DIGITAL VIDEO CAMERA
GR-
DVL315
Please visit our Homepage on the World Wide
Web and answer our Consumer Survey
(in English only):
http://www.jvc-victor.co.jp/english/index-e.html
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No. which is located on the
bottom of cabinet. Retain this information for future reference.
Model No.
Serial No.
CONTENTS
AUTOMATIC
DEMONSTRATION
GETTING STARTED
BASIC RECORDING &
PLAYBACK
BASIC RECORDING ............ 14 – 17
BASIC PLAYBACK .............. 18 – 21
ADVANCED
FEATURES
FOR RECORDING ................ 23 – 30
USING THE MENU FOR
DETAILED ADJUSTMENT ...... 31 – 36
DUBBING ......................... 37 – 38
USING THE REMOTE
CONTROL UNIT ................ 39 – 47
SYSTEM CONNECTIONS ........ 48 – 49
REFERENCES
DETAILS ................................... 51
TROUBLESHOOTING ............ 52 – 56
USER MAINTENANCE ................... 57
INDEX ............................. 58 – 62
CAUTIONS ........................ 63 – 65
TERMS .................................... 66
SPECIFICATIONS ......................... 67
LYT0710-001A
ENGLISH
5
6 – 12
13 – 21
22 – 49
50 – 67
EN
Advertisement
Chapters
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for JVC GR-DVL315
Summary of Contents for JVC GR-DVL315
-
Page 1: Digital Video Camera
DVL315 Please visit our Homepage on the World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/english/index-e.html INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which is located on the bottom of cabinet. Retain this information for future reference. -
Page 2: Safety Precautions
However, live recording and LCD monitor/viewfinder playback are possible anywhere. Use the JVC BN-V408U/V416U/V428U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.) -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS (1) Read these instructions. (2) Keep these instructions. (3) Heed all warnings. (4) Follow all instructions. (5) Do not use this apparatus near water. (6) Clean only with dry cloth. (7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 4: Provided Accessories
• AC Adapter AP-V10U •AAA (R03) Battery x 2 (for remote control unit) •Audio/Video Cable (ø3.5 mini-plug to RCA plug) NOTE: In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. PROVIDED ACCESSORIES •Remote Control Unit RM-V715U... -
Page 5: Automatic Demonstration
AUTOMATIC DEMONSTRATION Automatic Demonstration takes place when “DEMO MODE” is set to “ON” (factory-preset). Available when the Power Switch is set to “ no cassette is in the camcorder. Performing any operation during the demonstration stops the demonstration temporarily. If no operation is performed for more than 1 minute after that, the demonstration will resume. -
Page 6: Table Of Contents
GETTING STARTED GETTING STARTED CONTENTS Power ... 7 – 8 Grip Adjustment ... 9 Viewfinder Adjustment ... 9 Shoulder Strap Attachment ... 9 Tripod Mounting ... 9 Date/Time Settings ... 10 Loading/Unloading A Cassette ... 11 Recording Mode Setting ... 12... -
Page 7: Power
BAT. RELEASE Switch Power Switch CHARGE Lamp AC Adapter To AC outlet To DC connector Battery pack Charging time BN-V408U approx. 1 hr. 30 min. BN-V416U (optional) approx. 2 hrs. BN-V428U (optional) approx. 3 hrs. 20 min. Power This camcorder’s 2-way power supply system lets you choose the most appropriate source of power. -
Page 8: Using Ac Power
AA-V15U AC Power Adapter/Charger for BN-V840U battery pack and only AA-V80U AC Power Adapter/Charger for BN-V856U battery pack. Also, by using the optional JVC VC-VBN856U DC Cord, it will be possible to connect the BN-V840U or BN-V856U battery packs to the camcorder and supply power directly to the camcorder. -
Page 9: Grip Adjustment
Power Zoom Lever Recording Start/ Stop button PAUSE Grip Adjustment Separate the Velcro strip. Pass your right hand through the loop and grasp the grip. Adjust your thumb and fingers through the grip, to easily operate the Recording Start/Stop button and Power Switch and Power Zoom Lever. -
Page 10: Date/Time Settings
MENU/BRIGHT Wheel Power Lamp Lock Button Power Switch Display W I PE FADER OF F PROGR AM AE W. BAL AN E CAMER MANUA SYSTE D I SPL DISPLAY Menu ON SC RE N – LCD / TV DATE / I ME –... -
