Network - Sitecom MD-270 Full Manual

Full Manual MD-270/WL-355

Network

Use the Network menu to view the current network status of the MD-270/WL-355.
You can view the assigned IP address and other IP settings.
The Network menu is also used to set how the device will obtain an IP address so that
it can function on the local network. If your network has a functioning DHCP server,
such as a broadband router, the DHCP option can be used to automatically assign an
IP address. Choose the Static IP option to manually configure an IP address for the
media player.
To manually assign a Static IP address and other IP settings to the device:
1. Press the Home button on the remote control. The main menu opens.
2. Select the System icon and then press OK .
3. Select the Network icon, press OK .
4. Select Configure Network, press OK .
5. A network Settings window appears. Select the Next button and press OK to
proceed.
6. Select Advanced Setup, press OK , the IP address menu appears.
- 30 -
