690 JW1690 R1692 LOW B 3.3k CN1670 LOW B C1690 R1694 2200 3.3k...

  • Page 60: Hs Board Schematic Diagram

    KD-32FS130/36FS130 HS BOARD SCHEMATIC DIAGRAM [FRONT A/V, MENU KEY, IR DETECTOR] COMPONENT SIDE FRONT VIDEO2 J1231 C1238 — D1233 RD9.1EW-T1 C1201 1000p D1235 C1234 R1235 R1236 100k RD9.1EW-T1 1/4W 1/4W C1235 R1237 D1236 R1238 RD9.1EW-T1 1/4W 100k 1/4W — TO MD BOARD...

  • Page 61: Semiconductors

    KD-32FS130/36FS130 5-4. SEMICONDUCTORS 2SB709A-QRS-TX 2SB734-T-34 2SA1309A-QRSTA 2SC3840K 2SA1837 2SD601A-QRS-TX 2SC3209LK-TP 2SC3311A-QRSTA LETTER SIDE 2SD2144S-TP-UVW LETTER SIDE 2SA1091O-TPE2 IRF614 2SK2663 2SC4793 2SD2578-YB RU-1P ERA38-06TP1 ERB44-06TP1 RD9.1EW-T1 MA111-TX ERC06-15S ERA82-004TP5 UDZ-TE-17.5.1B 1SS83TD EGP20DPKG23 1SS133T-77 UDZ-TE-17.91B GP08DPKG23 MTZJ-T-77-5.1C CATHODE D1NS0R-TA CATHODE RGP10GPKG23 MTZJ-T-77-5.6C...

  • Page 62: Section 6: Exploded Views

    4-089-469-11 STANDOFF, HV QT Board. These boards cannot be ordered separately. (KD-36FS130 ONLY) A-1098-857-A MD (VAR) BOARD, MOUNTED A-1139-006-A C (VAR) BOARD, MOUNTED (KD-32FS130 ONLY) A-1098-864-A V (VAR) BOARD, MOUNTED A-1098-858-A MD (VAR) BOARD, MOUNTED 1-830-657-11 P-F CABLE (KD-36FS130 ONLY)

  • Page 63: Picture Tube

    [ASSEMBLY INCLUDES] 7-685-663-79 SCREW +BVTP 4X16 TYPE2 TT(B) X-2055-068-1 BEZNET ASSY [31-36] 1-428-988-31 DEGAUSSING COIL (31 INCH 120V) 4-046-765-12 SCREW, TAPPING 7+CROWN WASHER (KD-32FS130 ONLY) (KD-32FS130 ONLY) 4-388-477-02 SCREW (3X16), TAPPING, +BV X-2055-069-1 BEZNET ASSY [31-36] 1-456-011-21 COIL, DEGAUSSING 7-685-648-79...

