Summary of Contents for Jetview 27X Zoom
-
Page 2: Table Of Contents
Table of contents CAUTION INTRODUCTION OF PRODUCTS DIRECTIONS FOR USE FUNCTIONAL SETTING BY THE KEYBOARD OSD MESSAGE DISCRIPTION TROUBLE SHOOTING DIMENSION ASSEMBLY SPECIFICATION... -
Page 3: Caution
CAUTION Thank you for purchasing our product. Please operate the product after being fully aware of the manual. Pease contact us if you have any queries. Precaution Note the following matters before the installation of the product. Avoid the following places for the installation. A high/low temperature: Using indoor- Snow, rain and wet: Humidity or water cameras in the places of +50... - Page 4 Caution in Use - Disassembling the unit or putting alien substances such as a metal can make the camera defective. - Make sure of power switch-off before the installation. : Ensure power switch-off and check the voltage the camera before the installation. - Do not give the unit a shock and an operation.
-
Page 5: Introduction Of Product
INTRODUCTION OF PRODUCT 1. DESCRIPTION AND FEATURES - Description This camera has been designed elegantly for buildings, department stores that need to be in harmony with the interior as a high speed dome camera, including various observation functions. - Features High Zoom Rate Auto Tilt Function Built-in High Zoom (27x, 33x, 37x) - Page 6 2. INSTALLATION AND CONNECTION 1) Name and function of each part...
- Page 7 2) Installation...
- Page 9 3) How to connect equipments...
- Page 11 4) HOW TO SET PROTOCOL...
- Page 12 5) SETTING ADDRESS OF DIP SWITCHES...
-
Page 13: Directions For Use
DIRECTIONS FOR USE OSD (ON SCREEN DISPLAY) menu control It is the function to call up the Menu User can not only set Preset, Group, Tour, Swing, Trace functions of the camera up by the menu, but also set them up by shortening keys. Accessing OSD menu The menu is displayed on the screen with the key tone when user presses No.1 and menu key. - Page 14 1. ID SET. This function is to set camera ID up to 16 letters on the monitor. User can choose letters that they want, if user control a joystick up / down / right / left, and user can reselect the previous letters, if user presses Z/I, Z/O or turn the head of the joystick to right/left 2.
- Page 15 5. SHUTTER SPEED As a setting shutter speed mode, it can be distinguished a fast moving subject easily by means of shutter speed Attention-The illumination of the camera decreases if shutter speed is up. The state of first default is ‘AUTO’. It can be worked in the state of Flickerless ‘off’...
- Page 16 9. DNR CONTROL It can remarkably reduce noise of minimum illumination by super noise removable technique and also file size becomes smaller while DVR is being recorded by the effective reduction of noise. Off, Low, Medium, Max 10. BACK LIGHT This camera is designed so that it delivers a distinctive subject and background at the same time, even when the subject is in backlight, unlike conventional...
- Page 17 It is used when user corrects and limits the extensional range of the focus as a function to set the maximum value of zoom. Off, 27x zoom : 54X ~ 444X 27x zoom : 54X ~ 444X 33x zoom : 66X ~ 396X 37x zoom : 74X ~ 444X 15.
- Page 18 16. DAY& NIGHTF The function is used to distinguish an object clearly in the dark condition. Auto-Low : This mode is worked automatically according to sensitivity, if the sensitivity is low Auto-Hi : This mode is worked automatically according to sensitivity, if the sensitivity is high. On : Change into DAY &...
- Page 19 20. PRESET SET & RUN PAGE It is a function to set and operate Preset, Group, Tour. User can see the screen when moves the joystick to Right/Left after fixing the cursor on the menu. <<PRESET SETUP PAGE>> Preset set CH : User can set Preset No. and title on this menu.
- Page 20 Preset Swing SET : Set Preset Swing Move next SWING page for the setting, if user presses F/F key in the state of selection of the menu The preset must be set before the setting as Swing Is a function to repeat an auto observation of 2 Preset points user fixes in Preset set GROUP SET: User can set maximum 12 groups.
