Page 1: Table Of Contents
WIRELESS SECURITY SYSTEM Home Prosafe Sc9100 Introduction alarmconsole page 2 Installing page 3 Registering sensors and remotes page 5-7 Storing Phone Numbers page 8 Recording an own message page 8 Using the Security System page 9 What happens when the alarm is triggered page 9 Home Automation functions page 10... -
Page 2: Introduction Alarmconsole
The security console The security console 1. Display 17. On - Switch on a X10 Module. 2. Armed - Indicator lights up when the alarm is 18. Off - Switch off a X10 Module. switched on. 19. OK - Confirm setting. 3. -
Page 3: Installing
Installing Installing Chose a good space for the console and make sure you have a wall socket (230V) and a telephone connection close by. For optimal range it is best to mount the console central to the objects you wish to secure. This ensures that the distance between the console and the sensors is as short as possible and the range will be sufficient. - Page 4 The menu in English The menu in English To access the menu, press the menu upp or menu down button. The display now shows ENTER PIN. Use the menu buttons upp/down to go trough the menues. 1. INSTALL Registering and de-registering sensors, remote controls and thermostats. 2.
-
Page 5: Registering Sensors And Remotes
Key Chain Remote Key Chain Remote 1.Control indicator -Comes on when the remote control sends a radio signal when the key are pressed. When the indicator lblinks only weakly , the batteries have to be replaced. 2. Arm - Switches on the Security System in the Arm Away Mode. - Page 6 Door/Window sensor Door/Window sensor 1. Transmitter part - Built-in antenna.. 2.Control indicator LED -When pressing the Tamper contact button, or when the unit is transmitting a signal to the base station, this LED will light up. When the LED blinks weakly, batteries have to be replaced.
- Page 7 Motion detector Ms18 Motion detector Ms18 1.Control Indicator - Lights up when a signal is transmitted. 2. PIR 3.Tamper contact. 4.Battery compartment (2xAA, 1.5V). 5.Sensitivity switch ½ Iin setting 1 the sensor will iinstantly react to movement, in setting 2 the sensor is less sensitive and will only react MS18E after registering multiple...
-
Page 8: Setting The Clock
Setting up the Security Console Setting up the Security Console Setting the clock 1. To access the menu, press either the menu upp or down button. The display now shows ENTER PIN. 2. Enter your 4-digit PIN code (factory setting 0000 see page 12 for changing the PIN code). The display is cleared and shows a * for each number entered. -
Page 9: Using The Security System
Using the Home Prosafe system Using the Home Prosafe system Setting the alarm The system has two different alarm functions:: 1. ARM AWAY - Full alarm. All registered Sensors will be activated. 2. ARM HOME - Partial alarm All Door/Window sensors will be activated, but the motion detectors are not armed. This means you can walk around the house, while the ‘shell’... -
Page 10: Home Automation Functions
Lm12 Lamp/Dimmer module Plug-in module to switch and dim lighting. Am12 Device/Switch module. Plug-in module to switch lighting and electrical equipment. More information on these modules can be found on www.electia.se or you can contact your local dealer. Addressing your modules An adress can be set for every X10 module. -
Page 11: Setting Timers
X10 - Hemautomation X10 - Hemautomation Setting Timers 1. To access the menu press the menu upp or down button. The display now shows ENTER PIN. 2. Enter your 4-digit PIN code (factory setting 0000. See page 12) The display is cleared and shows a * for each number entered. -
Page 12: Changing The Access Code (Pin)
Advanced system functions Advanced system functions Setting the delays You can set a number of delay times via the menu DELAYS: ENTRY DELAY The time you get to switch off the system after entering your house (factory setting 30 sec). EXIT DELAY before the system is switched on when you leave the house (factory setting 60sec). -
Page 13: Removing/De-Registering A Sensor
Advanced security functions Advanced security functions Disarming the siren for silent alarm You can set the security system to raise the alarm without sounding the siren (just the telephone dialler and lighting). In case of a burglary, the built-in siren will not be activated (N.B., Other sirens installed will still work). The siren is turned on in the factory settings. - Page 14 Advanced Home Automation functions Advanced Home Automation functions Besides the Plug&Play modules a large number of built-in switches, sun blind switches, remote controls and special modules are available. With the addition of these modules you can control nearly everything that is electrically powered in your home via your security systems. See www.ehem.se for more information.
-
Page 15: Telephone Functions
Advanced Home Automation functions Advanced Home Automation functions Basic address for Home Automation functions The basic adress is set to control multiple Home Automation modules on the Base console. The standard basic address is A1. The A in this address is called the House Code. The House Code of the console, the remote controls and the Home Automation modules all have to have the same letter. -
Page 16: Trouble Shooting
Advanced Home Automation functions Advanced Home Automation functions Operating the alarm functions via an outside phone 1. Call your home number. The console will answer. Please enter PIN. 2. Enter your 4-digt PIN code. 3. If your PIN is correct, you will hear ‘PIN accepted’. If your PIN is incorrect, you will hear ‘Error’. 4.Press 0 followed by * to activate your security system.
