Specifications

Model

AV32L5EK* (UK model)

Item

Broadcasting systems

CCIR I

Colour systems

PAL

• The EXT terminals also support the NTSC 3.58/4.43 MHz system.

Channels and frequencies

E21-E69

Sound-multiplex systems

NICAM (I) system

Teletext systems

FLOF (Fastext), WST (World Standard Text)

Power requirements

220 - 240 V AC, 50 Hz

Power consumption

Maximum: 189 W, Average: 140 W, Standby: 2.8 W

Picture tube size

Viewable area 76 cm (measured diagonally)

Audio output

Rated Power output: 7.5 W + 7.5 W

(20 cm × 4 cm) oval × 2

Speakers

EXT-1 terminal

Euroconnector (21-pin, SCART)

• Video input, Audio L/R inputs and RGB inputs are available.

• TV broadcast outputs (Video and Audio L/R) are available.

EXT-2 terminal

Euroconnector (21-pin, SCART)

• Video input, S-VIDEO (Y/C) input, Audio L/R inputs and RGB inputs are available.

• Video and Audio L/R outputs are available.

• T-V LINK functions are available.

EXT-3 terminal

Euroconnector (21-pin, SCART)

• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.

RCA connectors × 3

EXT-4 terminal

S-VIDEO connector × 1

• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.

RCA connectors × 2

AUDIO OUT terminal

• Variable audio L/R outputs are available.

• Variable out 0-1 Vrms, low impedance

Headphone jack

Stereo mini-jack (3.5 mm in diameter)

Dimensions (W × H × D)

901 mm × 556 mm × 557mm

Weight

53.9 kg

Remote control unit × 1 (RM-C56)

Accessories

AAA/R03 dry cell battery × 2

* A basic model number. The actual model number may have characters added (such as "S" denoting silver) indicating the colour

of the TV set.

We may change the design and specifications without notice.

Pictures displayed on the screen using this TV's ZOOM functions should not be shown for any commercial or demonstration pur-

pose in public places (cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this

would be an infringement of copyright.

VICTOR COMPANY OF JAPAN, LIMITED

AV32L5EI* (Ireland model)

IR A-J, E2-E12, E21-E69, S1-S41, X, Y, Z,

Z+1, Z+2, ITALY A-H, ITALY H+1, ITALY H+2

LCT0909-001B-U

0106-T-CR-JMUK

COLOUR TELEVISION

AV32P10EK

AV32L5EK

(UK model)

AV32P10EI

A V 3 2 L 5 E I

(Ireland model)

INSTRUCTIONS

Contents

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Setting up your TV . . . . . . . . . . . . . . . . . . . . . . . . . . .4

T-V LINK functions . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Using your TV-the basics . . . . . . . . . . . . . . . . . . . . . .8

Remote control buttons and functions . . . . . . . . . . . . .11

Using the TV's menus. . . . . . . . . . . . . . . . . . . . . . . .17

Picture setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Picture features. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Sound setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

DIGITAL SURROUND (Only AV32P10EK and AV32P10EI) . .23

EXT SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

INSTALL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Other menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Further preparation . . . . . . . . . . . . . . . . . . . . . . . . . .37

TV buttons and parts . . . . . . . . . . . . . . . . . . . . . . . .41

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Table of Contents

Need help?

Do you have a question about the AV32P10EK, AV32L5EK, AV32P10EI, AV32L5EI and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC AV32P10EK, AV32L5EK, AV32P10EI, AV32L5EI

