TM
TM
ELECTRIC PRESSURE WASHER
ITEM: 248903
MODEL NO.: ZE04
CAUTION
BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND
RETAIN IT FOR FUTURE REFERENCE.
IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW
41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE
THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY. SEE PAGE 10 FOR
WINTERIZING PROCEDURE.
QUESTIONS, PROBLEMS, MISSING PARTS?
1-866-990-9918
Before returning to your retailer, call our customer service at
info@activeproducts.com
or email us at
PURCHASE DATE: _______________ SERIAL#: ___________________________________
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT.
ZE04_08/2007REV.3
Advertisement
Table of Contents
Related Manuals for Task Force ZE04
Summary of Contents for Task Force ZE04
- Page 1 ELECTRIC PRESSURE WASHER ITEM: 248903 MODEL NO.: ZE04 CAUTION BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE REFERENCE. IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Technical Specifications ........................i Precautions............................1 Safety Features and Electrical Power Information ................2 Package Contents ..........................3 Assembly Instructions..........................4 Operating instruction ...........................5 Using the Accessories .........................8 Working with Detergent ........................9 Shut Down and Clean-up ........................11 Taking a Break ........................... 11 Winterizing and Long-term Storage ....................12 Maintaining Your Pressure Washer ....................13 Troubleshooting ..........................14... -
Page 3: Precautions
IMPORTANT SAFETY INSTRUCTIONS - READ FIRST! SAFETY WARNINGS • This system is capable of producing 1750PSI. To avoid rupture and injury, do not operate this When using this product, basic precautions pump with components rated less than 1750PSI should always be followed: working pressure (including but not limited to •... -
Page 4: Safety Features And Electrical Power Information
SAFETY FEATURES AND ELECTRICAL POWER INFORMATION Extension Cords The pressure washer is equipped with a stop de- vice that will sense when the trigger on the gun is If possible, do not use extension cords with this released. It will open the power circuit to the motor product. -
Page 5: Package Contents
PACKAGE CONTENTS Needle Parts List Items No. Quantity Part Name Item No. Quantity Part Name Turbo wand Water filter Adjustable wand Needle Main unit Gun assembly Wing screw Left wing (gun holder) Detergent container Gun holster Extension hose Hose reel High-pressure hose Right-wing (wand holder) Quick-connect coupling... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Assembly Time: 5 minutes / Tools Required: Screw Driver Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects which could create a hazard. Remove any objects from the work area which could be tripped over, such as toys or outdoor furniture. Ensure that all doors and windows are closed tightly. -
Page 7: Operating Instruction
OPERATING INSTRUCTIONS Step 1 Make sure that the ON/OFF switch is in the “OFF” position. Fig. 2 Step 2 Fasten the quick-connect coupling (K1) onto the garden hose and then attach the quick-connecting cou- pling (K1) to the inlet adaptor (K2). Fig. - Page 8 OPERATING INSTRUCTIONS Step 3 Insert the wand (A or B) into spray gun, and twist 1/4 turn until rectangular tab appears. Fig. 4 A or B Step 4 Attach the L-shape coupler end of the extension hose (F) into the water outlet and the other end into the hose reel (H).
- Page 9 OPERATING INSTRUCTIONS Step 6 Plug the unit into an outlet. Press “TEST”. Then press “RESET” to assure proper connection to power. Fig. 7 Reset Test Step 7 Before turning the unit “ON”, depress the trigger to bleed any trapped air out of the pump and hose. Fig.
-
Page 10: Using The Accessories
USING THE ACCESSORIES Fig. 10 Adjusting the spray CAUTION The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet to fan Jet spray adjustment is very aggressive. Do spray by turning the nozzle as shown in Fig. 10. not adjust while spraying. -
Page 11: Working With Detergent
WORKING WITH DETERGENTS Working with detergent ensures a quick soaking of To apply detergents you must be operating at low- the dirt, and allows the high-pressure water to pen- pressure. This provides a gentle application of de- etrate and remove the dirt more effectively. Always tergent, with the pressure equivalent to a low-set spray detergent on a dry surface, do not pre-soak garden hose. - Page 12 WORKING WITH DETERGENTS — CONTINUED Step 4 CAUTION Turn on the pressure washer. Pull trigger to operate unit. The liquid detergent will automatically mix with Damage may occur to painted surface if water and be discharged through nozzle. Apply de- chemical is allowed to dry on surface.
-
Page 13: Shut Down And Clean-Up
SHUTTING DOWN AND CLEANING UP Step 1 Step 4 Turn the switch to “OFF” (0) position and unplug Disconnect the garden hose from the water inlet on cord from outlet. the unit. Step 2 Step 5 Turn off the water supply. Disconnect the high-pressure hose from the high- pressure outlet and engage the gun safety lock. -
Page 14: Winterizing And Long-Term Storage
WINTERIZING AND LONG-TERM STORAGE Optimum Winterizing Procedure Alternative Procedure If you cannot perform the Optimum Winterizing proce- Material required: Pump saver dure, you can still protect your pressure washer from Winterizing your pressure washer will help protect winter-damage: and prolong its life. It is strongly recommend you follow the below steps using a pump saver. -
Page 15: Maintaining Your Pressure Washer
USER MAINTENANCE Connections Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated with non-water soluable grease. Fig. 15 Fig. 16 Adjustable Nozzle (Fig. 15) Water Filter Screen (Fig. 16) The pressure washer is equipped with a water inlet When the nozzle is clogged, it will cause the pump to filter (L) that prevents debris going into the pump. -
Page 16: Troubleshooting
TROUBLESHOOTING Problem Cause Solution Motor will not start GFCI needs to be reset. Press RESET button on the GFCI. On/Off switch is in the “OFF” (O) position. Turn switch to the “ON” ( | ) position. Power cord is not plugged in. Plug in power cord. - Page 17 TROUBLESHOOTING - CONTINUED Problem Cause Solution Garden hose Loose fittings. Tighten fittings. connection leaks. Missing/worn rubber washer. Insert new washer. Spray wand, or Spray nozzle not properly attached. Insert the spray nozzle into the trigger extension, or gun. Carefully press in against the nozzle leaks.
-
Page 18: Warranty
WARRANTY LIMITED 1-YEAR WARRANTY This pressure washer is warranted to be free of defects in materials and workmanship under normal resi- dential use for one (1) year. Specific warranty applies to: • Electric motor and pump are warranted for one (1) year. •... -
Page 19: Replacement Parts And Diagram
REPLACEMENT PARTS AND DIAGRAM Manual Parts List Item No. Quantity Part Name Part No. Turbo wand (ZE04-090-0004) Adjustable wand (ZE01-090-0003) Gun Assembly (ZE01-090-0001) Left Wing (Gun holder) (ZE04-090-0007) Gun holder (ZE04-000-0001) Extension hose (ZE04-090-0008) Hand crank (ZE04-090-0009) Hose Reel (ZE04-090-0005) - Page 20 Printed in China...
