READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting Any service or maintenance procedure to your Clarke
American Sanders machine could result in injury to you or to other personnel; damage to the machine
or to other property could occur as well. You must have training in the operation of this machine
before using it. If you or your operator(s) cannot read English, have this manual explained fully before
attempting to operate this machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente
antes de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: Clarke
, 2100 Highway 265, Springdale, Arkansas 72764.
®
Form No. 70102B 1/03
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Clarke Super E Edger
Summary of Contents for Clarke Super E Edger
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting Any service or maintenance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
Pad ..................9 Pad Driver ................9 AssemblyDrawing #1 ............... 10 Assembly Parts List #1 .............. 11 Assembly Drawing #2 ............... 12 Assembly Parts List #2 .............. 13 Wiring Diagram ................. 14 American Sanders Super E Operator's Manual Page 2 ® Clarke... -
Page 3: Operator Safety Instructions
Failure to read the Owner's Manual prior to operating or attempting any service or mainte- nance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it. - Page 4 Maintenance and repairs performed by unauthorized personnel could result in damage or injury. Maintenance and repairs performed by unauthorized personnel will void your warranty. Servicing of this unit must always be referred to an authorized Clarke American Sanders distributor. CAUTION: Use of this machine to climb on could result in injury or damage.
-
Page 5: Machine Specifications
Model Super E Edger Specifications Specifications Model 07068C Super E 115V 07074C Super E 240V Voltage/Amperage/Hz 115V / 12 /60 Hz 240V/6/50 Hz Motor 1 HP Power Cord 50' 14-3 Gray Rubber Jacketed Pad Driver System Precision Ground 5mm Joined Belt... -
Page 6: Sanding Cuts And Sandpaper
120 grit For final sanding of certain conifers. 945605/500 150 grit For final sanding of certain conifers where a 945606/300 smooth surface is desired for surface roughening between coats of finish. American Sanders Super E Operator's Manual ® Page 6 Clarke... -
Page 7: Machine Set-Up
(Figure 3) 3. With the machine in the reclined position firmly grasp both handles and flip the control switch to the "ON" position. Figure 3 American Sanders Super E Operator's Manual ® Clarke Page 7... -
Page 8: Operating Instructions
Condition - Pad creates a ridge on the tip of the pad: Rotate both stems counter clockwise, tighten locknuts and test. Repeat procedure until condition is corrected. Use only 1/8 rotation for each attempt. Figure 4 American Sanders Super E Operator's Manual Page 8 Clarke ®... -
Page 9: Belt Tension
"dress in" by sanding the elastomer on the pad. Continue sanding until the entire surface of the elastomer shows signs of sanding. As in operation of the machine, take precautions performing this proce- dure. American Sanders Super E Operator's Manual ® Clarke Page 9... -
Page 10: Assemblydrawing #1
Model Super E Edger Drawing #1 1/03 American Sanders Super E Operator's Manual Page 10 Clarke ®... -
Page 11: Assembly Parts List #1
Model Super E Edger Parts List #1 1/03 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 920196 Nut ½-13 Jam 962555 Screw 0 x Ft. St. 52132A Assembly, Caster 70486A Name Plate 66199A Pulley, Motor 47394A Switch 980646 Washer ¼... -
Page 12: Assembly Drawing #2
Model Super E Edger Drawing #2 1/03 American Sanders Super E Operator's Manual Page 12 Clarke ®... -
Page 13: Assembly Parts List #2
Model Super E Edger Parts List #2 3/01 Ref. Part No. Description Qty. 22901A Extension 13" 51029A Belt-V, 5mm 63933A Guard Belt 13" 85313C Screw 6-32 x ref. 84241A Screw -18 x ½ F1 66965A Retainer, Abrasive 53534A Elastomer 5"... -
Page 14: Wiring Diagram 1/96
Model Super E Edger Wiring Diagram 1/96 American Sanders Super E Operator's Manual ® Page 14 Clarke... - Page 15 ALTO Nederland B.V. Vianen (770) 973-5225 Stuartweg 4C NL-4131 NJ Vianen +31 347 324000 ® Clarke Clarke American Sanders ALTO Sverige AB, Molndal (Sweden) A.L. Cook Aminogatan 18 Customer Service Headquarters and Factory Box 4029 2100 Highway 265 S-431 04 Molndal...
- Page 16 (b). Return the product to the nearest Clarke American Sanders repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (c). Clarke American Sanders will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