Page 1: Table Of Contents
Specifications Specifications Specifications Specifications Model AV32L5EK* (UK model) Item Broadcasting systems CCIR I Colour systems • The EXT terminals also support the NTSC 3.58/4.43 MHz system. Channels and frequencies E21-E69 Sound-multiplex systems NICAM (I) system Teletext systems FLOF (Fastext), WST (World Standard Text) Power requirements 220 - 240 V AC, 50 Hz Power consumption...
Page 2: Safety Precautions
Thank you for buying this To make sure you fully understand how to use your new TV, please read this manual thoroughly before you begin. Safety precautions Safety precautions Safety precautions Safety precautions Warning Warning Warning Warning I I I I To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
Page 3: Guidelines For Safe Operation
Guidelines for safe operation Guidelines for safe operation Guidelines for safe operation Guidelines for safe operation I I I I This equipment has been designed and manufactured to comply with international safety standards. However, as with any electrical appliance, care must be taken to ensure optimal results and operational safety.
Page 4: Setting Up Your Tv
Setting up your TV Setting up your TV Setting up your TV Setting up your TV Connecting the aerial and video cassette recorder (VCR) Connecting the aerial and video cassette recorder (VCR) Connecting the aerial and video cassette recorder (VCR) Connecting the aerial and video cassette recorder (VCR) I I I I If you are connecting a VCR, follow...
Page 5: Initial Settings
TV is in the standby mode. Press the (standby) button on the remote control to turn your TV on. • If the JVC logo does not appear this is because your TV has already been turned on for the first time: use the “LANGUAGE” and “AUTO PROGRAM”...
Page 6 Setting up your TV Press the button to start the AUTO PROGRAM function The AUTO PROGRAM menu appears and the TV channels you receive are automatically stored in the programme numbers list (PR). AUTO PROGRAM CH 10 BACK D0004-EK If “ACI START/ACI SKIP” appears in the AUTO PROGRAM menu: You can use the ACI (Automatic Channel Installation) function to decode the ACI data and complete the...
Page 7: T-V Link Functions
Set your TV’s main power to on (standby mode). Note: • A “T-V LINK compatible VCR” means a JVC video cassette recorder with the T-V LINK logo, or with one of the following logos. However, these VCRs may support some or all of the features described earlier.
Page 8: Using Your Tv-The Basics
Using your TV–the basics Using your TV–the basics Using your TV–the basics Using your TV–the basics Turn the main power on Turn the main power on Turn the main power on Turn the main power on I I I I Press the main power button on the TV The power lamp lights red and your TV is in the standby mode.
Page 9: Changing The Volume
Press the 5 and 6 buttons to choose a programme number (PR). Then press the a button • For programme numbers (PR) where you have the CHILD LOCK function set, the (CHILD LOCK) mark appears next to the programme number (PR) in the PR LIST. •...
Page 10: Using The Buttons On The Tv
Using your TV–the basics Using the buttons on the TV Using the buttons on the TV Using the buttons on the TV Using the buttons on the TV I I I I Press the P p buttons to turn the TV on from standby mode Press the P programme number (PR) or an EXT...
Page 11: Remote Control Buttons And Functions
Remote control buttons and functions Remote control buttons and functions Remote control buttons and functions Remote control buttons and functions MENU How to open the cover Muting button Muting button Muting button Muting button You can turn the sound off instantly. Press the (muting) button to turn off the sound.
Page 12 Remote control buttons and functions 14:9 ZOOM: This zooms up the wide picture (14:9 aspect ratio) to the upper and lower limits of the screen. 16:9 ZOOM: This zooms up the wide picture (16:9 aspect ratio) to the full screen. 16:9 ZOOM SUBTITLE: This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.
Page 13: Standby Button
DVD position. Press the VCR/DVD control button to control your VCR or DVD player • If your device is not made by JVC, these buttons will not work. • Even if your device is made by JVC, some of these buttons may not work, depending on the device you are using.
Page 14: Freeze Button
Remote control buttons and functions ~ ~ ~ ~ FREEZE button FREEZE button FREEZE button FREEZE button You can view the current programme as a still picture. Press the FREEZE button The still picture of the current picture will appear. current programme D0049-EK...
