X-Digital System XDS-PRO Quick Start Manual page 2

Your new XDS receiver may include a parts kit that includes two 6-foot RG-6 cables
and an L-band splitter that allows DC power to pass through one port.
B. Verify the XDS receiver is tuned and locked to the carrier
Once the satellite RF is properly connected, apply AC power to the receiver and
verify as follows:
If the SIGNAL LED is green, the receiver is locked to the carrier and the
LCD screen will display:
(Network Logo)
EB ##.# AG ### (# = numerical value)
EB should be above 7 and AG should be between about 40 and 70 for
proper operation.
If the XDS receiver does not acquire the network carrier, the red FAULT LED
will illuminate steadily and the LCD screen will display:
(Network Logo)
EB _ _._ AG ### (# = numerical value)
Verify proper RF connections and the XDS receiver should automatically
lock to the carrier.
To manually tune the XDS receiver to a network carrier:
o At the main screen with the network logo, press the SET key, then the left or
right arrow keys to reach Setup. Press SET.
o Press the left or right arrow keys to reach Tuner. Press SET.
o Press the left or right arrow keys to reach Frequency. Press SET.
o Use the four arrow keys and the SET key to set the frequency to the value on
the Network Data Sheet packed with your receiver.
o Press the left or right arrow keys to reach Symbol Rate. Press SET. Use
the four arrow keys and the SET key to set the symbol rate to the value on
the Network Data Sheet packed with your receiver.
The XDSPRO receiver should lock. (Green SIGNAL LED will illuminate
steadily).
