Relay A – DB37M
Pin Function
1 Relay 1A
2 Relay 2A
3 Relay 3A
4 Relay 4A
5 Ground
6 Relay 5A
7 Relay 6A
8 Relay 7A
9 Relay 8A
10 Ground
11 Relay 9A
12 Relay 10A
13 Relay 11A
14 Relay 12A
15 NC TxData
16 Relay 13A
17 Relay 14A
18 Relay 15A
19 Relay 16A
If your automation system can read text cues directly, the cue serial stream is available
from pins 15 and 10. The NC TxData pin is RS-232 data with no flow control or
handshaking. By default, the baud rate is set to 9600 bps, eight data bits, no parity, and
one stop bit.
The parts kit included with your receiver will include two mating DB-37 connectors with
shells. Full electrical specifications for the relay closures can be found in the XDS PRO4P
User's Guide.

4 Verification of Functionality

Once all of the connections have been made, you may connect AC power to the receiver and begin
verification of the receiver functionality.
4.1 Verify the receiver is tuned and locked to the network carrier
Once the satellite is properly connected and the receiver is powered up the receiver is
configured from the factory to tune and lock to your network's carrier. Please verify as
follows:
1327 R830002-1062
Rev A
Pin Function
20 Relay 1B
21 Relay 2B
22 Relay 3B
23 Relay 4B
24 Ground
25 Relay 5B
26 Relay 6B
27 Relay 7B
28 Relay 8B
29 Relay 9B
30 Relay 10B
31 Relay 11B
32 Relay 12B
33 Ground
34 Relay 13B
35 Relay 14B
36 Relay 15B
37 Relay 16B
NA NA
XDS PRO4P Quick Start Guide
Relay B – DB37M
Pin Function
1 Relay 1A
2 Relay 2A
3 Relay 3A
4 Relay 4A
5 Ground
6 Relay 5A
7 Relay 6A
8 Relay 7A
9 Relay 8A
10 Ground
11 Relay 9A
12 Relay 10A
13 Relay 11A
14 Relay 12A
15 Ground
16 Relay 13A
17 Relay 14A
18 Relay 15A
19 Relay 16A
Page 4 of 11
Pin Function
20 Relay 1B
21 Relay 2B
22 Relay 3B
23 Relay 4B
24 Ground
25 Relay 5B
26 Relay 6B
27 Relay 7B
28 Relay 8B
29 Relay 9B
30 Relay 10B
31 Relay 11B
32 Relay 12B
33 Ground
34 Relay 13B
35 Relay 14B
36 Relay 15B
37 Relay 16B
NA NA
5/6/2010