Page 11: Loading/Unloading A Cassette
Erase protection tab* PUSH HERE Cassette holder cover OPEN/EJECT Switch * To Protect Valuable Recordings ..slide the erase protection tab on the back of the tape in the direction of “SAVE”. This prevents the tape from being recorded over. To record on this tape, slide the tab back to “REC”... -
Page 12: Recording Mode Setting
MENU/BRIGHT Wheel Power Lamp Lock Button Power Switch Display Menu Screen REC MODE – Sub Menu GETTING STARTED Recording Mode Setting Set the tape recording mode depending on your preference. Set the Power Switch to “ the Lock Button located on the switch. The power lamp lights and the camcorder is turned on. -
Page 13: Basic Recording & Playback
BASIC RECORDING & PLAYBACK BASIC RECORDING & PLAYBACK CONTENTS BASIC RECORDING ... 14 – 17 Basic Recording ... 14 Journalistic Shooting ... 15 Self-Recording ... 15 Operation Mode ... 15 Zooming ... 16 Video Light ... 16 Time Code ... 17 BASIC PLAYBACK ... -
Page 14: Basic Recording
Power lamp Power Switch Lock Button Recording Start/Stop Button Display 25 min 90 min 89 min (Now calculating) 0 min 1 min (Blinking) (Blinking) BR I GHT MENU/BRIGHT Wheel 180° 90° PUSH-OPEN Button Tally lamp (lights while recording is in progress) Basic Recording NOTE: You should already have performed the procedures listed... -
Page 15: Journalistic Shooting
Self-Recording To turn on the camcorder, set the Power Switch to any operation mode except “OFF” while pressing down the Lock Button located on the switch. Power Switch Power lamp When the Power Switch is set to “ ”, “ ”... -
Page 16: Zooming
Do not use near flammable or explosive materials. It is recommended that you consult your nearest JVC dealer for replacing the video light. BASIC RECORDING Zooming To produce the zoom in/out effect, or an instantaneous change in image magnification. -
Page 17: Time Code
Time Code During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame). -
Page 18: Still Playback
Lock Button Power Switch Power Zoom Lever (VOL.) Play/Pause Button (4/6) Rewind Button (2) Stop Button (5) Speaker Still Playback: Pauses during playback. 1) Press 4/6 during playback. 2) To resume normal playback, press 4/6 again. If still playback continues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged. -
Page 19: Blank Search
BLANK SEARCH Button Lock Button Power Switch Display BLANK SEARCH Stop Button (5) Blank Search Helps you find where you should start recording in the middle of a tape to avoid time code interruption ( Load a tape ( pg. 11). Set the Power Switch to “... -
Page 20: Connections
Connections These are some basic types of connections. When making the connections, refer also to your VCR and TV instruction manuals. A. Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input connectors NOTE: In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. -
Page 21: Playback
The S-Video cable is optional. Be sure to use the pg. 20). YTU94146A S-Video cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. -
Page 22: Features
ADVANCED FEATURES CONTENTS FOR RECORDING ... 23 – 30 Snapshot ... 23 Night-Alive ... 24 Program AE With Special Effects ... 24 – 25 Fade/Wipe Effects ... 26 – 27 Auto Focus/Manual Focus ... 28 Exposure Control ... 29 Iris Lock ... 29 White Balance Adjustment ... -
Page 23: For Recording
FOR RECORDING SNAPSHOT Button Lock Button Power Switch Display Menu Screen SNAP MODE – P I N–UP FRAME FUL L MUL T I – 4 MUL T I – 9 FRAME PIN-UP Snapshot mode with Pin-Up mode* frame* FULL MULTI-4 Snapshot mode Multi-Analyzer 4 with no frame*... -
Page 24: Night-Alive
NOTES: During Night-Alive, the following functions or settings cannot be activated and its indicator blinks or goes out: • Some modes of “Program AE With Special Effects” ( pg. 24, 25), “Picture Wipe/ Dissolve” ( pg. 26, 27). • “GAIN UP” in CAMERA MENU ( •... - Page 25 SHUTTER 1/60–The shutter speed is fixed at 1/60th of a second. Black bands that usually appear when shooting a TV screen become narrower. 1/100–The shutter speed is fixed at 1/100th of a second. The flickering that occurs when shooting under a fluorescent light or mercury-vapor lamp is reduced.
