August 2011©
Jacobsen Turf Cat 628 ROPS
** Shown with optional equipment
Caution
** Please read installation instructions and follow all safety statements before attempting operating
this ROPS product.
** A copy of this operator manual should be kept with the machine operating manuals.
Jacobsen Turf Cat 628 ROPS Operator Manual
Jacobsen Turf Cat 628 ROPS
This ROPS is designed and built to fit
the Jacobsen Turf Cat 628.
Designed and Built by:
Tektite Manufacturing Inc:
24157 Hwy 3
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product
warranty provided by Tektite.
Advertisement
Related Manuals for Jacobsen Turf Cat 628 ROPS
Summary of Contents for Jacobsen Turf Cat 628 ROPS
- Page 1 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual Jacobsen Turf Cat 628 ROPS Jacobsen Turf Cat 628 ROPS ** Shown with optional equipment This ROPS is designed and built to fit the Jacobsen Turf Cat 628. Designed and Built by:...
- Page 2 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual Tektite Manufacturing Incorporated thanks you for purchasing a Jacobsen Turf Cat 628 ROPS! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
-
Page 3: Safety Precautions
August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS. - Page 4 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the utility vehicle. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
- Page 5 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual Safe Operation on Rough Terrain 1. Drive the utility vehicle slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
- Page 6 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the utility vehicle is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
- Page 7 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
- Page 8 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual 4. Rear Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work light is on. 5. Beacon Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
- Page 9 August 2011© Jacobsen Turf Cat 628 ROPS Operator Manual After your ROPS has been installed: Before starting a utility vehicle equipped with a Tektite ROPS: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and utility vehicle can cause operator interference which could lead to bodily injury and/or damage the machine.