  • Page 64: Section 7: Electrical Parts List

    KD-32FS130/36FS130 SECTION 7: ELECTRICAL PARTS LIST NOTE: The components identifi ed by shading The components in this manual identifi ed by the following RESISTORS mark are critical for safety. Replace only symbol: indicate parts that have been carefully factory- • All resistors are in ohms with part number specifi...
  • Page 65 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C432 1-164-315-11 CERAMIC CHIP 470pF C532 1-126-965-91 ELECT 22µF...
  • Page 66 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C650 1-100-120-51 ELECT 1000µF D320 8-719-069-60 DIODE UDZSTE-179.1B...
  • Page 67 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES D612 8-719-068-00 DIODE ERC04-06SE IC401 6-705-054-01 TDA8947J/N3 D613...
  • Page 68 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES PHOTO COUPLER Q608 8-729-922-37 TRANSISTOR 2SD2144S-UVW Q611 6-550-409-01...
  • Page 69 KD-32FS130/36FS130 A component identifi ed by this symbol indicates that it NOTE: The components identifi ed by shading has been carefully factory-selected to satisfy regulations mark are critical for safety. Replace only regarding X-ray radiation. Should replacement be required, with part number specifi ed.
  • Page 70 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R548 1-215-453-00 METAL 1/4W R613 1-216-833-11 METAL CHIP...
  • Page 71 C101 1-126-940-11 ELECT 330µF C102 1-115-416-11 CERAMIC CHIP 0.001µF 5% A-1098-857-A MD (VAR), BOARD, MOUNTED C103 1-126-947-11 ELECT 47µF (KD-32FS130 ONLY) A-1098-858-A MD (VAR), BOARD, MOUNTED C115 1-164-739-11 CERAMIC CHIP 560pF (KD-36FS130 ONLY) C116 1-107-826-11 CERAMIC CHIP 0.1µF C304 1-107-826-11 CERAMIC CHIP 0.1µF...
  • Page 72 KD-32FS130/36FS130 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C325 1-162-967-11 CERAMIC CHIP 0.0033µF 10% C3989 1-126-964-11 ELECT 10µF C326 1-164-505-11 CERAMIC CHIP 2.2µF C3990 1-126-964-11 ELECT 10µF C330 1-107-826-11 CERAMIC CHIP 0.1µF C3991 1-126-964-11 ELECT 10µF...
  • Page 73 KD-32FS130/36FS130 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES FERRITE BEAD TRANSISTOR FB302 1-469-549-21 INDUCTOR 1µH Q002 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q008 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q301 8-729-600-22 TRANSISTOR 2SA1235-F FILTER Q303 8-729-600-22 TRANSISTOR...
  • Page 74 KD-32FS130/36FS130 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R021 1-216-813-11 METAL CHIP 1/10W R100 1-216-849-11 METAL CHIP 220K 1/10W R022 1-216-813-11 METAL CHIP 1/10W R101 1-216-829-11 METAL CHIP 4.7K 1/10W R027 1-218-887-11 METAL CHIP 0.50% 1/10W...
  • Page 75 KD-32FS130/36FS130 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R365 1-216-864-11 SHORT CHIP R3394 1-216-833-11 METAL CHIP 1/10W R370 1-216-825-11 METAL CHIP 2.2K 1/10W R3395 1-216-864-11 SHORT CHIP R371 1-216-849-11 METAL CHIP 220K 1/10W R3396 1-216-864-11...
  • Page 76 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6002 1-216-833-11 METAL CHIP 1/10W D703 8-719-901-83 DIODE...
  • Page 77 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R721 1-216-825-11 METAL CHIP 2.2K 1/10W C909 1-104-999-11 MYLAR 0.1µF...
  • Page 78 KD-32FS130/36FS130 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R818 1-216-809-11 METAL CHIP 1/10W R819 1-216-841-11 METAL CHIP 1/10W IC801 6-701-598-01 UPC5023CS-184 R820 1-218-869-11 METAL CHIP 8.2K 0.50% 1/10W R821 1-216-832-11 METAL CHIP 8.2K 1/10W R822...
  • Page 79 KD-32FS130/36FS130 NOTE: The components identifi ed by shading mark are critical for safety. Replace only with part number specifi ed. REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R919 1-249-401-11 CARBON 1/4W CONNECTOR R921 1-249-429-11 CARBON...
  • Page 80 VALUES REF. NO. PART NO. DESCRIPTION VALUES TRANSISTOR ACCESSORIES AND PACKING Q1001 8-729-922-37 TRANSISTOR 2SD2144S-UVW 2-591-502-21 MANUAL, INSTRUCTION 2-591-501-01 CARTON, INDIVIDUAL (KD-32FS130 ONLY) RESISTOR 2-591-503-01 CARTON, INDIVIDUAL R1002 1-249-429-11 CARBON 1/4W (KD-36FS130 ONLY) R1003 1-249-417-11 CARBON 1/4W R1004 1-249-417-11 CARBON...
  • Page 81 In an effort to reduce the size of this pdf fi le the tiled schematics are not attached to this Service Manual. To receive a complete set of the tiled schematics for this manual please submit a request to: Service_Promotion@am.sony.com.
