OWNER'S MANUAL
LINE ARRAY SYSTEM
3-Way Active/Powered Speaker
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
w w w. B e t t e rM usi c B ui l d e r.c o m
It's what we do!
110421
Advertisement
Table of Contents
Related Manuals for Better Music Builder M-8
Summary of Contents for Better Music Builder M-8
- Page 1 Better Music Builder .com ® Passionate about Music It’s what we do! OWNER'S MANUAL ® Better Music Builder is a leader in the Audio and Karaoke equipment industry. We are committed to offering you high quality audio products. Unlike any others LINE ARRAY SYSTEM brand, we deliver the best cost and value to you directly.
-
Page 2: Table Of Contents
• Example of Speakon Connector ........................• Connection for Two M-8 Units (Mono Audio) ....................• Connection for Two M-8 Units (Stereo Audio) ....................• Connection for Two M-8 Units (Professional Stereo Audio) ..............• Line Out Connection ............................• Mix Out Connection ............................ -
Page 3: Introduction
• Line Input (Combined ¼ inch/XLR, RCA, 3.55mm) No karaoke user is left behind here as the M-8 uses all • Microphone Input (Combined ¼ inch/XLR) twelve midrange units to recreate the crisp clear voice from •... -
Page 4: Safety Instructions
Therefore, disconnect the electric plug from the outlet, and have the please visit our website at BetterMusicBuilder.com frequently device inspected by qualified Better Music Builder service to find out the most updated information, corrections on errors personnel. -
Page 5: Getting Started
For speaker connections, use a high-quality speaker wire with polarity coding. The side of the wire with a ridge or other coding is usually considered positive polarity. If desired, consult Better Music Builder technical NOTE support for speaker wire and connection options. -
Page 6: System Applications
SYSTEM APPLICATIONS EXAMPLE OF SPEAKON CONNECTOR Applications There are two groups on the speakon connectors: Group 1 (+1, – 1) and Group 2 (+2, – 2) as indicated in the diagram. In SPEAKON Y CONNECTORS order to use it, your speaker must have multi-functions (i.e. enable two sources of signal for input). -
Page 7: Connection For Two M-8 Units (Mono Audio)
CONNECTION FOR TWO M-8 UNITS (MONO AUDIO) • Connect the left and right audio output of the CD/DVD player to the Left and Right MUSIC INPUT 2 of the main unit. • For optimal performance, set The MUSIC 1 and/or MUSIC 2 and MIC and/or GUITAR VOLUME on the second unit to a high level. -
Page 8: Connection For Two M-8 Units (Stereo Audio)
CONNECTION FOR TWO M-8 UNITS (STEREO AUDIO) • First, connect the left audio output of the CD/DVD player to the Left MUSIC INPUT 2 of the main unit. • Then, connect the right audio output of the CD/DVD player to the Right MUSIC INPUT 2 of the second unit. -
Page 9: Connection For Two M-8 Units (Professional Stereo Audio)
CONNECTION FOR TWO M-8 UNITS (PROFESSIONAL STEREO AUDIO) • This is the most simplified way of connecting two units to achieve the best live sound. • Simply connect all inputs (CD/DVD player, microphone and guitar) to the mixer such as our EX-8 Multi Effects Mixer and control all the effects from it. -
Page 10: Line Out Connection
LINE OUT CONNECTION M-8 SUBWOOFER REAR VIEW “LINE OUT” is designed for connecting additional active/powered speaker; useful for extending the sound to MUSIC INPUT 1 GUITAR MUSIC INPUT 2 other areas. Audio signal needs to be connected to the (DVD) MUSIC INPUT 1 in order for the audio signal to go through the “LINE OUT.”... -
Page 11: Mix Out Connection