Page 15 Teletext control buttons and VCR Teletext control buttons and VCR Teletext control buttons and VCR Teletext control buttons and VCR P I I I I $ MENU Basic operation Basic operation Basic operation Basic operation You can view two types of teletext broadcasts on the TV: FLOF (Fastext) and WST (World Standard Text).
Page 16 Remote control buttons and functions Hold Hold Hold Hold You can hold a teletext page on the screen for as long as you want, even while several other teletext pages are being received. Press the N button Hold indication To cancel the Hold function: Press the button again.
Page 17: Using The Tv's Menus
Using the TV’s menus Using the TV’s menus Using the TV’s menus Using the TV’s menus This TV has a number of functions you can operate using menus. To use all your TV’s functions fully, you need to understand how to use the basic menus. Press the button to display the MENU (main menu)
Page 18: Picture Setting
Picture setting Picture setting Picture setting Picture setting PICTURE SETTING TINT NORMAL CONTRAST BRIGHT SHARP COLOUR ECO MODE BACK D0014-EK To display the PICTURE SETTING menu: Press the button to display the MENU (main menu) Press the 6 buttons to choose PICTURE SETTING, and press the TINT TINT...
Page 19: Picture Features
Picture features Picture features Picture features Picture features PICTURE FEATURES DIGITAL VNR AUTO DigiPure Pro AUTO COLOUR SYSTEM 4:3 AUTO ASPECT PICTIRE TILT PIP POSITION BACK D0015-EK To display the PICTURE FEATURES menu: Press the button to display MENU (main menu) Press the 6 buttons to choose PICTURE FEATURES, and press the DIGITAL VNR...
Page 20 Picture features COLOUR SYSTEM COLOUR SYSTEM COLOUR SYSTEM COLOUR SYSTEM I I I I The colour system is chosen automatically. However, if the picture is not clear or no colour appears, choose the colour system manually. Press the 6 buttons to choose COLOUR SYSTEM.
Page 21: Sound Setting
Sound setting Sound setting Sound setting Sound setting <AV32P10EK and AV32P10EI> SOUND SETTING STEREO/ BASS TREBLE BALANCE SPEAKER SUBWOOFER HEADPHONE BACK D0054-EK <AV32L5EK and AV32L5EI> SOUND SETTING STEREO/ BASS TREBLE BALANCE SPEAKER HEADPHONE BACK D0019-EK To display the SOUND SETTING menu: Press the button to display the MENU (main menu)
Page 22 Sound setting SUBWOOFER (Only SUBWOOFER (Only SUBWOOFER (Only SUBWOOFER (Only I I I I AV32P10EK and AV32P10EI) AV32P10EK and AV32P10EI) AV32P10EK and AV32P10EI) AV32P10EK and AV32P10EI) Set the SUBWOOFER function to ON when the subwoofer is connected to the TV. Press the 6 buttons to choose SUBWOOFER Press the 5 buttons to choose ON or OFF...
Page 23: Digital Surround (Only Av32P10Ek And Av32P10Ei)
DIGITAL SURROUND (Only AV32P10EK DIGITAL SURROUND (Only AV32P10EK DIGITAL SURROUND (Only AV32P10EK DIGITAL SURROUND (Only AV32P10EK and AV32P10EI) and AV32P10EI) and AV32P10EI) and AV32P10EI) DIGITAL SURROUND 3D-PHONIC DOLBY DIGITAL DANCE CLUB CONCERT HALL STADIUM SURROUND OFF BACK MORE D0045-EK You can enjoy the surround sound with any of the five surround functions.
Page 24 DIGITAL SURROUND (Only AV32P10EK and AV32P10EI) Other surround functions Other surround functions Other surround functions Other surround functions I I I I DANCE CLUB: This function creates a dance club atmosphere. CONCERT HALL: This function creates a concert hall atmosphere. STADIUM: This function creates a stadium atmosphere.
Page 25 Press the OK button to complete the setting The menu disappears. • When a speaker system is not connected to the TV, set TV SPEAKER to L/C/R and SUBWOOFER to OFF. Otherwise the sound will not be emitted correctly. • When you do not want to hear sound from the TV speakers, set TV SPEAKER to OFF.
Page 26: Ext Setting
EXT SETTING EXT SETTING EXT SETTING EXT SETTING <AV32P10EK and AV32P10EI> EXT SETTING EXT-1 DUBBING EXT-3 EXT-2 EXT-4 BACK D0055-EK <AV32L5EK and AV32L5EI> EXT SETTING EXT-1 EXT-3 EXT-4 BACK D0020-EK To display the EXT SETTING menu: Press the button to display the MENU (main menu) Press the 6 buttons to choose EXT SETTING.
Page 27 ID LIST ID LIST ID LIST ID LIST I I I I You can store a name for each of the devices connected to each EXT terminal. Giving a name to an EXT terminal makes the EXT terminal number appear on the screen, together with its name.
Page 28: Features
FEATURES FEATURES FEATURES FEATURES FEATURES SLEEP TIMER BLUE BACK CHILD LOCK DECODER(EXT-2) BACK D0023-EK To display the FEATURES menu: Press the button to display the MENU (main menu) Press the 6 buttons to choose FEATURES. Then press the SLEEP TIMER SLEEP TIMER SLEEP TIMER SLEEP TIMER...
Page 29 Press the blue button and set the CHILD LOCK function (CHILD LOCK) appears and the TV channel is locked. To reset the CHILD LOCK function: Press the blue button again. (CHILD LOCK) disappears. Press the button to complete the setting The menu disappears.