-
Page 26: Fade/Wipe Effects
Fade/Wipe Effects These effects let you make pro-style scene transitions. Use them to spice up the transition from one scene to the next. You can also vary transitions from scene to scene. IMPORTANT: Some Fade/Wipe Effects cannot be used with certain modes of Program AE with special effects ( pg. - Page 27 Fader And Wipe Menu Menu FADER — WHITE FADER — BLACK FADER — B.W MOSAIC WIPE — CORNER WIPE — WINDOW WIPE — SLIDE WIPE — DOOR WIPE — SCROLL WIPE — SHUTTER DISSOLVE WIPE — CORNER WIPE — WINDOW WIPE —...
-
Page 28: Auto Focus/Manual Focus
Focus detection zone Auto Focus FEATURE: PURPOSE: The camcorder’s Full Range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm (2") to the subject) to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •... -
Page 29: Exposure Control
Exposure Control Manual exposure adjustment is recommended in the following situations: • When shooting using reverse lighting or when the background is too bright. • When shooting on a reflective natural background such as at the beach or when skiing. •... -
Page 30: White Balance Adjustment
White Balance Adjustment A term that refers to the correctness of color reproduction under various lighting. If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional color/tint reproduction. -
Page 31: Using The Menu For Detailed Adjustment
USING MENUS FOR DETAILED ADJUSTMENT MENU/BRIGHT Wheel Lock Button Power Switch Display I PE FADER OF F Menu Screen PROGR AM AE . BAL AN E CAMER MANUA SYSTE REC M D I SPL SOUND MODE ZOOM SNAP MODE GA I N RETUR Sub Menu D I S... -
Page 32: Off
USING MENUS FOR DETAILED ADJUSTMENT Menu Screen Explanations WIPE/FADER PROGRAM AE W.BALANCE REC MODE SOUND 12 BIT MODE 16 BIT ZOOM 400X SNAP MODE GAIN UP AUTO : Factory-preset NOTES: The “ CAMERA” settings are effective when the Power Switch is set to both “ The “... - Page 33 Usually the distance to a subject where the lens is in focus depends on the TELE MACRO zoom magnification. Unless there is a distance more than 1m (3.3 ft.) to the subject, the lens is out of focus at the maximum telephoto setting. When set to “ON”, you can shoot a subject as large as possible at a distance of approx.
- Page 34 USING MENUS FOR DETAILED ADJUSTMENT Menu Screen Explanations (cont.) DEMO MODE CANCEL RESET EXECUTE SCREEN LCD/TV DATE/ TIME AUTO TIME CODE CLOCK ADJ. : Factory-preset NOTES: “ SYSTEM” and “ DISPLAY” functions which are set when the Power Switch is set to “ applied when the Power Switch is set to “...
