Page 1: Air Conditioner
RJ100F5HX ** AJ100FCJ5** Air Conditioner installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register F I P D G DB98-32978A(4) RJ100F5HXEA_IM_E_32978A(4).indd 31 2012-10-25 오후 5:22:56... -
Page 2: Table Of Contents
This manual explains how to install an indoor unit with a split system with two SAMSUNG units. The use of other types of units with different control systems may damage the units and invalidate the warranty. The manufacturer shall not be responsible for damages arising from the use of non compliant units. - Page 3 In order to prevent electric shocks, fires or injuries, always stop the unit, disable the protection switch and contact SAMSUNG’s technical support if the unit produces smoke, if the power cable is hot or damaged or if the unit is very noisy.
-
Page 4: Accessories
A A ccessories The following accessories are supplied with the air conditioner. Accessories in the outdoor unit case 3-wire 2-wire Power Cable Assembly Cable Drain Plug Installation Manual Rubber Leg (option) (option) Tube connector Tube connector Flare Nuts, 15.88mm Flare Nuts, 9.52mm (Pipe 12.70mm;... -
Page 5: Deciding On Where To Install The Air Conditioner
A D eciding on where to install the air conditioner When deciding on the location of the air conditioner with the owner, the following restrictions must be taken into account. General Do NOT install the air conditioner in a location where it will come into contact with the following elements : ◆... -
Page 6: Space Requirement For Outdoor Unit
A S pace requirement for outdoor unit When installing 1 outdoor unit (Unit : mm) ※ When the air outlet is opposite the wall ※ When the air outlet is towards the wall 2000 or more 300 or more 600 or more ※... -
Page 7: Fixing The Unit In Position
When installing more than 1 outdoor unit (Unit : mm) 300 or more 600 or more 600 or more 600 or more ※ When 3 sides of the outdoor unit are blocked by the wall 600 or more 600 or more ※... -
Page 8: Indoor/Outdoor Unit Installation Drawings
Indoor/outdoor unit installation drawings ◆ Piping outside diameter Indoor unit Outdoor unit Power supply ø, V, Hz Outside diameter Unit Liquid ** 020/023/026/ RJ100F5HX ** 030/035/052/ 1,220-240,50/60 ** 020/023/026/ AJ100FCJ5 ** 3/8" 07/09/12/18/24 ** 030/035/07/09/12 ** 1/4" ** 052/18 ** 1/2"... -
Page 9: Refrigerant Piping Work
Refrigerant piping work Installing drain hose While heating, ice may accumulate. During the process of defrosting, check if condensation draining is adequate. For adequate draining, do the following : Drain hole Insert the drain plug into the drain hole on the underside of the outdoor unit. -
Page 10: Connecting Refrigerant Pipe
Refrigerant piping work Connecting refrigerant pipe RJ100F5HX ** / AJ100FCJ5 ** OUTDOOR UNIT Follow different orders depending on the capacity of indoor units. A unit ** 016/020/023/026/030/035 ** /AQV07/09/12 ** /AR07/09/12 ** ◆ Install pipes between indoor and outdoor units orderly as [A→B →C→D→E]. B unit C unit ** 052 ** /AQV18/24 ** /AR18/24 **... -
Page 11: Important Information Regarding The Refrigerant Use
Checking gas leakage Before completing the installation (insulation of the cables, hose and piping and fixing of the indoor unit to the installation plate), you must check that there are no gas leaks. LEAK TEST WITH NITROGEN (before opening valves) In order to detect basic refrigerant leaks, before recreating the vacuum and recirculating the R-410A, it’... -
Page 12: Charging Additional Refrigerant
A C harging additional refrigerant If you install the excessive length of pipe, add additional refrigerant as 20g per unit meter ; refer to the table below. Refer to the Service Manual for more details on this operation. Model Total connecting pipe length (L) Adding refrigerant LT ≤... - Page 13 A M ethod for connecting wires Connecting wires A-unit B-unit C-unit D-unit E-unit 1(L) 2(N) 1(L) 2(N) 1(L) 2(N) 1(L) 2(N) 1(L) 2(N) Indoor unit Assembly cable F1 F2 F1 F2 F1 F2 F1 F2 F1 F2 Earth Earth Earth Earth Earth terminal...
