Better Music Builder KTV/Portable PS-308 Owner's Manual

Ktv/portable series coaxial loudspeakers pro-line coaxial driver

Advertisement

Quick Links

®
Passionate about Music
Better Music Builder is a leader in the Audio and
Karaoke equipment industry. We are committed
to offering you the high quality audio product.
Unlike any others brand, we deliver the best cost
and value to you directly. We may update our
manual on short notice, so we highly recommend
downloading the latest update information includ-
ing operation manuals, installation instruction,
and other new technologies updates, etc. from
our website www.BetterMusicBuilder.com.
PASSIVE/NON-POWERED
PS-308
PASSIVE/NON-POWERED
KTV-Series
PRO-Line Coaxial Driver
8-inch Woofer
10-inch Woofer
ACTIVE/POWERED
PS-308A
ACTIVE/POWERED
KTV-Series
PRO-Line Coaxial Driver
8-inch Woofer
10-inch Woofer
®
PS-312
PASSIVE/NON-POWERED
PS-310
KTV-Series
PRO-Line Coaxial Driver
Better Music Builder
12-inch Woofer
PS-312A
ACTIVE/POWERED
PS-310A
KTV-Series
PRO-Line Coaxial Driver
Better Music Builder
12-inch Woofer
OWNER'S MANUAL
KTV/PORTABLE SERIES
P R O - L i n e C o a x i a l D r i v e r
This is a portable speaker series with three sizes
(i.e. 8-inch, 10-inch and 12-inch). Speaker of
each size has both active/powered and
passive/non-powered speakers. The frame of
these speakers are made of plastic with high
portability. Unlike other speakers, our portable
speaker series use coaxial speaker technology
to maximize the sound quality.
Coaxial Loudspeaker
PREMIUM GRADE
PS-308
PS-310
PS-312
SUPERIOR GRADE
PS-308A
KTV-Series
PRO-Line Coaxial Driver
Better Music Builder
PS-310A
PS-312A
KTV-Series
PRO-Line Coaxial Driver
Better Music Builder
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual care-
fully before operating it. Please retain
this manual for future reference.
w w w . B e t t e r M u s i c B u i l d e r . c o m
8-inch PASSIVE
10-inch PASSIVE
12-inch PASSIVE
8-inch ACTIVE
10-inch ACTIVE
12-inch ACTIVE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTV/Portable PS-308 and is the answer not in the manual?

Questions and answers

Summary of Contents for Better Music Builder KTV/Portable PS-308

  • Page 1 Passionate about Music KTV/PORTABLE SERIES Better Music Builder is a leader in the Audio and Karaoke equipment industry. We are committed P R O - L i n e C o a x i a l D r i v e r to offering you the high quality audio product.
  • Page 2: Table Of Contents

    ............................... Intro SAFETY INSTRUCTIONS ..........................Safety SYSTEM APPLICATIONS ..........................Applications • Connecting the Speaker for Model PS-308, PS-308A, PS-310 and PS-310A ........ • Connecting the Speaker for Model PS-312 and PS-312A ............... VARIOUS SYSTEM APPLICATIONS ....................... Applications • High Portability ................................
  • Page 3: Introduction

    INTRODUCTION REAR SPEAKER PROFILE Intro Better Music Builder engineering team created a new high performance product line called the KTV/Portable Pro-Line Series. We use the higher quality of coaxial driver to COMPRESSION DRIVER HF ED3001A perform precise clarity and reliability on these portable speakers.
  • Page 4: Safety Instructions

    INSIDE REFER SERVICING TO QUALIFIED PERSONNEL CAUTIONS FOR INSTALLATION REFERENCE CONNECT TO CHANNEL 2 TO CHANNEL 1 The engineering team of Better Music Builder is committed to SPEAKER SPEAKER designing safe audio products. Speakon Outputs The upper Speakon jack has both Channel 1 and...
  • Page 5: Connecting The Speaker For Model Ps-308, Ps-308A, Ps-310 And Ps-310A

    CONNECTING THE SPEAKER FOR MODEL PS-308, PS-308A, PS-310 and PS-310A Please order the speakon cable for the active/powdered You can hook up the active/powered speaker with the NOTE passive/non-powered speakers, so a power amplifier is not speaker (including PS-308A, PS-310A and PS-312A) inside needed for connection.
  • Page 6: Connecting The Speaker For Model Ps-312 And Ps-312A

    Two input sources such as MP3 (including the package and the passive/non-powdered speakers iPhone/iPod) and dynamic microphone can be added to the (including PS-308, PS-310 and PS-312) from our authorized active/powered speaker. dealers. The speakon cables are available in 20 feet, 30 feet and 50 feet.
  • Page 7: Various System Applications

