CD RECEIVER
CD-RECEIVER
RECEPTEUR CD
CD-RECEIVER
KD-LX333R
KD-LX111R
This unit is equipped with the display demonstration. To cancel it, see page 8.
Dieses Gerät ist mit einer Demonstrationsfunktion für das Display ausgestattet. Auf
Seite 8 wird beschrieben, wie Sie diese Demonstrationsfunktion deaktivieren können.
Cet appareil est équipé d'une démonstration des affichages. Pour l'annuler, référez-
vous à la page 8.
Dit toestel heeft een display-demonstratiefunctie. Zie bladzijde 8 voor het annuleren
van deze functie.
For installation and connections, refer to the separate manual.
Angaben zu Einbau und Verkabelung entnehmen Sie bitte der gesonderten Anleitung.
Pour l'installation et les raccordements, se référer au manuel séparé.
Zie de afzonderlijke handleiding voor details aangaande het installeren en verbinden van het
toestel.
KD-LX333R
KD-LX111R
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D'INSTRUCTIONS
GEBRUIKSAANWIJZING
BAND
ATT
SEL
TP/PTY
DISP
MODE
EQ
MONO
8
S
T
D
M
7
SOURCE
BAND
ATT
EQ
MONO
SEL
TP/PTY
DISP
MODE
7
8
S
T
D
M
SOURCE
For Customer Use:
Enter below the password you
have entered for your security
lock.
Retain this password for future
reference.
PASSWORD:
KD-LX333R
INT
RPT
RND
OFF
9
12
KD-LX111R
INT
RPT
RND
OFF
9
12
PIM171200
[E/EX]

Advertisement

Table of Contents
loading

Related Manuals for JVC PIM171200

Summary of Contents for JVC PIM171200

  • Page 1 GEBRUIKSAANWIJZING KD-LX333R BAND TP/PTY DISP MODE MONO SOURCE KD-LX111R BAND MONO TP/PTY DISP MODE SOURCE For Customer Use: Enter below the password you have entered for your security lock. Retain this password for future reference. PASSWORD: KD-LX333R KD-LX111R PIM171200 [E/EX]...
