Page 1: Repair Manual
REPAIR MANUAL ZT2452A Swisher Mower Co Warrensburg, MO... -
Page 3: Table Of Contents
Table of Contents Belt Routing …………………………………………….……. 4 Wiring Diagram ………………………………………….…. 4 Diagnosing Starting Problems …………..…….…….. 5 Diagnosing PTO Clutch Problems ………………..…..6 Engine Running in Normal Mode ……………………..7 Battery Charging System ………………………………….8 Seat Switch – Ignition Kill Circuit …………………….. 8 Wiring Harness to Engine Plug Connection ………. 9 Drive Control Handle Adjustment …………….……. -
Page 4: Belt Routing
BELT ROUTING Deck belt Part# 3816 Transmission Belt# 4220 WIRING DIAGRAM... -
Page 5: Diagnosing Starting Problems
DIAGNOSING STARTING PROBLEMS You will notice that each position on the ignition switch sets up a certain section of the total wiring diagram. This section is energized by turning the ignition switch to the start position. The final purpose is to start the engine. The main components are the battery and the starter;... -
Page 6: Diagnosing Pto Clutch Problems
DIAGNOSING PTO CLUTCH PROBLEMS The electric clutch can be activated when the ignition switch is in the run position. For the purpose of checking out a problem with the circuit; the engine doesn’t have to be running; the switch just needs to be in the run position. First the battery has to have a full charge. -
Page 7: Engine In Normal Running Mode
ENGINE IN NORMAL RUNNING MODE First the battery was used to start the engine; and later it will be used to engage the PTO; but with the ignition switch in the run position, and the engine Voltage running, the battery is involved in three other Regulator function. -
Page 8: Battery Charging System
BATTERY CHARGING SYSTEM Red wire goes to the engine plug and then on to the positive terminal of the solenoid to keep the battery charged. Easiest way to check if charging is taking place is to measure the DC voltage of the battery before you start the engine. -
Page 9: Wiring Harness To Engine Plug Connection
WIRING HARNESS TO ENGINE PLUG CONNECTION Gray wire goes to carburetor fuel solenoid Green wire goes to oil pressure switch Black wire goes to engine ignition module Red wire goes to engine charging system Green wire goes to hour meter Red wire goes to terminal on solenoid with the positive battery cable. -
Page 10: Drive Control Handle Adjustment
DRIVE CONTROL HANDLE ADJUSTMENT Before any adjustments are made to the drive control arms; put an equal amount of air pressure in both rear wheel. If you push both handles forward as far as they will go and they are straight across from each other; but one side is traveling faster than the other;... -
Page 11: Deck Repairs
DECK REPAIRS A properly adjusted deck should have the blades about 3/8” lower in the front compared to the rear. This adjustment can be made by parking your mower on a level surface and measuring the distance from the blade’s cutting edge to the ground. To adjust, loosen the nuts on these bolts. -
Page 12: Replacement Parts - Quick Reference
REPLACEMENT PARTS QUICK REFERENCE For additional assistance on service Contact Swisher Mower Co., Inc. Phone 1-800-222-8183 Fax 1-660-747-3160 E-mail cust.serv@swisherinc.com...
