V I . C O M F O R T A D J U S T M E N T S

SEAT HEIGHT ADJUSTMENT

The seat can be repositioned to different heights.
See figure 15.
1. Remove the seat from your Travel Scooter.
2. Disconnect the battery harness and remove the
battery pack.
3. Use the attached ring to pull and remove the
detent pin from the lower seat post.
4. Raise or lower the upper seat post to the desired
seat height.
5. While holding the upper seat post at that height,
align the adjustment holes of the upper and
lower seat posts.
6. Fully insert the detent pin.
7. Replace the battery pack and connect the
battery harness.
8. Reinstall the seat.
Travel Pro
UPPER SEAT POST
LOWER SEAT POST
DETENT PIN
Figure 15. Seat Height Adjustment