Page 30: Install
INSTALL INSTALL INSTALL INSTALL INSTALL LANGUAGE AUTO PROGRAM EDIT / MANUAL BACK D0029-EK To display the INSTALL menu: Press the button to display the MENU (main menu) Press the 6 buttons to choose the INSTALL menu. Then press the LANGUAGE LANGUAGE LANGUAGE LANGUAGE...
Page 31 EDIT/MANUAL EDIT/MANUAL EDIT/MANUAL EDIT/MANUAL I I I I The EDIT/MANUAL functions are divided into two types: editing the current programme numbers (PR) • (EDIT functions); and manually storing a TV channel you want to view as a • programme number (PR) (MANUAL function). Here are the details about these functions: MOVE: This function changes the programme number (PR) of a TV...
Page 32 INSTALL Press the 6 buttons to choose a TV channel Every time you press the 6 buttons, the programme number (PR) changes, and the picture of the TV channel stored in the programme number (PR) appears on the screen. Press the red button to start the ID function EDIT BBC1...
Page 33 DELETE DELETE DELETE DELETE Press the 6 buttons to choose a TV channel Every time you press the 6 buttons, the programme number (PR) changes over, and the picture of the TV channel stored in the programme number list (PR) appears on the screen.
Page 34: Demo
DEMO DEMO DEMO DEMO DEMO BACK D0036-EK To display the DEMO menu: Press the button to display the MENU (main menu) Press the 6 buttons to choose DEMO. Then press the The DEMO function automatically demonstrates some of the TV functions. Press the 6 buttons to choose ON Press the button to complete the...
Page 35: Other Menus
Other menus Other menus Other menus Other menus Using the ACI function Using the ACI function Using the ACI function Using the ACI function I I I I This TV has an ACI function which decodes the ACI (automatic channel installation) data. Using the ACI function allows all TV channels transmitted from the cable TV station to be properly registered quickly, using the data from the cable TV station.
Page 36 Other menus Press the 6 buttons to choose FEATURES. Then press the The FEATURES menu appears. FEATURES SLEEP TIMER BLUE BACK CHILD LOCK DECODER(EXT-2) BACK D0023-EK Press the 6 buttons to choose DECODER (EXT-2) . Then press the 5 buttons to choose ON An unscrambled picture appears.
Page 37: Further Preparation
Further preparation Further preparation Further preparation Further preparation Connecting external equipment Connecting external equipment Connecting external equipment Connecting external equipment I I I I Connect the equipment to the TV, making the correct rear panel and front panel connections. Before connecting anything: •...
Page 38 Further preparation Equipment which can output the Equipment which can output the Equipment which can output the Equipment which can output the S-VIDEO signal (Y/C signal) such as S-VIDEO signal (Y/C signal) such as S-VIDEO signal (Y/C signal) such as S-VIDEO signal (Y/C signal) such as an S-VHS VCR an S-VHS VCR...
Page 39 Using additional audio Using additional audio Using additional audio Using additional audio I I I I equipment equipment equipment equipment After correctly connecting the audio equipment to the TV, use the TV menu to correctly set the functions of the audio equipment.
Page 40 Further preparation Set the following functions (A to D) correctly depending on the speakers you want to use A: SPEAKER function Stop the sound from being emitted from the TV speakers. Correctly perform the settings in accordance with “SPEAKER” on page 21. B: TV SPEAKER function (Only AV32P10EK and AV32P10EI) When using the 3D-PHONIC function or DOLBY...
Page 41: Tv Buttons And Parts
TV buttons and parts TV buttons and parts TV buttons and parts TV buttons and parts Front panel Front panel Front panel Front panel I I I I <AV32L5EK and AV32L5EI> EXT- EXT- AUDIO OUT EXT- 1 Remote control sensor and ECO sensor 2 Power lamp 3 Main power button 4 Headphone jack (mini jack)
Page 42: Troubleshooting
Troubleshooting Troubleshooting Troubleshooting Troubleshooting If a problem arises while you are using the TV, please read this troubleshooting guide carefully before you ask to have the TV repaired. You may be able to fix it easily by yourself. For example, if the mains plug is disconnected from the mains outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
Page 43: Specifications
Specifications Specifications Specifications Specifications Model Item Broadcasting systems CCIR I Colour systems • The EXT terminals also support the NTSC 3.58/4.43 MHz system. Channels and frequencies E21-E69 Sound-multiplex systems NICAM (I) system Teletext systems FLOF (Fastext), WST (World Standard Text) Power requirements 220 - 240 V AC, 50 Hz Power consumption...
