Descriptive diagram

A - Operating valve
B - Operating valve seat
C - Safety valve
D - Pressure indicator
E - Opening button
F - Long lid handle
G - Lid positioning mark
H - Operating valve positioning mark
Capacity
6.3 qt 6L

Compatible heat sources

GAS SOLID
HOTPLA TE
• The pressure cooker can be used
on all heat sources.
• When using an electric hob or induction, make sure
that the size of the hot plate does not exceed the
size of the pressure cooker base.
• On a ceramic or halogen hob, always make sure that
the pressure cooker base is clean and dry.
• On a gas hob, the flame should not extend past the
diameter of the pressure cooker base.
2
Pressure cooker base diameter - model references
Cooker Base
diameter diameter
8.6" 7.5"
Standards information:
Upper operating pressure limit: 100 kPa (14,5 psi).
Maximum safety pressure limit: 170 kPa (25 psi).
CERAMIC INDUCTION
or
HALOGEN
I - Lid gasket
J - Steam basket
K - Steam basket support
L - Long pressure cooker body handle
M - Pressure cooker body
N - Short pressure cooker body handle
O - Maximum filling mark
Model
P25107
ELECTRIC
HOTPLA TE
Characteristics
Lid and body
Item number
YS223H64
material
Stainless
steel
