- Page 1 User’s Manual Legend SB500R UPS K01-1120008-00...
-
Page 2: Table Of Contents
TROUBLESHOOTING……………………………………………………………….……...….6 TECHNICAL SPECIFICATIONS………………………………………………….………..….7 LIMITED WARRANTY …………………………………………………………………….……8 Thank you for purchasing a Legacy Power Conversion Product. To enjoy all the features and benefits of this Uninterruptible Power System (UPS), please read and follow all installation and operation instructions completely. This UPS is designed to provide guaranteed power protection for connected electronic equipment. -
Page 3: Important Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS (SAVE THESE INSTRUCTIONS) This manual contains important instructions that should be followed during installation and maintenance of the UPS and batteries. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate. -
Page 4: Installing Your Ups System
Legend SB500R Uninterruptible Power System INSTALLING YOUR UPS SYSTEM UNPACKING The box should contain the following: (1) UPS unit ; (1) User’s manual for UPS; (1) SeeUPS2020 software; (1) serial interface cable (DB-9); (1) Telephone communication cable; (1) warranty registration card. -
Page 5: Basic Operation
FRONT AND REAR PANEL DESCRIPTIONS 1. Battery/Surge Outlets Provides four battery powered/surge outlets for connected equipment and insures temporary uninterrupted operation of your equipment during a power failure. 2. Power Switch Can be used as a mater on/off switch for equipment connected to the battery power supplied outlets. 3. -
Page 6: Definitions For Illuminated Led Indicators
Legend SB500R Uninterruptible Power System DEFINITIONS FOR ILLUMINATED LED INDICATORS CONDITION Circuit Wiring Power Alarm Breaker Fault Normal Utility Failure- the UPS is providing power to On/Off Beeps battery power-supplied outlets from its battery. Utility Failure- The UPS is providing battery... -
Page 7: Troubleshooting
Battery not fully charged. Recharge the battery by leaving the UPS not perform plugged in. expected Battery is slightly worn out. Contact Legacy Power Conversion about runtime. replacement batteries at service@lpc-ups.com or 800-859-5711. The UPS will The on/off switch is Turn the UPS off. -
Page 8: Technical Specifications
Legend SB500R Uninterruptible Power System TECHNICAL SPECIFICATIONS SB500R Capacity 500VA(275W) Input Voltage on Utility 100V to 140V Input Frequency 57 Hz to 63 Hz On-Battery Output Voltage 120Vac ± 5% On-Battery Output Wave Form Simulated Sine Wave Form Transfer Time... -
Page 9: Limited Warranty
Limited Warranty.) LIMITED WARRANTY Legacy warrants to you, the Initial Purchaser, that the Product will be free from defects in material and workmanship for three years from the date of original purchase, subject to the terms of this Limited Warranty. -
Page 10: N9246 Hwy 80 South, Suite
Legacy will inspect and examine the Product within ten (10) days of receipt. If the Product is not as warranted, Legacy will repair or replace the Product and return it to you at Legacy's expense, or, if Legacy is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, Legacy will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 11 (collectively, "High Risk Activities"). Legacy expressly disclaims any express or implied warranty of fitness for High Risk Activities. Legacy does not authorize use of any of its products use in any High Risk Activities. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF LEGACY PRODUCTS.
- Page 12 N9246 Hwy 80 South, Suite 7 Necedah, WI 54646 Tel: (800) 859-5877 Fax: (608) 565-5879 Email: sales@lpc-ups.com Web: www.lpc-ups.com Entire contents copyright ©2006 Legacy Power Conversion, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited.