-
Page 35: For Playback Menu
MENU/BRIGHT Wheel Power Switch Lock Button Recording Start/Stop Button Display V I DEO SOUND MODE SYSTE 12B I T MODE D I SPL SYNC RO MODE – STEREO SOUND 12B I T – SOUND 1 SYNCH – REC M – RETUR BEEP –... -
Page 36: Using Menus For Detailed Adjustment
USING MENUS FOR DETAILED ADJUSTMENT PLAYBACK SOUND During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. According to the menu access explanation on pg. -
Page 37: Dubbing
The S-Video cable is optional. Be sure to use the YTU94146A S-Video cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. The core filter reduces interference. -
Page 38: Dubbing To Or From A Video Unit Equipped With A Dv Connector (Digital Dubbing)
DV IN/OUT connector. When using a DV cable, be sure to use the optional JVC VC-VDV204U DV cable. ” while pressing down the Lock Button located on the switch. -
Page 39: Using The Remote Control Unit
USING THE REMOTE CONTROL UNIT The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. It also makes additional playback functions possible. If you want to perform Random Assemble Editing ( control. - Page 40 USING THE REMOTE CONTROL UNIT RM-V715U (Provided) Buttons Infrared beam transmitting window ZOOM (T/W) Buttons PLAY Button REW Button STOP Button INSERT Button* REC TIME Button* ANIM. Button* START/STOP Button FF Button PAUSE Button A.DUB Button INT. TIME Button* SELF TIMER Button* PAUSE IN Connector MBR SET Button VISS Button*...
-
Page 41: Playback Zoom
Remote sensor Zoom Buttons PLAY STOP Normal playback Press T Playback Zoom FEATURE: PURPOSE: To magnify the recorded image up to 40X at any time during playback. OPERATION: 1) Press PLAY (4) to find the scene of interest. 2) Press the Zoom Buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. -
Page 42: Vcr Code List
VCR CTL BUTTONS VCR BRAND NAME (A) (B) PHILIPS IMPORTANT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with PANASONIC yours or may offer limited functions. NOTES: SANYO SHARP SONY... -
Page 43: Make Connections
Be sure to use the following cables: • YTU94146A S-Video cable. • YTU94154A Editing cable. Consult the JVC Service Center described on the sheet included in the package for details on its availability. Make sure to connect the end with a core filter to the camcorder. - Page 44 USING THE REMOTE CONTROL UNIT Program MODE – – – – : – – ~ T I ME CODE – – : – – TOTAL 0 : 00 Remote sensor PLAY IN/OUT CANCEL RM-V700U (optional) SELECT SCENES Point the remote control at the camcorder’s remote Random Assemble sensor.
- Page 45 Recording Start/Stop Button MODE Random Assemble – – 00 : 2 5 ~ 02 : 05 – – – – Editing Menu – – 07 : 18 ~ 08 : 31 – – – – – – 0 3 : 33 ~ 05 : 53 –...
-
Page 46: For More Accurate Editing
USING THE REMOTE CONTROL UNIT Program 1 MODE – – – – : – – ~ T I ME CODE – – : – – 0 : 00 TOTAL SYNCH – O . 1 Remote sensor NOTES: Before performing actual Random Assemble Editing, do a few Random Assemble Editing trial runs to check whether the value you have input is appropriate or not, and make... -
Page 47: Audio Dubbing
Display Audio Dub Standby mode Speaker Power Switch Remote sensor Stereo microphone PLAY PAUSE STOP A.DUB Audio Dubbing The audio track can be customized only when recorded in the 12-bit mode ( pg. 32). NOTES: Audio Dubbing is not possible on a tape recorded in 16-bit audio, on a tape recorded in the LP mode or on a blank portion of a tape. -
Page 48: System Connections
DV connector-equipped capture board. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC, or use the DV cable provided with the capture board. -
Page 49: Connection To A Video Unit With A Dv Connector
DV connector, the image will take on an effect similar to a colored mosaic pattern or it will become black. Also refer to the instruction manuals of the connected units. When using a DV cable, be sure to use the optional JVC VC-VDV204U DV cable. pg. 38), which ” while... -
Page 50: References
REFERENCES CONTENTS DETAILS ... 51 TROUBLESHOOTING ... 52 – 56 USER MAINTENANCE ... 57 INDEX ... 58 – 62 Controls, Connectors And Indicators ... 58 – 59 Indications ... 60 – 62 CAUTIONS ... 63 – 65 TERMS ... 66 SPECIFICATIONS ... -
Page 51: Details
DETAILS I T E M S ➪ ❍ Perform charging where the temperature is between 10°C and 35°C Power pg. 7) ❍ Charging times are for a fully discharged battery pack. ❍ Charging time varies according to the ambient temperature and the ❍... -
Page 52: Troubleshooting
If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Adapter, etc.) and wait a few minutes;... - Page 53 SYMPTOM 9. The image taken using Snapshot is too dark. 10. The image taken using Snapshot is too bright. 11. Digital Zoom does not work. 12. The Black & White Fader does not work. 13. The Dissolve function does not work. 14.
