- Page 1 Electronic Service Manuals This electronic document is provided as a service to our customers. We do not create the contents of the information contained in this docu- ment. Should you have detailed questions pertaining to the information contained in this document, you may contact Michco, or the manufac- turer which provided the original information in this electronic deliver- able.
- Page 2 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 3: Table Of Contents
Products in such environments. The Manufacturer disclaims any responsibility to advise purchasers of any specifi c requirements that may be applicable to the use of the Products in such environments. ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke... -
Page 4: Operator Safety Instructions
DANGER: Failure to read the Owner’s Manual prior to operating or servicing your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it. -
Page 5: Introduction And Machine Specifi Cations
ENGLISH Introduction & Machine Specifi cations Model EZ Sand-HDTR Code Number 07163A Voltage/Frequency 115V/60 Hz Amperage (A) Motors (3) 1/3 hp each Pad Size (3) 7” O.D. each Power Cable 40’ 12-3 Ga Gray Rubber Jacketed Orbits Per Minute 5000 ea. motor Orbit Dia. -
Page 6: Machine Transportation
fi rm grip and proper lifting technique. Get assistance if necessary. 6. Secure machine to prevent movement in cargo area. Figure 1A Figure 2 ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR - 5 - Clarke... -
Page 7: Machine Set-Up
Never put yourself or let others be in a position to get injured if the machine should tip or fall while replacing the pad or changing abrasive. Figure 4A ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke... - Page 8 NOTE: For best results, empty frequently. Follow all warnings posted in this manual and on the dust bag. Figure 6 ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR - 7 - Clarke...
-
Page 9: Operating Instructions
To prevent damage to the fl ooring and to Figure 8 reduce swirling, keep the machine in motion while the motor is running. NOTE: For sanding cuts and sandpaper, see page 10. ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke... -
Page 10: Troubleshooting
The latches have loosened up. To tighten latches, loosen the lock to base machine. nut, screw in the latch hook and then tighten the lock nut. ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR - 9 - Clarke... -
Page 11: Sanding Cuts And Sandpaper
54078A 120 grit For fi nal sanding of certain hardwoods and conifers where a smooth surface is desired. 53886A For leveling after initial fi nish coat. ® -10- American Sanders Operator's Manual (EN) - EZ Sand - HDTR Clarke... - Page 12 ENGLISH ® American Sanders Operator's Manual (EN) - EZ Sand - HDTR - 11 - Clarke...
- Page 13 Este manual contiene información importante acerca del uso y la seguridad de la máquina. Si no lee el manual antes de utilizar su máquina Clarke American Sanders o de intentar realizar los procedimientos de reparación o mantenimiento de la misma, usted o el resto del personal podrían sufrir lesiones; asimismo, podrían producirse daños a la máquina o a otras propiedades.
-
Page 14: Instrucciones De Seguridad Para El Operador
PELIGRO: Si no lee el manual de instrucciones antes de operar, reparar o realizar el mantenimiento de su máquina Clarke American Sanders, el resultado puede ser que usted o el resto del personal sufra lesiones. Asimismo, pueden producirse daños a la máquina o a otras propiedades. -
Page 15: Introducción Y Especifi Caciones De La Máquina
40’ 12-3 Cable de alimentación con revestimiento de goma cada motor 5000 Giros por minuto pulg. Diámetro de giro libras Peso del envío Ruido (dBA) Vibración (m/s/s) ® -14- American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke... -
Page 16: Transporte De La Máquina
fi rmeza y utilice la técnica de elevación adecuada. De ser necesario, solicite ayuda. Figura 1A 6. Asegure la máquina para evitar movimientos en el área de carga. Fgiura 2 ® American Sanders Manual del operador (ES) - EZ Sand - HDTR - 15 - Clarke... -
Page 17: Instalación De La Máquina
(ni deje que otras personas lo hagan) en una posición en la que pueda lesionarse si la máquina se inclina o cae. Figura 4A ® -16- American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke... - Page 18 NOTA: Para lograr los mejores resultados, vacíe frecuent- Figura 6 emente. Siga todas las advertencias incluidas en el manual y en la bolsa de polvo. ® American Sanders Manual del operador (ES) - EZ Sand - HDTR - 17 - Clarke...
