INSTRUCTION MANUAL
IMPORTANT INFORMATION
: Please read these instructions carefully and make
GB
sure you understand them before using this unit. Retain these instructions for future
reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS:
Avant d'utiliser cet appareil, veuillez lire
FR
atentivement les instructions et assurez- -vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
Lesen Sie diese Hinweise zur Handhabung des
DE
Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE:
Lea atentamente las instrucciones y
ES
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc-
ciones para la referencia en el futuro.
545154276 Rev. 3 4/15/09 BRW

Advertisement

Table of Contents
loading

Related Manuals for Partner B 320 B

Summary of Contents for Partner B 320 B

  • Page 1 INSTRUCTION MANUAL IMPORTANT INFORMATION : Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez- -vous de les avoir comprises. Conservez les instructions pour référence ultérieure.
  • Page 2 IDENTIFICATION (WHAT IS WHAT?) 1. Fuel tank 13. Throttle lock- -out 2. Handlebar 14. Start throttle button 3. ON/STOP switch 15. Starter handle 16. Fuel cap 4. Throttle cable clip 5. Shoulder harness clamp 17. Primer bulb 6. Shoulder harness 18.

  • Page 3: Identification Of Symbols

    IDENTIFICATION OF SYMBOLS WARNING! This brushcutter can be dangerous! Careless or improper use can cause serious or even fatal injury. B. Read and understand the instruction manual before using the brushcutter. C. Always use: Ear protection, eye protection, head protection, boots, and gloves. DANGER! Blade can thrust violently away from material it does not cut.

  • Page 4: Operator Safety

    Keep blade sharp. Keep cut- blade by contacting the right hand side of the ting line at the proper length. coasting blade with material already cut. S Use only 2,4 mm diameter Partner brand replacement line. Never use wire, rope, Stop coasting string, etc.
  • Page 5 S Use only recommended Partner accessories S Cut from your left to your right. Cutting on and replacement parts. right side of the shield will throw debris S Have all maintenance and service not ex- away from the operator. plained in this manual performed by your au- S Use only in daylight or good artificial light.

  • Page 6: Attaching The Handlebar

    ATTACHING THE HANDLEBAR 2. Position the lower shoulder harness clamp under the shaft and align the upper DANGER: and lower clamp screw holes. Clamp To avoid serious injury, the must be fittle above the arrow on the shaft barrier portion of the handlebar must be installed (see illustration above).
  • Page 7 3. Pivot shield until bolt passes through hole in bracket. 4. Reinstall nut and tighten securely with wrench (provided). NOTE: If your unit has a plastic cover over the threads on the threaded shaft, remove the 76 cm covering to expose the threads. Before instal- ling the trimmer head, make sure the dust cup and retaining washer are positioned on the gearbox as shown below.
  • Page 8 These 10. Remove the screwdriver. parts must be provided by Partner and installed 11. Turn blade by hand. If the blade binds as shown below. Failure to use proper parts can...

  • Page 9: Operation

    Before operation, petrol must be mixed Starter Handle with a good quality 2-cycle air-cooled engine oil. We recommend Partner brand oil mixed at a ra- tio of 40:1 (2.5%). A 40:1 ratio is obtained by mixing 5 liters of unleaded petrol with 0,125 liter Start Lever of oil.
  • Page 10 require pulling the starter handle many times, WARNING: depending on how badly the unit is flooded. Use only 2,4 mm diameter If the unit still doesn’t start, refer to the TROU- line. Other sizes of line will not advance properly BLESHOOTING TABLE.
  • Page 11 Allow the tip of the line to strike the ground lose control of the unit. The uncontrolled unit around trees, posts, monuments, etc. This can cause serious injury if the blade contacts technique increases line wear. the operator or others. S WHEN BLADE THRUST OCCURS - - Blade Thrust can occur without warning if the blade snags, stalls, or binds.

  • Page 12: Maintenance

    S Cut while swinging the upper part of your WARNING: body from left to right. The operator or others S As you move forward to the next area to cut, must not try to clear away cut material with the be sure to maintain your balance and footing.

  • Page 13: Service And Adjustments

    11. Make sure the lines are not caught be- place line using a 4,5 meters length of 2,4 tween the rim of the spool and the wall of mm diameter Partner brand line. the cover. 5. When installing new line on an existing 12.

  • Page 14: Seasonal Storage

    If you require further assistance or are unsure about performing this procedure, contact an authorized service dealer. Air Filter Cover Idle Speed Screw STORAGE ENGINE WARNING: Perform the following S Remove spark plug and pour 1 teaspoon of steps after each use: 40:1, 2-cycle engine oil (air cooled) through S Allow engine to cool before storing or trans- the spark plug opening.

  • Page 15: Troubleshooting Table

    TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE REMEDY Engine will not 1. ON/STOP switch in STOP 1. Move ON/STOP switch to ON start.

  • Page 16: Declaration Of Conformity

    We, Husqvarna AB, SE- -561 82 Huskvarna, Sweden, Tel: +46- -36- -146000, as authorised representative in the Community, declare that the brushcutter model Partner B 320 B from serial numbers 2009- -031N00001 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S...

  • Page 17: Technical Data Sheet

    TECHNICAL DATA SHEET ODEL: B 320 B Blade Trimmer ENGINE Displacement, cm Maximum engine power, measured in accordance with ISO 8893, kW Catalytic converter muffler ENGINE ROTATIONAL SPEEDS At maximum engine power, rpm 7000 7000 Maximum rotational frequency of the spindle...
