CS-612 G3 (PVC PLYWOOD)
ELEGANT FINISH
CS-812 G3 (BLACK COLOR PIANO WOOD)
®
Passionate about Music
OWNER'S MANUAL
CLASSIC SERIES
PRO - Line Loudspeaker
3-Way Loudspeaker
PREMIUM GRADE
CS-600 G3
3-Way Loudspeaker
SUPERIOR GRADE
CS-612 G3
CS-812 G3
CS-600 G3 (PIANO WOOD)
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
w w w. B e t t e rM usi c B ui l d e r.c o m
110421
10-inch WOOFER
12-inch WOOFER
12-inch WOOFER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic CS-600 G3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Better Music Builder Classic CS-600 G3

  • Page 1 CS-612 G3 12-inch WOOFER CS-812 G3 12-inch WOOFER CS-612 G3 (PVC PLYWOOD) CS-600 G3 (PIANO WOOD) ELEGANT FINISH CS-812 G3 (BLACK COLOR PIANO WOOD) Thank you for purchasing this unit. To make full and effective use of this unit, please read this Owner's Manual carefully before operating it.
  • Page 2: Table Of Contents

    CONTROLS AND FUNCTIONS ........................Speaker • Front & Rear Panel Features for 3-Way Full Range Speaker Model CS-600 G3......• Front & Rear Panel Features for 3-Way Full Range Speaker Model CS-612 G3 / CS-812 G3..SYSTEM SETUP GUIDELINES ........................
  • Page 3: Introduction

    INTRODUCTION SYSTEM FEATURES Intro Features Better Music Builder is excited to introduce the next genera- CS-600 G3 (Premium Grade) tion of the Classic Series speaker, the CS-812 G3. • 3-Way Full Range Piano Wood Speaker The high performance speaker uses dynamic audio •...
  • Page 4: Safety Instructions

    Therefore, disconnect the electric plug from the outlet, and have the please visit our website at BetterMusicBuilder.com frequently device inspected by qualified Better Music Builder service to find out the most updated information, corrections on errors personnel.
  • Page 5: Getting Started

    For speaker connections, use a high-quality speaker wire with polarity coding. The side of the wire with a ridge or other coding is usually considered positive polarity. If desired, consult Better Music Builder technical NOTE support for speaker wire and connection options.
  • Page 6: System Applications

    1. Insert Type (Standard Connection) HOW TO CONNECT THE SPEAKER TO AMPLIFIER We at Better Music Builder always provide you the technical support and relevant information to help you make the best use of your audio equipment. To avoid damages in...
  • Page 7: Connecting The Speaker With 3-D Positional Audio (Premium Format)

    Please refer to the diagram on the right for connecting the Model: DX-222 G2 3-D Positional Audio speakers to the 3-D Positional Audio system designed by the CENTER MAIN MAIN Better Music Builder engineering team. VOCAL With 3-D Positional Audio technology, user can actually experience the following effects: SUBWOOFER RIGHT LEFT •...
  • Page 8: Connecting The Speaker With 5-D Pro Audio (Superior Format)

    GROUP-B GROUP-A GROUP-A CENTER GROUP-B the speakers to the 5-D Pro VOCAL Audio system designed by the Better Music Builder engineering team. RIGHT RIGHT LEFT SUBWOOFER LEFT The concept of 5-D Pro Audio technology is the same as that of the 3-D Positional Audio technology.
  • Page 9: Controls And Functions

    CONTROLS AND FUNCTIONS Speaker FRONT & REAR PANEL: features are available for model CS-600 G3 Front View Top View Rear View 3-INCH TWEETER: PAPER CONE HIGH FREQUENCY DRIVER MOUNTABLE SCREW: TWO 8mm SCREW SIZE 10-INCH WOOFER: PAPER CONE LOW FREQUENCY DRIVER...
  • Page 10: System Setup Guidelines

    SYSTEM SETUP GUIDELINES Adjusting the Ceiling Mount (NB-901) Set Up INSTALLATION SETUP Precise Angle 1. MOUNTING THE SPEAKER TO THE CEILING The Ceiling Mount allows swing adjustment, slightly loosen an screw to make an adjustment, then re-tighten. Once you have set up the right position, then you can use the screw to STEP : Place the wall mount panel on the top of the tight it up.
  • Page 11: Mounting The Speaker To The Wall