    K T V- S e r i e s PRO-Line Coaxial Driver K T V- S e r i e s Better Music Builder PRO-Line Coaxial Driver Better Music Builder for rental and any purposes. AUDIO...
  • Page 8: Controls And Functions

    CONTROLS AND FUNCTIONS Speaker FRONT PANEL: features are available for active/powered model PS-308A and PS-310A ONLY. LINE VOLUME CONTROL for the LINE LEVEL INPUT (10) LEFT and (11) RIGHT: Increase volume by rotating clockwise and decrease volume by rotating counter-clockwise. Attention: Please first adjust the volume to minimum.
  • Page 9: Front & Rear Panel Features For Active/Powered Model Ps-312A

    KTV-Series SIGNAL INDICATOR PRO-Line Coaxial Driver Better Music Builder PS-312A Front View LINE LEVEL INPUT TERMINAL RIGHT: Transfer the signal from this TERMINAL to SIGNAL OUTPUT TERMINAL (7) for output after it is controlled by LINE VOLUME CONTROL (8).
  • Page 10: Rear Panel Features For Passive/Non-Powered Model Ps-308 And Ps-310

    CONTROLS AND FUNCTIONS REAR PANEL: features are available for passive/non-powered model PS-308 and PS-310 ONLY. ® Better Music Builder ® PS-308 [Coaxial Driver] Power Tating: KTV-SERIES 150~300 Watts Impedance: 4~8 Ohm INPUT Sensitivity: OUTPUT 90 dB (1m/1Wd) Frequency Response: 65Hz~15kHz 3 6 0 1 0 0 1 0 4 1 9 0 Serial No.:...
  • Page 11: System Setup Guidelines

    SYSTEM SETUP GUIDELINES How to Adjust the Wall Mount (SL-001) Set Up INSTALLATION SETUP Adjust the wall mount left/right at 180 degree and up/down at 90 degree for rotation at different angles to achieve the 1. MOUNTING THE SPEAKER TO THE WALL best sound effect.
  • Page 12: Placing The Speaker On The Floor To Monitor Singing

    This portable series speaker has both active/powered (PS-308A, PS-310A & PS-312A) and passive/non-powered (PS-308, PS-310 & PS-312) models. K T V- S e r i e s...
  • Page 13: Troubleshooting

    TROUBLESHOOTING Troubleshooting 1. SYMPTOM: NO SOUND ON ACTIVE/POWERED Remedy: SPEAKER. A. Check the connection between the microphone and the Probable cause: active/powered speaker. Make sure that they are connected properly. For condense microphone, it doesn't The A/C power of the active/powered speaker is not work with the active/powered speaker.
  • Page 14: Physical Dimensions

    42.7×52×36.8 cm 49×61×41.9 cm (WXHXD) This dimension diagram are all the This dimension diagram are all WIDTH WIDTH same in these models: PS-308, the same in these models: PS-310, PS-308A and PS-310A. PS-312 and PS-312A. HEIGHT HEIGHT Better Music Builder...
  • Page 15: Final Words To User

    Again, we must thank you for choosing Better Music Builder product. We hope you can make the best use of the machine and enjoy it for years to come. If you have any questions regarding our product, please feel free to contact us at w w w.B et terM usicB uil d er.com.
  • Page 16: Warranty

    WARRANTY Warranty ONE-YEAR LIMITED WARRANTY FOR HOME USE ADDITIONAL NOTES: EQUIPMENT 1. Limited warranty for home use equipment is only valid in Our one-year warranty covers both parts and labors. The North America. warranty becomes effective from the date of your purchase for one year.
  • Page 17: Agency Regulatory Notices

    AGENCY REGULATORY NOTICES Notices Federal Communications Commission Notice your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a These limits are designed to provide reasonable protection manner that protects human health and the environment. For against harmful interference in a residential installation.
  • Page 18: Contact Information

    CONTACT INFORMATION Contact Us MAILING ADDRESS B et ter M usic Builder 2930 0 Kohoutek Wa y #150 Union Cit y, CA 94587 U.S.A . TELEPHONE NUMBERS USA Re gion USA Toll Fre e: 1-80 0 -318-2218 S ales & M arketing: 510 - 477-9955 Customer S er vice: 510 - 477-9955 FAX NUMBERS USA Re gion...
  • Page 19 MAINTENANCE NOTE...
  • Page 20 ANTENNA-B SPEAKER IS SOLD IN UNIT (NOT IN PAIR) SPEAKER IS SOLD IN UNIT (NOT IN PAIR) 360100118960 Printed on 100% Recycled Paper Code: 20100501 Comments E-mail to info@bettermusicbuilder.com Copyright © 2010 Better Music Builder. All rights reserved. Legal trademark.
