Questions, problems, missing parts? Before returning to your retailer, please contact our
customer service department at 1-866-788-5598.
¿Consultas, problemas, piezas faltantes? Antes de devolver la unidad a la tienda,
contáctese con nuestro Departamento de Servicio al Cliente llamando al 1-866-788-5598.
This product is covered by US patents and other international patents.
Este producto está protegido por patentes de los EE. UU. y otras patentes internacionales.
Derecho de autor. Todos los derechos reservados.
READ AND SAVE THESE INSTRUCTIONS
LEA Y GUARDE ESTAS INSTRUCCIONES
Copyright. All Rights Reserved.
ITEM / ARTICULO # 0008885
2000PSI ELECTRIC
PRESSURE WASHER
EQUIPO ELÉCTRICO DE
LAVADO CON AGUA A
PRESIÓN DE 2000 PSI
MODEL / MODELO # TF2000
Español p. 19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Task Force TF2000
Summary of Contents for Task Force TF2000
- Page 1 PRESSURE WASHER EQUIPO ELÉCTRICO DE LAVADO CON AGUA A PRESIÓN DE 2000 PSI MODEL / MODELO # TF2000 Español p. 19 READ AND SAVE THESE INSTRUCTIONS LEA Y GUARDE ESTAS INSTRUCCIONES Questions, problems, missing parts? Before returning to your retailer, please contact our customer service department at 1-866-788-5598.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ........................Safety Features ........................Power Supply and Electrical Info ..................... Package Contents ......................... Assembly Instructions ......................Operation Instructions ......................Cleaning Techniques ......................End of Use / Storage Instructions .................... Care and Maintenance ......................Troubleshooting ........................Warranty .......................... -
Page 3: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please contact our customer service department at 1-866-788-5598. Safety precautions are essential when any mechanical equipment is involved. These precautions are necessary when using, storing, and servicing mechanical equipment. - Page 4 SAFETY INFORMATION 15. Check power cords before using. Damaged cords can reduce performance of pressure washer or cause a fatal electric shock. 16. The narrow pin point stream is very powerful. It is not recommended for use on painted surfaces, wood surfaces or items attached with an adhesive backing. 17.
-
Page 5: Safety Features
SAFETY FEATURES ® AUTOMATIC TOTAL STOP The pressure washer is equipped with a stop device which will sense when the trigger on the gun is released. It will open the power circuit to the motor and cause the pressure washer to stop. WARNING: If Automatic Total Stop®... -
Page 6: Power Supply And Electrical Info
POWER SUPPLY AND ELECTRICAL INFO GROUND-FAULT CIRCUIT INTERRUPTER PROTECTION The pressure washer is factory-equipped with an electrical cord and a Ground Fault Circuit Interrupter (GFCI) power plug. This cord should only be connected to an electrical outlet installed in accordance with local safety regulations. NOTE: The power supply must be 120 V, 60 Hz and a minimum 15 amp dedicated circuit. -
Page 7: Package Contents
PACKAGE CONTENTS Part Description Quantity High pressure hose On/Off switch Detergent regulator dial High pressure outlet Pressurized hose reel Garden hose connector Spray gun Cord storage hook 35 ft power cord with GFCI Turbo spray nozzle Storage compartment Gun/Lance holders Dual detergent tanks Variable spray lance... -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Slide the storage hook onto the back of the machine as shown in Fig.1 Fig. 1... -
Page 9: Operation Instructions
OPERATING INSTRUCTIONS Step 1 Remove the shipping plug(s) from the front of the machine. Fig. 2 Fig. 4 Step 2 Connect the high pressure hose to the machine outlet. To connect, carefully insert the L-shaped connector fitting with the o-ring into the high pressure outlet and tighten the threaded nut by hand. - Page 10 OPERATING INSTRUCTIONS Step 4 Insert the spray lance into the gun by pushing firmly and simultaneously twisting 1/4 of a turn until locked into place. Fig. 4 Fig. 5 Step 5 Connect the garden hose to water supply and turn water on. Fig.
- Page 11 OPERATING INSTRUCTIONS Step 7 Before turning unit on, squeeze and hold trigger to bleed any trapped air out of the unit. Release trigger when water flow is steady. Fig. 4 Fig. 8 Step 8 Depress the ON button. Note that the motor will momentarily start and then stop.
-
Page 12: High Pressure / Low Pressure Spray
OPERATING INSTRUCTIONS WARNING: Risk of Injection or Injury. Do not directly discharge stream at anyone. WARNING: If the lance and nozzle are not securely locked into place, they could be ejected under high pressure when operating the gun. WARNING: Make sure the wand is pointed in a safe direction when starting the pressure washer. -
Page 13: Variable Spray
OPERATING INSTRUCTIONS Variable Spray The variable spray nozzle can adjust from fan to pencil point spray in both the high and low pressure positions. The spray can be adjusted by turning the nozzle head. CAUTION: The pencil point spray adjustment is very aggressive. We recommend that for most cleaning applications a 20°... -
Page 14: Detergent
OPERATING INSTRUCTIONS Detergent CAUTION: Use only approved pressure washer cleaners. Do not use bleach, chlorine, or any cleaners containing acids. This product is equipped with dual Dial-N-Wash® detergent tanks. The dial is used to control the suction between detergent tanks and increase/decrease detergent flow. 1) Remove the tank cap(s) (1-2) present on the back of the machine. -
Page 15: End Of Use / Storage Instructions
CLEANING TECHNIQUES 2) Allow detergent to remain on the surface for short time before rinsing. Do not allow the detergent to dry on the surface. 3) Rinse with clean water under high pressure. On a vertical surface, first rinse from the bottom up, then rinse from the top down. -
Page 16: Care And Maintenance
CARE AND MAINTENANCE Connections Connections on pressure washer hose, gun and spray wand should be cleaned regularly and lubricated with non-water soluble grease to prevent leakage and damage to the o-rings. Nozzles The nozzles should be lubricated with non-water soluble grease or light oil regularly. Clogging of the nozzle causes the pump pressure to build up too high and cleaning is immediately required. -
Page 17: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Motor will not start or stops while Defective GFCI. Perform GFCI reset procedure. See Operator’s operating. Manual page 6. Extension cord length or gauge incorrect. Use proper extension cord. See Operator’s Manual page 6. Loose or disconnected plug. Reconnect plug. -
Page 18: Warranty
WARRANTY Limited Warranty This product is warranted against defects in material and workmanship for a period of one year on all components excluding the gun, hose, lances, nozzles, and ground fault circuit interrupter (GFCI) which are only covered for 90 days; effective from the date of retail purchase and is not transferable. This warranty excludes incidental/consequential damages and failures due to misuse, abuse or normal wear and tear.