KTV-Series PRO-Line Coaxial Driver Better Music Builder 10-INCH WOOFER All audio signals received on the M-8 will go through the “MIX OUT”. Additional speaker to the M-8, reproduces the same audio signal playing via XLR connection. AUDIO INPUT CONNECTION M-8 SUBWOOFER REAR VIEW... -
Page 12: Live Sound Input Connection (Mono Mode)
LIVE SOUND INPUT CONNECTION M-8 SUBWOOFER REAR VIEW MUSIC INPUT 1 GUITAR MUSIC INPUT 2 (DVD) GUITAR 1/8 inch 3.55mm MULTI GUITAR INPUT LINE OUT RECORD OUT MIX OUT STEREO: Left audio plays, Right audio bypasses to other speaker GUITAR... -
Page 13: Controls And Functions
MUSIC INPUT 2 (DVD) MULTI 1/8 inch INPUT 3.55mm LINE OUT RECORD OUT MIX OUT MONO STEREO Passionate about Music Better Music Builder .com ® LINE ARRAY SYSTEM AUDIO VIDEO Karaoke TV Video Display 8-INCH WOOFER System Wired Mic Guitar... -
Page 14: Control Panel
Smart AUDIO M-8 G2 Phone MIX OUTPUT: XLR audio output to a second M-8 unit 3 6 0 1 5 1 0 3 4 0 0 0 RECORD OUTPUT: RCA audio to connect a recorder SERIAL NO. AC POWER SWITCH MODEL NO.: M-8... -
Page 15: System Setup Guidelines
SYSTEM SETUP GUIDELINES Set Up HOW TO SETUP SPEAKER SYSTEM Place the subwoofer on even surface. Insert the linkable line array speaker to the top of the subwoofer at 45° counterclockwise. Be sure to fully insert LINE ARRAY it into the socket to assure stability and good connection. Once inserted, turn 45°... -
Page 16: Physical Dimensions
PHYSICAL DIMENSIONS Dimensions M-8 = 1 x ACTIVE SUBWOOFER + 2 x COLUMN LINE ARRAY 3-WAY FULL RANGE ACTIVE SPEAKER FRONT VIEW SIDE VIEW REAR VIEW MODEL LINE ARRAY SUBWOOFER FULL SYSTEM (each) NET WEIGHT 7.4 Lbs/3.4 Kg 36.4 Lbs/16.5 Kg 51.2 Lbs/23.2 Kg... -
Page 17: Troubleshooting
The removal of the Grounding plug B. The left and right speakers have independent volume may cause internal damage to the M-8 and/or the personal injuries, so be sure to use a proper 3-prong wall plug or UL controls;... - Page 18 4. SYMPTOM: NOISE/SIGNAL COMING FROM 7. SYMPTOM: TOO MUCH MICROPHONE FEEDBACK SPEAKER(S) FROM SPEAKER(S) Possible causes: Possible cause: • The A/C power cord of the speaker(s) is not grounded Incorrect tremble and bass adjustments on the speaker. Remedy: • Audio source is presenting a short circuit •...
-
Page 19: Warranty
WARRANTY Warranty ONE-YEAR LIMITED WARRANTY FOR HOME USE ADDITIONAL NOTES: EQUIPMENT 1. Limited warranty for home use equipment is only valid in Our one-year warranty covers both parts and labors. The North America. warranty becomes effective from the date of your purchase 2. -
Page 20: Agency Regulatory Notices
AGENCY REGULATORY NOTICES Notices FEDERAL COMMUNICATIONS COMMISSION NOTICE your waste equipment at the time of disposal will help to conserve natural resources and ensure that it is recycled in a These limits are designed to provide reasonable protection manner that protects human health and the environment. For against harmful interference in a residential installation. -
Page 21: Final Words To User
Final Words Contact Us MAILING ADDRESS The engineering team of Better Music Builder has many years of experience in audio equipment design. The team BE T TER M USI C BU I LD ER constantly develops new audio technologies, designs... - Page 22 MAINTENANCE NOTE...
- Page 23 MAINTENANCE NOTE...
- Page 24 Owner's Manual carefully before operating it. Please retain this manual for future reference. 360151034000 Printed on 100% Recycled Paper Code: 20160802 Comments E-mail to sales@bettermusicbuilder.com Copyright © 2016 Better Music Builder. All rights reserved. Legal trademark.
