- Page 1 Cordless Serial Adapter User Guide Cordless Serial Adapter User Guide Revision 0.95 September 22, 2003 September 22, 2003 September 22, 2003 September 22, 2003 Copyright © 2002 Socket Communications, Inc. Document#: 6410-00000 A CONFIDENTIAL Revision 0.9...
- Page 2 Socket Communications, Inc. 37400 Central Court Newark, CA 94560 You are also welcome to call Socket Communications Inc. at (510) 744-2700, or you may FAX inquiries to (510) 744-2727. Other than the above, Socket Communications, Inc. can assume no responsibility for anything resulting from the application of information contained in this manual.
- Page 3 User Guide Regulatory Compliance The Socket Bluetooth module is designed to be compliant with the rules and regulations in locations where they are sold and will be labeled as required. This product is type approved — users are not required to obtain license or authorization before using.
- Page 4 Products intended for sale within the European Union are marked with a CEMark which indicates compliance to applicable Directives and European Normes (EN), as follows. Amendments to these Directives or ENs are included: Normes (EN), as follows: September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page iii Document#: 6410-00000 A CONFIDENTIAL...
- Page 5 Control Equipment, Part 4: Electrical Fast Transients Requirements. EN 60 950 + Amd 1 + Amd 2 – Safety of Information Technology Equipment Including Business Equipment. September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page iv Document#: 6410-00000 A CONFIDENTIAL...
- Page 6 Cordless Serial Adapter User Guide Revision Table Revision Date Comments 0.95 10-Sep-2003 C. Ader Extract user guide from specification September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page v Document#: 6410-00000 A CONFIDENTIAL Revision 0.9...
-
Page 7: Table Of Contents
9.1 Basic Agency Certifications ......................7 9.2 Additional Certifications and Logos ....................7 Packaging ............................8 10.1 Accessory Item(s) to be included in final package ................8 September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page vi Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... - Page 8 Cordless Serial Adapter User Guide September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page vii Document#: 6410-00000 A CONFIDENTIAL Revision 0.9...
- Page 9 User Guide List of Tables Table 1: DC Voltage Levels ......................... 2 Table 2: Power Consumption........................2 Table 3: DTE Pin Assignment ........................3 September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page viii Document#: 6410-00000 A CONFIDENTIAL Revision 0.9...
-
Page 10: Introduction
If the Adapter is in ‘acceptor’ mode, it will be a slave and will not request any role reversal. • Default baud rate 19,200 • Baud rates configurable from 9,600 – 230,000 September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 1 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 11: Operational Specifications
Connected standby (RS232 transceiver off) 53.0 Waiting to connect 39.1 55.9 Waiting to connect standby (RS232 transceiver off) 19.1 Table 2: Power Consumption September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 2 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 12: Hardware Interface
If acting as ACCEPTOR connectable. If acting as INITIATOR waiting for local host to issue command to initiate the connection. • LED flashing three times every two seconds CSA is connected. September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 3 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 13: Hardware Interface Protocol
When module pin 14 is low the module will send any available data to the local host. When this pin is high the module will not send data to the local host. September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 4 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 14: Mechanical Specifications
Physical repair is allowed only to the connector area for proper insertion into a DB9 connector. Conditions: No degradation of functional performance. No loose internal components. September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 5 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 15: Vibration
No erroneous operation at ±8kV • No destruction at ±10kV 6.5.3 Characteristics of electric static discharge generator Energy Accumulation Capacitance (Cs+Cd): 150pF±10% Discharge Resistance (Rd): 330ohm±10% September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 6 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 16: Software Functionality
Bluetooth Brand Logo as authorized by complying with the Bluetooth SIG Certification. • The product must pass the “Bluetooth End Product” type certification. September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 7 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9... -
Page 17: Packaging
10 Packaging 10.1 Accessory Item(s) to be included in final package • US AC power supply (includes 2 European and one Australian power connectors) September 22, 2003 Copyright © 2003, Socket Communications, Inc. Page 8 Document#: 6410-00000 A CONFIDENTIAL Revision 0.9...
