Rosen DS-GM1010 GM Series Installation Manual

Ds-gm1010 gm series rosen

Hide thumbs

Table Of Contents

NOTICE OF INTENDED INSTALLATION AND USE

THE ROSEN MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH IS

NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE VEHICLE

THE INSTALLER OF THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS

IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION OF

THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO VIOLATE

ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR

PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION

Rosen Entertainment Systems

Multi-Media Navigation System Installation Guide

IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.

WORKING PROPERLY PRIOR TO DELIVERY OF THE VEHICLE.

STATE AND/OR FEDERAL LAW.

Do not proceed until process has been completed

CAUTION

Process must be carefully observed in order to reduce

the risk of damage to the accessory or vehicle

Process must be carefully observed in order to ensure a

Specific tools and equipment recommended for this

Observe safe practices, this process can be dangerous

and there is a risk of personal injury

TESTING and TROUBLESHOOTING

Content specific testing and troubleshooting points

AND/OR USE.

STOP

Damage to the vehicle may occur

CAUTION

CRITICAL

quality installation

TOOLS and EQUIPMENT

process

SAFETY RISK

Installation Guide

Table of Contents

Need help?

Do you have a question about the DS-GM1010 GM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rosen DS-GM1010 GM Series

Page 1 Installation Guide NOTICE OF INTENDED INSTALLATION AND USE THE ROSEN MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH IS NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE VEHICLE IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.
Page 2 STEP The first step you need to complete Is to CONFIRM the Vehicle Audio System before you proceed. The Rosen Nav Systems are specifically designed to be CONFIGURED to work in appropriate vehicles. This System can be Configured to work in...
Page 3 Identify the Vehicle Audio System STEP The first step you need to complete Is to CONFIRM the Vehicle Audio System before you proceed. The Rosen Nav Systems are specifically designed to be CONFIGURED to work in appropriate vehicles. USING THE RPO CODES You can use the Regular Production Order (RPO) Codes to determine the Audio Platform Type.
Page 4 STEP Before you start, please read these critical steps below BEFORE YOU START THE INSTALLATION, READ THIS GUIDE! VISIT Rosen Dealer Central For the latest Updates, Corrections and Technical Tips about this product and installation www.RosenDealerCentral.com CHECK THE BATTERY Test the battery voltage to make sure it’s fully charged This only takes seconds and can save hours of troubleshooting later.
Page 5 (Note: No need to disconnect climate controls on Acadia!) Remove Mounting Screws Remove 4 radio mounting screws Remove Radio Remove OE radio and unplug all connections CAUTION (Non-Bose system shown) Rosen Entertainment Systems Copyright 2010 All Rights Reserved Multi-Media Navigation System Installation Guide DP-GM1014 Rev A Page 5...
Page 6 Interface Module. INSTALL THE ROSEN NAVIGATION SYSTEM STEP You will need to prepare the Rosen Navigation System for installation in the vehicle. Remove the DVD Transport Screws There are 2 x Phillips Transport Screws which protect the DVD Mechanism during transportation.
Page 7 These harnesses must be fully engaged prior to the system installation. See the Harness Diagrams for more information Prepare the Vehicle side harnesses for connection to the Rosen Harness Use care not to pinch or damage cables as this will cause performance issues/failures Engage all Connectors to the Factory...
Page 8 “Off” position BLUETOOTH PHONE NOTICE If this Vehicle is equipped with FACTORY BLUETOOTH, the Rosen Integrated Bluetooth must be set to OFF in the Installer Setting Menu. ONLY ONE BT System can be Paired at a time (either Factory or RES)
Page 9 Confirm CD audio playback is OK Troubleshooting 1) Confirm the Disc is Store Bought and in good condition 2) Reset the system Rosen Entertainment Systems Copyright 2010 All Rights Reserved Multi-Media Navigation System Installation Guide DP-GM1014 Rev A Page 9...
Page 10 2) Confirm the Disc is Store Bought and in good condition 3) Reset the system Select Phone as the Source (Rosen Bluetooth only!) Confirm Phone Pairing is successful Troubleshooting 1) Confirm the Phone has BT and is in discoverable mode...
Page 11 There are a number of GM Radios which look identical but operate on different data protocol. You may experience problems if the OE System was not properly identified or if the harness has become damaged. The Following Table will help to Resolve Typical Problems. Installed Rosen System Symptom Cause...
Page 12 Un-Pair with RES BT BT is Not Paired or is Paired Factory BT Reports No Phone Set RES BT OFF Audio Steering Wheel Buttons with Rosen System – Not Paired Factory Pair with Factory System Factory BT Button on Steering...
Page 13 Camera, Universal Black DP-1013-1 Harness, iPod Interface NOTE: Items marked “*” are not compatible with all systems, contact Rosen Technical Support for specific compatibility. The DP-1062 kit contains DP-1008, DP-1009, DP-1011 ** Included with DP-1066, DP-1067, and DP-1068 Part Number...
Page 15 Installation Guide GM Series www.RosenEntertainment.com Rosen Entertainment Systems Copyright 2010 All Rights Reserved Multi-Media Navigation System Installation Guide DP-GM1014 Rev A Page 15...