-
Page 14: Checking Correct Earthing
Tightening power terminal ≫ Connect the cables to the terminal board using the compressed ring terminal. ≫ Use rated cables only. ≫ Connect the cables with driver and wrench that can apply the rated torque to the screws. ≫ Make sure that appropriate tightening torque is applied for cable connection. If the terminal is loose, arc heat may occur and cause fire and if the terminal is connected too firmly, terminal may get damaged. -
Page 15: Setting Indoor Unit Address
Setting indoor unit address Setting indoor unit address automatically ◆ Switch the system on and wait for code " " to appear on the display of the external unit (this requires approximately 60 seconds ** ). ◆ As soon as code " "displays, press once the red button (K1) shown on the figure on the side of the page : ◆... - Page 16 Setting indoor unit address Setting indoor unit address manually Step 1 Review all the following elements in the installation: ◆ Installation site strength ◆ Piping connection tightness to detect any gas leakage ◆ Connection wiring ◆ Heat-resistant insulation of the piping ◆...
- Page 17 ROTARY SWITCH “SW02” POSITION ACCORDING TO REFRIGERANT CIRCUIT CONNECTED ( 0=A; 1=B; 2=C; 3=D; 4=E ) Indoor Unit OUTDOOR UNIT SW02 Att. "A" Att. "B" Att. "C" Att. "D" Att. "E" A unit B unit C unit D unit E unit TO SET ADDRESSING MANUALLY BY TYPE PICTURE...
- Page 18 Setting indoor unit address Setting indoor unit address manually Setting option (AQV**/AJN**/AR**) Entering mode for Option setting mode setting option Mode change High Temp Button High Fan Button Low Temp Button Low Fan Button Setting option 1. Remove batteries from the remote controller. 2.
- Page 19 The procedure of setting option Operation Indication * Step 1 1. Remove the batteries from the remote controller. 2. Insert batteries while pressing High Temp Button and Low Temp Button. * Step 2 1. Press Low Fan button to enter SEG2 value. 2.
- Page 20 Setting indoor unit address Setting indoor unit address manually Setting an indoor unit address (MAIN/RMC) 1. Check whether power is supplied or not. - When the indoor unit is not plugged in, there should be additional power Indoor Unit supply in the indoor unit. 1(L) 2.
- Page 21 • When “A”~”F” is entered to SEG4~6, the indoor unit MAIN ADDRESS is not changed. • If you set the SEG 3 as 0, the indoor unit will maintain the previous MAIN ADDRESS even if you input the option value of SEG4~6. •...
-
Page 22: Setting Installation Option
Setting installation option It could take maximum 60 minutes to operate for the protection of the compressor if the outdoor temperature is below -5°C. Ampere Limit Setting & Changing Procedure ◆ Do not adjust the “Ampere Limit Switch(DIP Switch)”, if it’ s not necessary : before modifying it, evaluate the total number of electric and electronics loads consumption and use “Ampere limits switch(DIP WARNING... - Page 23 Settings of PCB Display of the Outdoor unit ◆ Key Options of PCB Display - K1 : pipe checking operation button - K2 : Function button - K3 : Reset button - K4 : View mode change button Push Pipe Checking Heat Mode Try run Operation (Display:...
-
Page 24: Installing Transmitter And Sub Pcb For Central Control
A I nstalling transmitter and sub PCB for central control Transmitter installation (optional) ◆ RJ100F5HX ** / AJ100FCJ5 ** Accessories (Transmitter : MIM-B13B) DC Power Cable DC Power Cable Communication Transmitter Transmitter SUB Communication Cable Tie Case MAIN (12V) (5V) Cable Cable R2 R1 R2 R1... - Page 25 Sub PCB installation (optional) If indoor unit is AQV**/AR**, install sub PCB. 1. Turn the power off and take off the front panel of the indoor unit. 2. Take off the PCB cover. 3. Attach the Sub PCB to the right side of the Panel frame. 4.
-
Page 26: How To Use Additional Function
How to use additional function Function Remark K1 K2 K3 K4 External room sesor Disuse Centralized controller Disuse SW05 Compensate RPM Standard Only MH ** FS/FU ** , NJ *** LHX ** SW05 Drain Pump Disuse Only MH ** FS/FU ** , NJ *** LHX ** +2°C +5°C K5 K6 K7 K8... -
Page 27: Test Run And Final Check
A T est run and final check Test Run Please do cool mode try-run or heat mode try-run. ◆ Cool mode try-run : Push the [K2] button three times. ◆ Heat mode try-run : Push the [K2] button once. After 12 minutes of stationary condition check each indoor unit air treatment. ◆... -
Page 28: Troubleshooting
A T roubleshooting The table below give indication about self diagnostic routine. Some of error code requires activities exclusively for Authorise Service Center. ◆ The error indicated on the PCB display of outdoor unit EXPLANATION (The error indicated on the PCB display of outdoor unit) DISPLAY REMARK Communiaction error(indoor unable to receive data) - Page 29 DISPLAY EXPLANATION (The error indicated on the PCB display of outdoor unit) REMARK EvaOut1 Sensor Short/Open EvaOut2 Sensor Short/Open EvaOut3 Sensor Short/Open EvaOut4 Sensor Short/Open EvaOut5 Sensor Short/Open check pipe lenght, indoor unit filter, Outdoor unit freezing(Compressor stop) refrigerant leakage/charge and service port check pipe lenght, refrigerant Outdoor unit overload - Safety control(Compressor stop)
- Page 30 "EEE Yönetmeliğine Uygundur" "This EEE is compliant with RoHS" RJ100F5HXEA_IM_E_32978A(4).indd 30 2012-10-25 오후 5:22:55...