- Page 21 Tour SET Group : User can set continual Group motion that can be put 12 Groups in 1 Tour Move to the setting page if user presses F/F key on this menu The Group user wants to set must be set previously Setting is only possible when Preset is already set in the state of setting of Swing, Group, Tour if not, it displays the message “Sorry Undefined”.
- Page 22 22. ALRAM CHANNEL ON/OFF What is the ALARM function? : It operates to observe the location of the camera which is memorized previously in the situation of the warning signal or trespassers by using a sensor. - CH On/Off : Alarm Input - Each channel can be ON/ OFF - Alarm Relay : It can be set On or not when ALARM OUTPUT PORT operates wrong.
- Page 23 24. PRIVARCY ZONE SET Max 16 privacy zones can be configured for the protection of privacy. How to set privacy zone In <<PRIVACY ZONE SET>> menu, select the channel that you want by a joystick, then move to the next page if you press the [F/F] key Fix the black square on the middle of area that you want to hide by a joystick, then go back to the previous page by [F/F] key after controlling...
- Page 24 25. AUTO TILT MODE The PAN is turned in a 180 degree arc automatically when the angle of the camera moves down to the maximum degree, therefore, it is possible to track objects continuously 26. SMART PANTILT It is a function that P/T speed is getting slower as Zoom in.
- Page 25 29. SHORTCUT KEY The Shortcut Key can make some of the functions to perform faster and easily. How to use shortcut key (All protocols is operated it at the same way ) Function Operation Function Operation Group 1 51 + Preset Run Trace 66 + Preset Group 2...
- Page 26 32. FACTORY RESET WARNING Please be careful of that all setting data of OSD MENU are reset into the first default when operates FACTORY RESET WARNING. The setting data of Preset, Swing, Group, Tour, Trace, also is deleted all...
-
Page 27: Functional Setting By The Keyboard
Functional Setting by the Keyboard 1. Preset setting You can set Preset point up to 250. Preset Input. Preset setting can be set 1 to 250 sequentially after moves the camera to where you want Preset Move The camera moves to the preset point, if you press Preset No. - Page 28 3. Group setting Start Group setting mode - Set Preset No. again if you want to input it continuously. - Set a GROUP again from the first after ending with Key , if you would like to finish Preset input in one group to input next Group.
- Page 29 Start / End Tour Delete Tour 5. Spiral Function It is a function to observe objects in the spiral direction. Spiral observation ON 6. PTZ Trace It memorizes P/T/Z motions for 200sec, then operates them at the same Trace. Start / End Trace Set Trace Delete Trace...
-
Page 30: Osd Message Discription
OSD MESSAGE DISCRIPTION 1. PRESET MESSAGE... -
Page 32: Trouble Shooting
TROUBLE SHOOTING 1. You must turn off the power switch before installation of this equipment 2. Avoid installation places where it is the ultimate cold, hot, and humid. 3. Use a power supply of AC24V, 1.5A output. 4. Please be careful that you connect respective wires without mismatching in installation. 5. -
Page 33: Dimension
DIMENSIONS Wall mount bracket Outdoor Type Indoor Type... - Page 34 Outdoor Type Indoor Type In-ceiling mount bracket...
-
Page 35: Assembly
ASSEMBLY DSC-30EWP Wall mount bracket... - Page 36 DSC-20EWP Wall mount bracket Assembly of outdoor dome with pole mount pendant...
- Page 38 Main & Sub Keyboard configuration...
-
Page 39: Specification
SPCIFICATIONS MODEL 27X Zoom 33X Zoom 37X Zoom 1/4" Sony Super HAD 1/4" Sony Super HAD 1/4" Sony Double Image sensor Density interline CCD Effective pixels NTSC 768(H) 494(V), PAL 752(H) 582(V) Horizontal resolution Color : 550 TVL, B/W 680 TVL...
