2000 Expedition/Navigator Workshop Manual
SECTION 303-01A: Engine — 4.6L and 5.4L
IN-VEHICLE REPAIR
Timing Drive Components — Romeo Engine
Special Tool(s)
Aligner, Camshaft
303-380 (T91P-6256-A)
Aligner, Camshaft Pulley
303-413 (T92P-6256-A)
Holding Tool, Crankshaft
303-448 (T93P-6303-A)
Removal
CAUTION: Since the engine is not free-wheeling, timing procedures must be followed exactly or piston and valve damage may occur.
1. Remove the engine front cover. For additional information, refer to
2. Remove the crankshaft sensor ring from the crankshaft.
3. Rotate the crankshaft until the timing mark on the RH camshaft sprocket is approximately at the 11 o'clock position, and the timing mark on the LH camshaft
sprocket is approximately at the 12 o'clock position.
4. Install the special tools on the camshaft.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYJ/~MUS~LEN/20/S...
Engine Front Cover — 4.6L
in this section.
Page 1 of 8
2000 Expedition/Navigator Workshop Manual
Procedure revision date: 03/11/2002
3/27/2010