- Page 31 A A ppendix Product fiche Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. AR09FSFP *** x 1 AR12FSFP *** x 1 Model name...
- Page 32 Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. Model name AR09FSFP *** x 3/ AR12FSFP *** x 3/ AR09FSFP *** x 4/ (Indoor/Outdoor)
- Page 33 Product fiche Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. AR09FSFP *** x 2 AR12FSFP *** Model name AR09FSFP *** x 5/ + AR12FSFP *** x 2/...
- Page 34 Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. AR12FSSYAWTN x 1 AR09FSSYAWTN x 2 AJN016NDEHA x 1 Model name + AR18FSSYAWTN x 1/...
- Page 35 Product fiche Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. AJN026NDEHA x 2 MH026FSEA x 2 Model name AJN052NDEHA x 2/ + AJN035NDEHA x 2/...
- Page 36 Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. NJ026LHXEA x 2 MH020FAEA x 1 Model name MH052FUEA x 2/ + NJ035LHXEA x 2/...
- Page 37 Product fiche Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. MH026FAEA x 1 MH035FAEA x 1 + MH035FAEA x 1 MH035FNEA x 1...
- Page 38 Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Samsung Electronics Samsung Electronics Samsung Electronics Supplier's name Co., Ltd. Co., Ltd. Co., Ltd. MH035FJEA x 1 MH026FJEA x 2 AR12FSSEDWUN x 1 Model name + MH052FJEA x 1/...
- Page 39 Product fiche Energy Labeling Information(AC product) According to Commission Regulation (EU) No 626/2011 Supplier's name Samsung Electronics Co., Ltd. Samsung Electronics Co., Ltd. AR09FSSEDWUN x 2 AR12FSSEDWUN Model name + AR12FSSEDWUN x 2/ + AR24FSSEDWUN/ (Indoor/Outdoor) AJ080FCJ4EH AJ100FCJ5EH Sound Power Level (Inside/...
- Page 40 [ESPAÑOL] [FRANÇAIS] [ITALIANO] Nombre del proveedor Nom du fournisseur Nome del Costruttore Nombre del modelo (unidad Nom du modèle Nome del Modello (Unità interior/exterior) (intérieur/extérieur) Interna/Unità Esterna) Nivel de potencia acústica Niveau de puissance acoustique Livello di Potenza Sonora (interior/exterior) (intérieur/extérieur) (Unità...
- Page 41 Product fiche [PORTUGUÊS] [DEUTSCH] [EΛΛHNIKA] Nome do fornecedor Name des Lieferanten Επωνυμία προμηθευτή Nome do modelo (interior/ Modellbezeichnung Ονομασία μοντέλου (εσωτερικού exterior) (Innen-/Außengerät ) χώρου/εξωτερικού χώρου) Nível de potência sonora Schallleistungspegel Στάθμη έντασης θορύβου (interior/exterior) (Innen/Außen) (Εντός/Εκτός) Nome do fluido refrigerante Name des Kältemittels Ονομασία...
- Page 42 [ESPAÑOL] 1) Las fugas de refrigerante contribuyen al cambio climático. Cuanto mayor sea el potencial de calentamiento global (GWP) de un refrigerante, más contribuirá a dicho calentamiento su vertido a la atmósfera. Este aparato contiene un líquido refrigerante con un GWP igual a [1975]. Esto significa que, si pasara a la atmósfera 1 kg de este líquido refrigerante, el impacto en el calentamiento global sería, a lo largo de 100 años, [1975] veces mayor que si se vertiera 1 kg de CO Nunca intente intervenir en el circuito del refrigerante ni desmontar el aparato usted mismo;...
- Page 43 Product fiche [PORTUGUÊS] 1) A fuga de fluido refrigerante contribui para as alterações climáticas. Os fluidos refrigerantes com menor potencial de aquecimento global (PAG) contribuem menos para o aquecimento global do que os fluidos refrigerantes com maior PAG, em caso de fuga para a atmosfera. Este aparelho contém um fluido refrigerante com um PAG igual a [1975].
- Page 44 Memo RJ100F5HXEA_IM_Product fiche_32978A(4).indd 14 2012-11-12 오후 3:59:56...
