TECHNICAL MANUAL
INVERTER WALL MOUNTED TYPE
RESIDENTIAL AIR-CONDITIONERS
(Split system, air to air heat pump type)
Indoor unit / Outdoor unit
SRK25ZJ-S / SRC25ZJ-SA
SRK35ZJ-S / SRC35ZJ-SA
SRK20ZJX-S / SRC20ZJX-SA
SRK25ZJX-S / SRC25ZJX-SA
SRK35ZJX-S / SRC35ZJX-SA
Manual No.'10•SRK-T-098
