User's Manual
These units have been designed and
tested for capacity and effi ciency in
accordance with ARI standards. These
outdoor air conditioning units are de-
signed for use exclusively with select
NORDYNE G6 gas furnaces and select
NORDYNE B5 air handlers equipped
with dedicated matched indoor coils.
IMPORTANT NOTE
This equipment is one part of a total
system designed for maximum ef-
fi ciency, adequate capacity and total
comfort. The system must function as
intended. Under no circumstances any
part of the system may be substituted
with other components.
USER'S INFORMATION
IMPORTANT
Read this owner information to become
familiar with the features, capabilities
and use of your system.
Keep this with literature of other
appliances where you have easy
access to it in the future.
If a problem occurs, check instructions
and follow recommendations given.
If these suggestions don't eliminate
the problem, call your servicing
contractor.
Variable Speed Ultra-High
SEER Split System
THE iQ Drive SYSTEM
The iQ Drive Air Conditioning System
features fully variable speed compres-
sor technology and variable speed
indoor and outdoor motors. The system
provides variable cooling capacity as
needed modulating over a fi ve de-
grees Fahrenheit temperature range.
It operates near the nominal rated
capacity at the thermostat set point
and modulates as the temperature
difference between the set point and
the room temperature changes. The
system can operate at approximately
20% higher capacity than the nominal
capacity to provide rapid cooling. Then
as the room temperature decreases,
the system modulates down through
the intermediate capacities until reach-
ing the minimum capacity if the room
temperature reaches 2 degree F below
set point. If the room temperature de-
creases below the set point by 2 degree
F, then the unit will turn off.
The system has a built-in humidity
control that will maintain the humidity
of the home in the desired range. If the
humidity in the home is too low, then
the system will activate the humidifi er
(if installed). If the humidity is too high,
then the system will reduce the indoor
blower speed to increase the water
removal from the conditioned space
and lower the humidity.