- Page 54 SYMPTOM 15. The picture wipe function does not work. 16. Scene transition does not go as expected. 17. The Video Echo mode does not work. 18. Even when Slow Shutter is not selected, the image looks like it is activated. 19.
- Page 55 LCD monitor become dark. Consult your nearest JVC dealer. 26. •The light used to illuminate the LCD monitor causes it to become hot. 27. •This may occur when the surface or the edge of the LCD monitor is pressed.
-
Page 56: Troubleshooting
If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. 38. •To protect the battery, it is recommended to charge it in places with a temperature of 10°C to 35°C (50°F to 95°F) (... -
Page 57: User Maintenance
USER MAINTENANCE After Use Turn off the camcorder. Slide and hold OPEN/EJECT in the direction of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically. Remove the cassette. Press “PUSH HERE” to close the cassette holder. •Once the cassette holder is closed, it recedes automatically. -
Page 58: Index
INDEX Controls, Connectors And Indicators & 3 4 5 6 7... -
Page 59: Video Light
Controls Monitor Open Button [PUSH OPEN] ... Diopter Adjustment Control ... Battery Release Switch [BAT. RELEASE] ... •MENU Wheel [+, –, PUSH] ... •LCD Monitor BRIGHT (Brightness) Control [+, –] ... Snapshot Button [SNAPSHOT] ... •Power Zoom Lever [T/W] ... •Speaker Volume Control [VOL.] ... -
Page 60: Lcd Monitor/Viewfinder Indications During Recording
LCD Monitor/Viewfinder Indications During Recording Appears when the Power Switch is set to “ • : Appears when Night-Alive is engaged. • : Appears when “GAIN UP” is set to “AUTO” and the shutter speed is being automatically adjusted. Appears when the white balance is adjusted. •... -
Page 61: Lcd Monitor/Viewfinder Indications During Playback
LCD Monitor/Viewfinder Indications During Playback Displays the sound mode. Displays the Blank Search mode. Displays the tape speed. Appears while a tape is running. : Playback 3 : Fast-Forward/Shuttle search 2 : Rewind/Shuttle search : Pause 64 : Forward slow-motion 16 : Reverse slow-motion : Audio Dubbing 6e : Audio Dubbing Pause... -
Page 62: Index
Appears when the date/time is not set. Appears when the built-in clock battery runs out and the previously set date/time is erased. Consult your nearest JVC dealer for replacement. Appears for 5 seconds after power is turned on if the lens cap is attached. -
Page 63: Cautions
In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Plug adapter Video Light DANGER The video light can become extremely hot. -
Page 64: Main Unit
In order to maintain a clear picture at all times, periodic check-ups are recommended after using the unit for about 1,000 hours. For periodic check-ups please consult your nearest JVC dealer. (cont.) - Page 65 Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from function- ing properly.
-
Page 66: Terms
AC Adapter ... Audio Dubbing ... Auto Date ... Auto Focus ... Auto Shut off ... Backlight Compensation ... Battery Low ... Battery Pack ... Beep ... Blank Search ... Brighten The LCD Monitor ... Channels (Left/Right) ... Charge The Battery Pack ... Cinema ... -
Page 67: Specifications
SPECIFICATIONS For General Power supply Power consumption LCD monitor off, viewfinder on LCD monitor on, viewfinder off Video light Dimensions (W x H x D) Weight Operating temperature Operating humidity Storage temperature Pickup Lens Filter diameter LCD monitor Viewfinder Speaker For Digital Video Camera Format Signal format... - Page 68 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan COPYRIGHT© 2001 VICTOR COMPANY OF JAPAN, LTD. 1200HOV...