-
Page 19: Instrucciones De Funcionamiento
PRECAUCIÓN: para evitar daños al piso y reducir los remolinos, mantenga la máquina en movimiento mientras el motor esté funcionando. NOTA: para cortes de lija y papel de lija consulte la página 20. ® -18- American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke... -
Page 20: Resolución De Problemas
Para ajustar los seguros, afl oje a la base de la máquina. la tuerca de seguridad, atornille el gancho del seguro y por último ajuste la tuerca de seguridad. ® American Sanders Manual del operador (ES) - EZ Sand - HDTR - 19 - Clarke... -
Page 21: Cortes De Lija Y Papel De Lija
Para el lijado fi nal de ciertas maderas duras y malla 120 granos coníferas si se desea obtener una superfi cie lisa. 53886A Para nivelar después del capas de acabado intial. ® -20- American Sanders Manual del operador (ES) - EZ Sand - HDTR Clarke... - Page 22 ESPAÑOL ® American Sanders Manual del operador (ES) - EZ Sand - HDTR - 21 - Clarke...
- Page 23 Ce Manuel contient des informations importantes concernant l’utilisation et le fonctionnement de cette machine dans des conditions de sécurité optimales. La non-lecture de ce manuel avant d’utiliser ou d’entretenir votre machine Clarke American Sanders risque de provoquer un accident ou d’endommager la machine ou son environnement. Vous devez avoir été formé...
-
Page 24: Consignes De Sécurité
ATTENTION apparaissant sur l’appareil ou dans votre manuel d’utilisation. DANGER: Si vous ne lisez pas le manuel d’utilisation avant d’utiliser ou réparer votre appareil Clarke, vous risquez de vous blesser ainsi que d’autres personnes. Vous risquez également d’endommager l’appareil et de causer divers dommages matériels. -
Page 25: Introduction Et Spécifi Cations De L'appareil
Câble d’alimentation gaine grise en caoutchouc 5000 pour chaque moteur Tours par minute 1/4 pouces Diamètre de rotation 110 lbs. Poids à l’expédition Bruit (dBA) Vibrations (m/s/s) ® -24- American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke... -
Page 26: Transport De L'appareil
Demandez de l’aide si nécessaire. Figure 1A 6. Attachez l’appareil pour éviter qu’il ne bouge sur le véhicule de transport. Figure 2 ® American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR - 25 - Clarke... -
Page 27: Préparation De L'appareil
à basculer ou se renverser. Figure 4A ® -26- American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke... - Page 28 NOTE: Pour obtenir les meilleurs résultats, vider fréquemment le sac. Respecter toutes les mises en garde indiquées dans le présent manuel et sur le sac à poussières. Figure 6 ® American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR - 27 - Clarke...
-
Page 29: Utilisation De L'appareil
REMARQUE : Pour avoir des conseils sur le ponçage et le papier Figure 8 abrasif, voir en page 30. ® -28- American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke... -
Page 30: Dépannage
Le verrou n’est pas enfoncé. Enfoncez le verrou avant d’actionner la manette de commande. Interrupteur défectueux, Contactez un détaillant Clarke agréé. mauvaise connexion. Le moteur démarre mal ou Tension faible à cause d’une Utilisez une rallonge électrique fonctionne trop lentement. -
Page 31: Ponçage Et Papier Abrasif
120 grains bois franc et de bois mou lorsqu’une surface lisse 53886A est désirée. Pour le nivellement après l’application d’une couche de produit de fi nition. ® -30- American Sanders Manuel de l’utilisateur (FR) - EZ Sand - HDTR Clarke... - Page 32 EZ Sand - HDTR Section II Parts and Service Manual (71358A)
-
Page 33: Section Ii Parts And Service Manual Assembly Drawing #1
11154A Disc (incl. items 7,8,9,14) NOTE: # indicates a change has been made since the last publication of this manual. *NOTE: Item 25 will repair one complete machine. ® -32- American Sanders Operator's Manual - EZ Sand - HDTR Clarke... -
Page 34: Assembly Drawing #2
(attaches item 16 to item 15) NOTE: # indicates a change has been made since the NOTE: Items 17 & 31 are used for attaching ground wires. last publication of this manual. ® American Sanders Operator's Manual - EZ Sand - HDTR - 33 Clarke... -
Page 35: Assembly Drawing #3
61801A Collar, Handle Lock 40540A Cordset 80318A Screw, 1/2-13 x 1 911248 Plug 29895A Weight, Iron 911461 Connector L5-15R 40931A Cord, Pigtail 70823A Label, HDTR 70175A Tag, Warning ® -34- American Sanders Operator's Manual - EZ Sand - HDTR Clarke... -
Page 36: Electrical Schematics
EZ Sand - HDTR Electrical Schematic 3/07 ® American Sanders Operator's Manual - EZ Sand - HDTR - 35 - Clarke... - Page 37 14600 21st Avenue North Plymouth, MN 55447-3408 www.clarkeus.com Phone: 800-253-0367 Fax: 800-825-2753 ©2010 Nilfi sk-Advance, Inc. A Nilfi sk-Advance Brand...
