3.3 Connecting the Audio Ports

The analog audio outputs of the PRO4P receiver is routed through the DB-9 connector
labeled Audio-A through Audio-D on the rear panel. The table below details the wiring
pin out for the ports:
Your receiver will be delivered with a parts kit that will include four mating DB-9
connectors with shells. Please see the XDSPRO4P User's Guide for detailed
specifications on the audio output.
3.4 Relay Closures
The receiver has two DB-37 connectors labeled Relay-A and Relay-B on the rear panel.
These connectors contain sixteen relay/contact closures that can drive external
automation systems. The tables below detail the pin out for the ports:
1327 R830002-1062
Rev A
Pin
1
2
3
4
5
6
7
8
9
(*) - These additional output pins are provided for StarGuide receiver
compatibility.
Signal
L OUT+
Ground
L OUT+ (*)
Ground
R OUT+
L OUT-
Ground (*)
L OUT- (*)
R OUT-
XDS PRO4P Quick Start Guide
Page 3 of 11
5/6/2010