    2. MOUNTING THE SPEAKER TO THE WALL Adjusting the Wall Mount (NB-901) STEP : Place the wall mount panel on the top of the Precise Angle speaker cabinet and use two screws to fasten it. The Wall Mount allows swing adjustment, slightly loosen an STEP : Then, use four screws to hold the speaker firmly screw to make an adjustment, then re-tighten.
  • Page 12: Placing The Speaker On The Floor To Monitor Singing

    3. PLACING THE SPEAKER ON THE FLOOR TO Speaker Stand External Adapter Mount MONITOR SINGING Dimensions: This speaker can be placed on the floor to perform the vocal monitoring function for live singing experience. It can also be used for business conference, coffee shop and church, etc. 7.1 inches 18 cm 2 inches...
  • Page 13: Recommended Tools

    The recommended tools in this page are not included in the package. You may purchase the recommended tools and Allen Screw other accessories from a hardware store. We at Better Music Builder always provide our customers 8 mm with useful information on audio equipment installation to 30 mm make your installation safe and easy.
  • Page 14 CS-600 G3 (10-inch Woofer) FRONT VIEW REAR VIEW SIDE VIEW 4 inch/10 cm 4 inch/10 cm 11.4 inch 29 cm 12.4 inch 12.4 inch 12.4 inch 31.5 cm 31.5 cm 31.5 cm 19.7 inch/50 cm 19.7 inch/50 cm 11.4 inch/29 cm...
  • Page 15: Physical Dimensions

    PHYSICAL DIMENSIONS Dimensions 3-WAY FULL RANGE LOUDSPEAKER CS-600 G3 CS-612 G3 CS-812 G3 MODEL NET WEIGHT 23.8 lbs / 10.8 kg (each) 36 lbs / 16.3 kg (each) 38 lbs / 17.2 kg (each) SHIPPING WEIGHT 54 lbs / 24.5 kg (pair) 50 lbs / 22.7 kg (each)
  • Page 16: Troubleshooting

    TROUBLESHOOTING Troubleshooting 1. SYMPTOM: NO SOUNDS COMING OUT FROM THE 3. SYMPTOM: NOISES FROM THE SPEAKER. SPEAKERS Probable cause: Probable causes: The A/C power cord of the speaker is not grounded. 1. The A/C power of the speaker is turned off. Remedy: 2.
  • Page 17: Final Words To User

    FINAL WORDS TO USER Final Words 7. SYMPTOM: TOO MUCH MICROPHONE FEEDBACK The engineering team of Better Music Builder has many FROM THE SPEAKER. years of experience in audio equipment design. The team constantly develops new audio technologies, designs Probable cause: innovative audio and karaoke equipment to suit your specific Incorrect tremble and bass adjustments on the speaker.
  • Page 18: Warranty

    WARRANTY Warranty ONE-YEAR LIMITED WARRANTY FOR HOME USE ADDITIONAL NOTES: EQUIPMENT 1. Limited warranty for home use equipment is only valid in Our one-year warranty covers both parts and labors. The North America. warranty becomes effective from the date of your purchase for one year.
  • Page 19: Agency Regulatory Notices

    AGENCY REGULATORY NOTICES Notices Federal Communications Commission Notice your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a These limits are designed to provide reasonable protection manner that protects human health and the environment. For against harmful interference in a residential installation.
  • Page 21 DUAL HARD-DRIVE The VOD-900 will be the first multimedia player produced by Better Music Builder. This player comes with high defini- tion capabilities and has two hard drive ports for your data. It comes with pre-installed software to manage your all your audio and video.
  • Page 22: Contact Information

    CONTACT INFORMATION Contact Us MAILING ADDRESS BE T TER M USI C BU I LD ER 2930 0 Kohoutek Wa y #150 Union Cit y, CA 94587 U.S.A. TELEPHONE NUMBERS USA Re gion USA Toll Fre e: 1-80 0 -318-2218 S ales &...
  • Page 24 Owner's Manual carefully before operating it. Please retain this manual for future reference. 360121208600 Printed on 100% Recycled Paper Code: 20121201 Comments E-mail to sales@bettermusicbuilder.com Copyright © 2013 Better Music Builder. All rights reserved. Legal trademark.
